  • Page 2 :: Introduction Thank you for purchasing this Team Associated product. This assembly manual contains instructions and tips for building and maintaining your new RC10 B64 CR. Please take a moment to read through this manual to help familiarize yourself with these steps.
  • Page 3 :: Hardware - 1:1 Scale View Button Head (bhcs) Flat Head (fhcs) Ball Bearings 2x4mm (31510) 2.5x8mm (31448) 3x7x3mm (91475) Aluminum (8545) 3x6mm (31541) 2.5x8mm (31521) Aluminum (8551) 5x8x2.5mm (31400) Titanium (91591) 3x6mm (31531) Aluminum (8550) 3x8mm (25201) 5x10x4mm (91560) Titanium (91580) Aluminum (8553) Titanium (91592)
  • Page 4 Team Associated’s Tech Tips replacement parts. videos. These videos will help you with your build and setup! Associated Electrics, Inc. Customer Service 26021 Commercentre Dr. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501 http://www.TeamAssociated.com · http://www.RC10.com · http://twitter.com/Team_Associated · www.facebook.com/Team Associated...

  • Page 5: Bag 1.1, 1.2,

    3/17 :: Front and Rear Gear Differential Build - Bag 1.1, 1.2, 1.3 - Step 1 92076 92077 Sun Gear, 92079 Sun Gear Plastic Shim 5x8.5x0.17 92080 Front/Rear Gear Diff Case 92078 Diff Outdrive O-Ring 92082 Gear Diff Outdrives :: Front and Rear Gear Differential Build - Bag 1.1, 1.2, 1.3 - Step 2 92079 Shim 92079...
  • Page 6 :: Center Gear Differential Build - Bag 2.1, 2.2, 2.3 - Step 1 92077 Sun Gear 92080 92079 Center Gear Shim Diff Case 5x8.5x0.17 92078 Diff Outdrive O-Ring 92082 Gear Diff Outdrives :: Center Gear Differential Build - Bag 2.1, 2.2, 2.3 - Step 2 92076 Sun Gear, 92079...

  • Page 7: Bag 3.1, 3.2,

    :: Center Gear Differential Build - Bag 2.1, 2.2, 2.3 - Step 4 31448 2.5x8mm 31531 FHCS 3x6mm Tighten the Tighten the screws evenly in a screws evenly in a BHCS crossing order! crossing order! 92084 B64 Spur Gear, 78T 92078 Diff Gasket...

  • Page 8: Bag 4.1,

    :: Steering Rack Build - Bag 4.1, 4.2 - Step 1 25187 91048 31521 3x14mm HD 8mm 2.5x8mm BHCS 92004 Ball Stud BHCS Steering 91475 92005 31382 Rack 3x7x3mm Bellcrank Bellcrank Bearing Input Arm, Input Arm, Shim 18mm 31382 Shim 25215 91048 91048...
  • Page 9 :: Front Gearbox Build - Bag 5.1, 5.2 - Step 2 Arm Mount Insert, Step 1: Arm Mount B 91563 Add shims on 92079 10x15x4mm this side to Outdrive Bearing TIGHTEN 1° Up Diff Shims gear mesh. Subtract shims 92014 on this side to 25211 LOOSEN...

  • Page 10: Bag 6.1,

    :: Front Gearbox Build - Bag 5.1, 5.2 - Step 5 25202 92038 3x10mm B64 Front FHCS Body Post 92038 B64 Top Plate 31541 3x6mm FHCS :: Front Gearbox Build - Bag 5.1, 5.2 - Step 6 Arm Mount Insert, Arm Mount A 1°...
  • Page 11 :: Steering Block Build - Bag 6.1, 6.2 - Step 2 89202 91438 3x12mm CVA Rebuild BHCS Kit, 92058 92060 B64 Front B64 Front CVA Bone. CVA Axle 76mm 91438 CVA Rebuild 92061 B64 Front CVA Retainer :: Steering Block Build - Bag 6.1, 6.2 - Step 3 9956 Front Hex Roll Pin...

  • Page 12: Bag 7.1,

    :: Servo Build - Bag 7.1, 7.2 - Step 1 Servo Included servo spacers 31521 31531 91451 Included! can be installed between 2.5x8mm 3x6mm HD 4mm the servo mounting tabs BHCS Ball Stud and servo mounts to BHCS correctly align your servo. 92041 31622 B64 Floating...
  • Page 13 :: Rear Gearbox Build - Bag 8.1, 8.2 - Step 2 Arm Mount Isert, Step 1: Arm Mount C Add shims on 91563 this side to 92079 10x15x4mm TIGHTEN Outdrive 0° - Down Bearing gear mesh. Diff Shims Subtract shims 92014 on this side to LOOSEN...

