PCV-J200
SERVICE MANUAL
US Model
Canadian Model
Ver 3-2005B
Revision History
S400
Specifications
PERSONAL COMPUTER VAIO
9-874-308-13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCV-J200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony PCV-J200

Summary of Contents for Sony PCV-J200

  • Page 1 PCV-J200 SERVICE MANUAL US Model Canadian Model Ver 3-2005B Revision History S400 Specifications PERSONAL COMPUTER VAIO 9-874-308-13...
  • Page 2 CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. Confidential – 2 – PCV-J200 (UC)

  • Page 3: Table Of Contents

    5-2. Jumper Setting of Main Board ........5-2 FRAME HARNESS 6-1. Connector List .............. 6-1 6-2. Frame Harness Diagram ..........6-5 REPAIR PARTS LIST 7-1. Exploded View and Parts List ........7-1 7-2. Accessories and Parts List ........... 7-4 Confidential – 3 – PCV-J200 (UC)

  • Page 4: Disassembly

    P2-9 P2-5 P2-5 • Ps-s denotes the page concerned. • HDD has a low resistance to vibration, requiring careful handling. 2-2. MAIN ELECTRIC PARTS ARRANGEMENT mother board memory (DIMM) CD-RW/DVD-ROM switching power ethernet card modem card (PCI) Confidential PCV-J200 (UC)

  • Page 5: L Side Plate Ass'y

    L SIDE PLATE ASS’Y 1 ornamental screw 2 Remove the L side plate ass’y in the direction of arrow A . 2-4. UP CASE 1 screw (No.6-32UNC) 2 Remove the up case in the direction of arrow A . Confidential PCV-J200 (UC)

  • Page 6: Front Panel Ass'y

    2-5. FRONT PANEL ASS’Y 3 two claws 4 Remove the front panel ass’y in the direction of arrow A . 2 two claws 2-6. SLOT COVER 1 two screws (No.6-32UNC) 2 two slot covers Confidential PCV-J200 (UC)

  • Page 7: Ethernet Card

    2-7. ETHERNET CARD PCI3 1 screw (No.6-32UNC) 2 ethernet card 2-8. MODEM CARD (PCI) 1 screw (No.6-32UNC) PCI4 2 modem card Confidential PCV-J200 (UC)

  • Page 8: Hdd

    A . 4 three screws (No. 6-32UNC) 1 claw 5 claw 3 Disconnect respective power connectors on the mother board, 6 Remove the switching power CD-RW/DVD-ROM, in the direction of arrow B . FDD, and HDD. Confidential PCV-J200 (UC)

  • Page 9: Cd-Rw/Dvd-Rom

    2 harness (CD-ROM/AUDIO) 1 harness (IDE/CD-ROM) 3 two screws (PWH3 × 5) 4 Remove the CD-RW/DVD-ROM. 2-12. FDD 3 lever 1 harness (FDD) 4 FDD holder 2 screw (No.6-32UNC) 5 four screws (PWH3 × 5) 6 FDD Confidential PCV-J200 (UC)

  • Page 10: Memory (Dimm)

    Note 1: In opening the clips, hold lightly the top of the memories with your fingers to prevent a drop. Note 2: In removing the memories, always start from the one having largest bank number. 1 Open two clips. Confidential PCV-J200 (UC)

  • Page 11: Cpu

    Thermal diffusion grease : silicon compound (G-751) 200G Amount to apply : 0.1 g (as the same size as the tip of a match) grease Take care not to apply the grease to any other places because it has high conductivity. Confidential PCV-J200 (UC)

  • Page 12: Mother Board

    (SW-HOLDER ASS’Y) 8 five screws (SW) (No.6-32UNC) 7 harness (CD-ROM/AUDIO) 4 harness (FDD) 9 Remove the mother board in the direction of arrow A . 5 harness (IDE/CD-ROM) 8 three screws (SW) (No.6-32UNC) 6 harness (HDD) Confidential PCV-J200 (UC) (END)

