Efitment E018 Flywheel User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E018 Flywheel Elliptical User Manual
IMPORTANT：
Read all instructions carefully before using this product.
Retain this manual for future
reference. For customer service, contact: service@zoovaa.com.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E018 Flywheel and is the answer not in the manual?

Questions and answers

Related Manuals for Efitment E018 Flywheel

Summary of Contents for Efitment E018 Flywheel

  • Page 1 E018 Flywheel Elliptical User Manual IMPORTANT： Read all instructions carefully before using this product. Retain this manual for future reference. For customer service, contact: service@zoovaa.com.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Note the following precautions before assembling and using the machine. Assemble the machine exactly as described in the instruction manual. Before exercise, in order to avoid injuring the muscle, warm-up exercises are recommended. Please make sure all parts are not damaged and fixed well before use. This equipment should be placed on a flat surface.

  • Page 4: Parts List

    PARTS LIST Description Qty No. Description Main Frame 1 29 Handrail Arm End Cap Ø25x1.5 Handrail Arm Foam Grip 2 30 Cap Nut M10 Ø24xØ35x280 03L Left Handrail Arm Ø25x1.8 1 31 Curve Washer Ø10 03R Right Handrail Arm Ø25x1.8 1 32 Bearing Cup Ø55.6x16 Handrail Arm End cap...
  • Page 5 Description Qty No. Description Right Nylon Nut 1 66 Washer Ø10xØ20x2.0 Bearing 15/16” 1 67 T ension Bracket Washer Ø40x2.8 1 68 Bolt M6 x 45 Hexagon Bolt M6x35 1 69 Cap Nut M8 Brake 1 70 Spring Washer Ø12 Spacer Bushing Ø10x9 1 71 Wire Plug Ø12...

  • Page 6: Hardware Bag

    HARDWARE BAG Spanner S10-S13-S17-S19 Spanner with Phillips Screwdriver S13-S14-S15 Allen Wrench S6 2PCS Allen Wrench S8 (18L) Bolt for left Crank (18R) Bolt for right Crank (48) Wave Washer Ø26xØ16x0.3 1PC (48) Wave Washer Ø26xØ16x0.3 1PC (70) Spring Washer Ø12 (70) Spring Washer Ø12 (57) Left...

  • Page 7: Exploded Drawing

    EXPLODED DRAWING...

  • Page 8: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Spanner S10-S13-S17-S19 (30) Cap Nut M10, 2PCS (31) Curve Washer M10x56, 2PCS (27) Bolt Ø10, 2PCS STEP 1： Attach the Rear Stabilizer (No. 26) onto the Main Frame (No. 1) with 2 Cap Nuts (No. 30), 2 Curve Washers (No. 31) and 2 Bolts (No. 27). Tighten with the Spanner provided.
  • Page 9 Spanner S10-S13-S17-S19 (30) Cap Nut M10, 2PCS (31) Curve Washer M10x56, 2PCS (27) Bolt Ø10, 2PCS STEP 2: Attach the Front Stabilizer (No. 36) onto the Main Frame (No. 1) using 2 Cap Nuts (No. 30), 2 Curve Washers (No. 31) and 2 Bolts (No. 27). Tighten with the Spanner provided.
  • Page 10 Allen Wrench S8 llen Wrenches S6 Spanner S10-S13-S17-S19 (5) Bolt M10x20, 2PCS (6) Spring Washer Ø10, 2PCS (7) Washer Ø28xØ16xt5, 2PCS (48) Wave Washer Ø26xØ16x0.3, 2PCS (52) Rotation Rod, 1PC (18R) Bolt for right Crank, 1PC (18L) Bolt for left Crank, 1PC (48) Wave Washer Ø26xØ16x0.3, 1 PC (48) Wave Washer Ø26xØ16x0.3, 1 PC (70) Spring Washer Ø12, 1 PC...
  • Page 11 STEP 3: Remove 2 Bolts (No. 5), 2 Spring Washers (No. 6), 2 Washers (No. 7), and 2 Wave Washers (No. 48) from the Rotation Rod (No. 52). Insert the Rotation Rod (No. 52) into the hole of the Main Frame (No. 1). Attach the L & R Handrails (No.
  • Page 12 Spanner S10-S13-S17-S19 (20) Bolt M8x50, 4PCS (19) Nylon Nut M8, 4PCS STEP 4： Attach the Right Foot Pedal (No.11) onto the Right Foot Bar (No.16) using 2 Bolts (No.20) and Nylon Nuts (No.19). Tighten with the Spanner provided. Repeat the same procedure to assemble Left Foot Pedal (No.11) onto the Left Foot Bar (No.53).
  • Page 13 Spanner with Phillips Screwdriver S1-S14-S15 Allen Wrenches S6 Ø8xØ16xδ1.5, 4PCS (69) Cap Nut M8, 4PCS (72) Arc Washer (9) Bolt M8x40, 4PCS STEP 5: Insert the Right Handrail Arm (No. 3R) into the Plastic Bushing (No. 22) on the tube of the Right Handrail (No.

  • Page 14: Maintenance

    ADJUSTMENTS Adjusting the Spring Knob To increase the tension, turn the Spring Knob clockwise. To decrease the tension, turn the Spring Knob counter-clockwise. Adjusting the Rear Stabilizer End Cap Turn the Rear Stabilizer End Cap as needed to level the elliptical. MAINTENANCE Cleaning The elliptical bike can be cleaned with a soft clean damp cloth.

  • Page 15: Troubleshooting

    TROUBLESHOOTING PROBLEM SOLUTION Remove the computer console and verify the wire that comes from the computer console is properly connected to the wire There is no display on the computer that comes from the handlebar post. console. Check if the batteries are correctly positioned and battery springs are in proper contact with batteries.

  • Page 16: Exercise Computer

    EXERCISE COMPUTER FUNCTIONS: TIME………………………………00:00~99:59 MIN/SEC SPEED……………………………0.0~99.9 ML/H DISTANCE……………………… 0.00~999.9 ML CALORIE…………………………0.0~9999 CAL OPERATION PROCEDURES: 1. AUTO ON/OFF The exercise computer turns on when any key is pressed or when it receives an input from the speed sensor. The exercise computer turns off automatically when the speed sensor has no signal input and no key is pressed for approximately 4 minutes.
