INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
ER2001G / ER2401G
Model Numbers / Nos. de Modelos:
ELECTRIC RANGE
COCINA ELECTRICA
(Picture May Vary)
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS. AND SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
La sección en español empieza en la página 25.
Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 33152
www.avantiproducts.com
Advertisement
Table of Contents
Related Manuals for Avanti ER2001G
Summary of Contents for Avanti ER2001G
- Page 1 INSTRUCTIONS. AND SAVE FOR LOCAL ELECTRICAL INSPECTOR’S USE. La sección en español empieza en la página 25. Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice. Avanti Products, A Division of The Mackle Co., Inc.
-
Page 3: Table Of Contents
Cleaning Surface Units and Reflector Bowls Lift-up Cooktop Removable Storage Drawer Replacing the Oven Light Troubleshooting Guide Service for Your Appliance Wiring Diagram Your Avanti Products Warranty Instrucciones en Español Registration Information and Registration Card ABLE OF CONTENTS 26 ~ 37... -
Page 4: Range Safety
All safety messages will alert you to what the potential hazard is, tell you how to reduce the chanc injury, and let you know what can happen if the instructions are not followed. RANGE SAFETY Danger means that failure to heed th safety statement may result in severe personal injury or death. -
Page 5: Important Safeguides
When installing or removing the range for service, a rolling lift jack should be used. Do not push against any of the edges of the range in an attempt to slide it into or out of the installation. Pushing or pulling a range (rather than using a lift jack) also increases the possibility of bending the leg spindles or the internal coupling connectors. -
Page 6: The Anti-Tip Bracket
ATION INSTRUCTIONS ti-tip bracket is installed: Slide range forwa Look for the anti -tip bracket securely a Slide range back so rear range foot is under anti-tip bracket. an tip if you apply too much ed by properly CE PACKED... -
Page 7: Help Us Help You
Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call: Avanti Customer Service 800-220-5570 Keep proof of original purchase date (such as your sales slip) with this guide to establish the warranty period. -
Page 8: Parts And Features
PARTS & FEATURES Model # ER2001G OVEN VENT BACKSPLASH 6” BURNERS (3) COOKTOP 8” BURNER (1) CONTROL PANEL OVEN DOOR HANDLE GLASS OVEN DOOR DRAWER HANDLE LEVELING LEGS RATING LABEL ANTI-TIP BRACKET BROIL HEATING ELEMENT OVEN LIGHT BROILER TRAY AND GRID... -
Page 9: Parts And Features
PARTS & FEATURES Model # ER2401G OVEN VENT BACKSPLASH 6” BURNERS (3) COOKTOP 8” BURNER (1) CONTROL PANEL OVEN DOOR HANDLE GLASS OVEN DOOR DRAWER HANDLE LEVELING LEGS RATING LABEL ANTI-TIP BRACKET BROIL HEATING ELEMENT OVEN LIGHT BROILER TRAY AND GRID WIRE RACKS (2) BAKE ELEMENT (NOT SHOWN) REMOVABLE STORAGE DRAWER... -
Page 10: Important Safety Instructions
SO REAR RANGE FOOT IS UNDER A • CAUTION: Do not store items of interest to children in cabinets above a range or on the backsplash of a range – children climbing on the range to reach items could be serious injured. -
Page 11: Installation Instructions
This Unit Is For Indoor Use Only -SAVE THESE INSTR INSTALLATION INSTRUCTIONS HAVE THIS RANGE INSTALLED BY A QUALIFIED INSTALLER. Im o pr per installation, adjustment, alteration, or maintenance can cause injury or property damage. Consult a qualified installer, or service agency. -
Page 12: Important Precautions And Recommendations
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS After having unpacked the range, check to ensure that it is not damaged and the oven door closes correctly. In case of doubt, do not use it and consult your supplier or a professionally qualified technician. -
Page 13: Installation Of Your Electric Range
This range is intended for household use. Never use the appliance for any other purpose. • If you should decide not to use the range any longer (or decide to substitute an older model), before disposing of it, it is recommended that it be made inoperative in an appropriate manner... - Page 14 • Place your electric range on a floor that is strong enough to support it when it is fully assembled as in above picture. To level your electric range, adjust the leveling legs at the bottom of the unit.