  • Page 13: Mother Board Description

    SECTION 3 MOTHER BOARD DESCRIPTION 3-1. A7S-AV MOTHER BOARD Confidential PCV-J200 (UC)
  • Page 14 Confidential PCV-J200 (UC)
  • Page 15 Confidential PCV-J200 (UC)
  • Page 16 Confidential PCV-J200 (UC)
  • Page 17 Confidential PCV-J200 (UC) (END)

  • Page 18: Programs For Service

    SiS301 is checked. Serial COM1 As a test result, “< No SiS301 Exist! >” will be displayed, but Test is conducted automatically. the PCV-J200 does not use it and accordingly this is not a prob- Parallel LPT1 lem. Test is conducted automatically.

  • Page 19: Service Information

    Memo (formatted) PCV-J200 A-8048-262-A Seagate ST340823A 40 GB 177293813 Master/Slave selection Jumper setting Limit capacity to 32 Gbytes Factory setting Master or single drive Drive is a slave Master with a non-ATA compatible slave Enable cable select Confidential PCV-J200 (UC)

  • Page 20: Jumper Setting Of Main Board

    1 When Revision is 1.07 (A-8025-188-A), it can be used after “J0801” is opened. CAUTION Do not change the jumper with the power turned on. Before changing the jumper, turn off the power and disconnect the power cord from the set. Confidential PCV-J200 (UC) (END)

  • Page 21: Frame Harness

    Socket A ( Socket 462) AMD Duron and Socket A based AMD Athlon, supported * Connectors mentioned (not installed) are not used even they are Connector location on MB See the frame harness diagram mounted on MB. Confidential PCV-J200 (UC)
  • Page 22 See the frame harness diagram USBP1 Ground USBVCC3 pin assignments : USBP2# USBP2 Signal Name Ground GREEN BLUE USBVCC1/USBVCC2/USBVCC3 lines need the over current protector. Raychem miniSMDC110-2 or equivalent is used for that. Reserved DDCDAT HSYNC VSYNC DDCCLK Confidential PCV-J200 (UC)
  • Page 23 1.3.3 Secondary DASP (Only for Rev. 1.07 M/B) Secondary DASP Enable/Disable Connector location on MB See the frame harness diagram Jumper header Combination of jumper caps J0801 Disable Open Enable Closed US Model: Open JP Model: Closed Confidential PCV-J200 (UC)
  • Page 24 MEMO Confidential PCV-J200 (UC)

  • Page 25: Frame Harness Diagram

    Power PRIMARY IDE SECONDARY IDE Switch (direct connection) POWER/SUSPEND Harness (Rear side) (with connectors on both ends) HDD Bay1 30GB POWER Harness (soldering on either end) Harness (HDD) SW-HOLDER ASSY HDD Bay2 EXTENTION POWER (Front side) Confidential PCV-J200 (UC) (END)

  • Page 26: Repair Parts List

    51 A-8048-262-A HDD/S-U5 (40GB) ASSY (S) for CTO Option ♦ 51 A-8049-997-A HDD/S-U5/123 (40GB) ASSY (S) for CTO Option 7-300-000-55 SILICON COMPOUND (G-751) 200G *Used on replacing CPU, heat sink. (Refer to page 2-8) DIMM CTO HDD CTO Confidential PCV-J200 (UC)

  • Page 27: Accessories And Parts List

    Replace only with part number specified. Les composants identifiés par une marque 0 sont critiquens pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. WHEEL MOUSE (1) CONNECTION CORD (1) SPEAKER UNIT (1) Confidential PCV-J200 (UC) (END)
  • Page 28 PCV-J200 (UC) This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. English Sony Corporation 2005B0500-3 © 2005 Sony Corporation – ? – Published by Sony EMCS VAIO-GSC [C]...
  • Page 29 Revision History Suffix Contents QM No. Ver. Date First Ver. 1 2001.5.31 Edition QUICK MEMO Ver. 2 2004.1.28 (FIT-D2001_021) FIT-D2004_030 reflection QUICK MEMO Ver.3 2005.2.21 (FIT-D2004_115) FIT-D2005_033 reflection < Remarks > [Confidential] PCV-J200 (UC)