  • Page 14: Bag 9.1,

    :: Rear Gearbox Build - Bag 8.1, 8.2 - Step 5 25202 3x10mm FHCS NOTE: Add one drop of black grease to all screws holding the gearbox ! 25204 3x16mm FHCS 92065 25203 3x12mm B64 Rear Center DogBone, 110mm FHCS :: Rear Gearbox Build - Bag 8.1, 8.2 - Step 6 Arm Mount Insert, Arm Mount D...

  • Page 15: Bag 10.1,

    :: Rear Hub Build - Bag 9.1, 9.2 - Step 2 91438 CVA Rebuild Kit, 92057 B64 Rear 92062 CVA Bone, B64 Rear 65mm 91563 Axle 10x15x4mm Bearing 91438 91562 CVA Rebuild 6x13x5mm Bearing :: Rear Hub Build - Bag 9.1, 9.2 - Step 3 91436 Wheel Hex 92055...
  • Page 16 :: Anti-Roll Bar Build - Bag 10.1, 10.2 - Step 2 Rear Anti Roll Bar Install Install the roll bar into the Anti Roll Bar Coupler #92054 until it bottoms out. :: Anti-Roll Bar Build - Bag 10.1, 10.2 - Step 3 25225 3x3mm Set Screw...
  • Page 17 :: Turnbuckle Build - Bag 11.1 - Step 2 91722 91723 Ballcup 3x48mm Turnbuckle Orient the notch to the left throughout the car. It indicates which end has the Front Camber left hand threads! Build x2 Racers Tip: Use black grease 20.50mm (#6588) on the threads of the...
  • Page 18 :: Shocks Build - Bag 12.1, 12.2, 12.3 - Step 1 31510 M2 x 4mm BHCS Mount the shock 91634 pistons with the 12mm V2 number facing up! Shock Piston 89278 (1.5 front) 4187 2.5mm (1.7 rear) Nylon Spacer, Washer (.030) 91617 V2 3x23...