-
Page 15: Electrical Connection
• The range can be connected directly to the fused disconnect (or circuit breaker box) through flexible, armoured or non-metallic sheathed, copper cable (with grounding wire). Allow two to three feet of slack in the line so that it can be moved if servicing is ever necessary. -
Page 16: Leveling The Range
The ground wire of the power supply cord must be attached to the frame of the range by using the green colored grounding screw. The power leads must be connected to the outside terminals. -
Page 17: Anti-Tip Bracket Installation
Secure the bracket to the floor using the screws supplied. • Slide the appliance into position. NOTE: If range is relocated, the bracket must be removed and installed in new location. Install the anti-tip bracket either right or left side. The contour line of back panel of appliance 1.30"... -
Page 18: Operating Your Electric Range
CONTROL PANEL Model ER2001G 1. Oven Function Selector Knob 2. Oven Thermostat Knob 3. Front Left Burner Control Knob 4. Rear Left Burner Control Knob ODEL ER2401G 1. Oven Function Sele ctor Knob 2. Oven Thermostat Knob 3. Timer Knob 4. -
Page 19: Using The Surface Unit
LO to HI with a number of ositions. The range of heat is increased by turning the knob towards HI, decreased by turning the knob towards LO. -
Page 20: Using The Oven
This also makes it mor to reach the cooking pots/pans. USING THE OVEN You can use your range for Bake and Broil. For that reason, the oven has two different heating elemen ts which are:... -
Page 21: Function Selector Knob
Broiler Pan maintain the selected temperature. For best efore adding the food to be broiled. Turn . Always broil with the oven door closed. ctor knob and thermostat control knob to the ces of the range get hot. is distributed... -
Page 22: Care And Maintenance
2 tablespoons of baking soda to a • Wash the shelves and rack with a mild detergent solution. • The outside of the range should be cleaned with mild detergent and warm water. • Wring excess water out of the spon electrical parts. -
Page 23: Lift-Up Cooktop
• After the unit has been removed, the reflector bowl can be lifted out of the • Clean the burners and reflector bowls with mild detergent and warm water. Wring excess water out of the sponge or cloth when cleaning them. •... -
Page 24: Troubleshooting Guide
BLEMS WITH YOUR ELECTRIC RANG You can solve many common appliance problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM Surface units will not maint ain a rolling boil or frying rate is not fast enou Foods cook slowly... -
Page 25: Service For Your Appliance
Avanti appliances. With the ppliance, you can have the confidence that if you ever need additional in ducts Customer Service team w... -
Page 26: Your Avanti Products Warranty
Alaska. C. Pick up and delivery. Your range is designed to be repaired in the home. D. Damage to your range caused by accident, misuse, fire, flood, acts of God, or use o products not mentioned in this manual. -
Page 27: Instrucciones En Español
Las partes de reemplazo autorizadas se pueden conseguir en los distribuidores de partes autorizados. Contacte el centro de servi de Avanti más cercano. INSTRUCCIONES EN ESPAÑOL r ninguna parte de su artefacto a no ser que esté... -
Page 28: Conexión Electrica
Si el cordón io autorizado por Avanti robados por UL, de ltaje. Estos cables pueden cto. rra por un... - Page 29 Para minimizar la posibilidad de choque eléctrico, desconecte la cocina del suministro eléctrico A/C, antes de empezar el mantenimiento. NOTA: Apagar la cocina no la desconecta del suministro eléctrico. Recomendamos que llame un té cnico calificado para dar mantenimiento a su cocina. INSTALACION DEL CORDON o Retire la placa de acceso del bloque terminal que se atrás de la cocina, removiendo los 2 tornillos.
- Page 30 INSTALACION DEL SOPORTE PARA EVITAR QUE LA COCINE SE VOLTEE Para reducir el riesg o que la cocina se voltee o voltee debido al uso inapropiado o al poner emasiado peso sobre la puerta del horno, la cocina debe estar asegurada al instalar correctamente el soporte para evitar que la cocina se voltee, el cual viene incluido cocina.
-
Page 31: Panel De Control
OPERANDO SU COCINA M delo ER2001G NEL DE CONTROL 1. Perilla selectora de función del horno 2. Perilla de tempera tura del horno 3. Perilla de control de la hornilla delantera izquierda 4. Perilla de control de la hornilla trasera izquierda 5. - Page 32 o Perilla del reloj Gire la perilla en sentido horario para seleccionar el tiempo de cocina deseado. El reloj marca hasta 120 minutos. Una alarma sonará en cuanto termina el tiempo seleccionado. o Perilla selectora de función del horno Hay tres funciones – OVEN LIGHT, BAKE y BROIL. Para apagar los calentadores d horno gire el selector de función a la posición OFF.
- Page 33 CONSEJOS PARA USAR LA COCINA Las características físicas de las ollas y sartenes influencian el desempeño de cualquier cocina. Por tanto, debe enfatizar la importancia de usar el equipo de cocina apropiad o Use equipo de cocina con fo energía y acortar los tiempos de cocción. o Solamente ciertos tipos de esmaltados son recome ndab...
- Page 34 TERMOSTATO DEL HORNO Esta perilla solo controla la temperatura de cocción y no enciende el horno. Gírela en sentido horario hasta alcanzar la temperatura deseada (desde WARM (tibio) hasta 450ºF La luz indicadora de encendido se enciende cu TABLA DE TEMPERATURAS PERILLA DE CONTROL WARM (tibio) RILLA DE SELECTOR DE FUNCION...
- Page 35 Broil (asar) En esta función, solamente el calentador de arriba se encenderá. El calor redistribuye por radiación. Asegúrese que la puerta del horno esté cerrada. EL control de temperatura ede variar entre WARM (tibio) hasta 450ºF. Para asar, siga los siguientes pasos: oloque la carne en la rejilla de asar y esta en la bandeja.
- Page 36 LIMPIANDO SU COCINA • Desconecte el suministro eléctrico A/C de la caja general o interruptor, verifique que la cocina esté apagada y que todas las hornillas estén apagadas y frías antes de mover nada. Luego retire todos las piezas incluyendo las rejillas. •...
- Page 37 TA: no tire o suelte la tapa bruscamente. De hacerlo, podría herirse o causar daño a la cocina. CAJON D E ALMACENAJE REMOVIBLE Para efectos d e limpieza, puede remover el ca más, entonces levántelo. Nunca almacene ningún material inflam REEMPLAZANDO LA LUZ DEL HORNO Antes de empezar cualquier mantenimiento d cocina del suministro eléctrico.
- Page 38 PROB d. Puede resolver muchos problemas comunes a los electrodomésticos fácilmente, ahorrándo se el costo de una posible llamada al servicio técnico. Pruebe las sugere mencionadas abajo p ara ver si puede resolver el problema antes de llam técnico. PROBLEMA •...
-
Page 39: Registration Information And Registration Card
R EGISTRATION INFORMATION Thank you for purchasing this fine Avanti products. Please fill out this form and return it within 100 days of purchase and receive these important benefits to the following address: Avanti Products, A Division of The Mackle Co., Inc.
