PS Power MT2000 User Manual

Brief introduction
Thank you for purchasing our product MT2000-- This is a multifunctional and intelligent charger. This product uses
the microcomputer control technology. Before using this product, please carefully read the following instructions.

Product Features

This product uses the microcomputer control, it can charge, discharge, or test any combination of any size, any
capacity Ni-Mh / Ni-Cd / Cylindrical lithium battery.
This product has many special functions: a dual-channel independent charging / battery capacity detection / battery
internal resistance detection / anti-reverse / short circuit protection / overcharge protection / and other functions, and
can monitor the battery voltage, current and other parameters automatically and timely. Suitable Battery:
Li-ion batteries:26650、26500、22650、18650~16340、14500、10440
Ni-Mh/Ni-Cd batteries: AA、AAA、C、SC

Specifications

I. Input parameters
AC 100-240V 50/60Hz；or DC12V/1.5A(It is recommended to use a dedicated power adapter)
II.
Output characteristics
1. DC li-ion batteries: 4.20V/250mA×2、500mA×2、700mA×2、1000mA×2
2.DC Ni-MH/CD batteries: 1.48V/250mA×2、500mA×2、700mA×2、1000mA×2
3.The highest voltage of Ni-MH and Ni-CD: 1.55V±0.05V;
4.The highest voltage of li-ion batteries: 4.25V±0.05V
5.Resistance test range: 0~99mR
6. Discharging voltage and current:
Ni-MH and Ni-CD battery discharging cut-off voltage: 0.9V±0.05V
L i-ion battery discharging cut-off voltage: 2.8V±0.05V
Discharging model
Test Model Discharging rate：250mA (when charging current is 250mA and 500mA) and 500mA
(when charging current is 700mA and 1000mA)
III. Use and storage environment
Operating Temperature
Operating Humidity
Testing Temperature
User Manual For MT2000
Discharging rate：250mA and 500mA
Pls indoor use
Storage Temperature
0 —35
35%—95%
Atmospheric Pressure
25 ±10
Storage Humidity
0 —40
45%—85%
70—106Mpa