  • Page 19: Bag 13.1, 13.2,

    :: Shocks Build - Bag 12.1, 12.2, 12.3 - Step 4 91491 #91310 12mm Shock Spring Cups 12mm threaded collar collar o-ring o-ring Racers Tip: Use your finger to rub Front: shock oil on the o-ring for smoother adjustment! 8.25mm 91310 91331 Rear:...
  • Page 20 :: Electronics/Wheels & Tires/Body & Wing Build - Bag 13.1, 13.2, 13.3 - Step 2 25211 91458 89090 3x10mm FT Battery Swaybar Ball BHCS Thumbwheel Joint 31382 5407 92047 B64 Battery Shim O-Ring Strap 91737 92047 3x20mm B64 Battery Set Screw Spacer Adjust the #89090 Ball joint according to how...
  • Page 21 :: Electronics/Wheels & Tires/Body & Wing Build - Bag 13.1, 13.2, 13.3 - Step 5 91738 M4 Locknut, 91738 Serrated M4 Locknut, Serrated :: Electronics/Wheels & Tires/Body & Wing Build - Bag 13.1, 13.2, 13.3 - Step 6 Front of Vehicle 0°...
  • Page 22 Gear ratios will vary depending upon motor brand, wind, and electronic speed control. Consult your motor and electronic speed control manufacturers for more information. Team Associated is not responsible for motor damage due to improper gearing. :: Notes...
  • Page 23 :: Shock Springs :: Shocks 4187 .030 Nylon Washer 91325 12mm Front Spring BRN 2.85 31327 VCS3 Shock Bottom Cap and O-Ring 2 ea. 91326 12mm Front Spring BLK 3.00 31510 2x4mm BHCS 91327 12mm Front Spring GRN 3.15 89278 2.5mm Washer 91328 12mm Front Spring WHT 3.30...
  • Page 24 :: Gear Differentials 31448 2.5x8mm FHCS 31531 3x6mm BHCS 91563 FT Bearings, 10x15x4mm 92073 B64 Gear Diff Kit, Front/Rear 92074 B64 Gear Diff Kit, Center 92075 B64 Ring Gear, 42T 92076 B64 Gear Diff Rebuild Kit, Plastic 92077 B64 Gear Diff Rebuild Kit, Metal 92079 92078 B64 Diff Gasket/O-Rings...
  • Page 25 :: Center Bulkhead 25201 3x8mm FHCS 25211 3x10mm BHCS 31532 31382 Alum. Washers, 5.5x1.0mm 31532 31532 3x8mm BHCS 31532 92044 B64 Motor Mount 31532 92045 B64 Motor Mount Slide 92046 B64 Center Bulkhead/Cover 25211 92046 31382 25211 92044 31382 92046 92045 25201 31532...
  • Page 26 :: Front Gearbox 25202 3x10mm FHCS 25204 3x16mm FHCS 25211 3x10mm BHCS 25225 3x3mm Set Screw 31511 2x5mm SHCS 31521 2.5x8mm BHCS 31531 3x6mm BHCS 89202 3x12mm BHCS 92008 91563 91563 10x15x4mm FT Bearings 92008 B64 Gearbox Front/Rear 92065 92014 B64 Arm Mount Inserts 92071 92015...
  • Page 27 :: Rear Gearbox 25202 3x10mm FHCS 31521 25204 3x16mm FHCS 25211 31511 25211 3x10mm BHCS 25225 3x3mm Set Screw 25225 31511 2x5mm SHCS 2x5mm SHCS 91563 31521 2.5x8mm BHCS 2.5x8mm BHCS 89202 3x12mm BHCS 3x12mm BHCS 91563 10x15x4mm FT Bearings 10x15x4mm FT Bearings 92008 B64 Gearbox Front/Rear...
  • Page 28 :: Front Shock Tower 25188 3x20mm BHCS 25211 3x10mm BHCS 25215 Locknut, M3 25188 25612 Locknut, M3 with Flange 91048 HD Ballstuds, 8mm 91447 Shock Bushing Balls 91533 91533 Shock Bushings, Short 91048 92009 B64 Front Shock Tower 25188 25211 25612 91048 25215...
  • Page 29 :: Body and Decals :: Factory Team and Option Parts 1364 FT Aluminum Servo Horn, 23T, 15.5mm 91741 RC10B6 Wing 1366 FT Aluminum Servo Horn, 25T, 15.5mm 91743 Adhesive Hook and Loop 31381 Aluminum Ballstud Washers, 5.5x0.5mm 92086 RC10B64 Decal Sheet 31382 Aluminum Ballstud Washers, 5.5x1.0mm 92087...
  • Page 30 :: Reedy Motors / Spare Parts / Accessories :: Reedy ESC’s Sonic 540-M3 25.5 252C Blackbox 800Z/540-M3 25.5 Combo Sonic 540-M3 21.5 253C Blackbox 800Z/540-M3 21.5 Combo Sonic 540-M3 17.5 254C Blackbox 800Z/540-M3 17.5 Combo Sonic 540-M3 13.5 255C Blackbox 800Z/540-M3 13.5 Combo Sonic 540-M3 10.5 256C Blackbox 1000Z+/540-M3 10.5 Combo...
  • Page 31 Factory Team 5.5mm Short Nut Driver SP24** AE Splash T-shirt - Blue (S, M, L, XL-5XL) 1569 Factory Team 7mm Nut Driver, T-Handle SP29 Team Associated Countertop / Setup Mat 1570 Factory Team 7.0mm Short Nut Driver SP30 Team Associated Pit Mat 1590 FT 3/32”...
  • Page 32 Club Racer Setup Driver: Event: Date: Track: Qualify: Main: Finish: Best Lap Time: Front Suspension: 20mm Ride Height: Axle Height: Bump Steer Spacing: -1° Camber: Toe: Ball Stud Spacing: None Anti-Roll Bar: Front Wheelbase Shim: Wheel Hex: Steering Plate: Caster Block: 7 °...
  • Page 33 Driver: Event: Date: Track: Qualify: Main: Finish: Best Lap Time: Front Suspension: Ride Height: Axle Height: Bump Steer Spacing: Camber: Toe: Ball Stud Spacing: Anti-Roll Bar: Wheelbase Shim: Wheel Hex: Steering Plate: Caster Block: 7 ° 10 ° 13 ° Ball Stud Spacing: Arm Mount A: Notes:...
