4. Enter the password received from the administrator to register the TrueConf Server on
gatekeeper. If you leave this field empty, the registration without a password will be used.
5. The switch can be used to temporarily disable the server registration on the gatekeeper.
6. After making changes to "H.323 Gatekeeper" section, click "Save" to commit the changes. It is
necessarily to restart is the server.
7. This section contains TrueConf Server settings necessary for work in the Gatekeeper mode. In
this mode third-party H.323 endpoints can be registered on the server under the user account of
TrueConf Client application.
8. as explained above, after registered the TrueConf Server on the external gatekeeper, you can
make calls to the server using its registration data (h323-id and/or Dialed Digits (E.164)). This
section is used to determine the recipient of these numbers. Enter the TrueConf ID or Conference
ID (CID) of the recipient in the input field and press "Apply". If left empty, calls to the client
application of the TrueConf Server will be rejected.
DialedDigits
DialedDigits (E.164) is an identifier consists of numbers and special characters, «,#*» (for instance, dial
#h323:\e\041412 to call the subscriber 041412). Please note that the characters \e\ are mandatory
when using Dialed Digits (E.164). Thus, if you dial #h323:041412, H323-ID will be used instead of
DialedDigits (E.164)and the call can be addressed to other subscriber. After registration, other terminals
will be able to make calls to the client application TrueConf using this identifier.
Note: It is not necessary to indicate h323-ID and DialedDigits (E.164) simultaneously. To register a
server on the H.323-gatekeeper you only have to enter one of them.
Network settings
In this mode third-party H.323 endpoints can be registered on the server under the user account of
TrueConf Client application. Thus, a user may log in to a server using either TrueConf Client or any
H.323 endpoint with a support for password-based registration. By default if 'Use all IP addresses' is
selected, TrueConf Server will use all accessible connections by default (server's IP addresses + port
1719). Do not change this section without necessity. If you need to change IP addresses or ports to
access TrueConf Server (e.g. to deny access from a particular IP, or if port 1719 is blocked by Firewall
and you need another port) uncheck 'Use all IP addresses'. In this case, three buttons will be activated:
Add, Reset, and Apply. Using the Add button you can set an additional access point (you should input
an IP address for the access in the drop-down window (in the Host field), port, and protocall (TCP or
UDP)). By clicking any access point in the list, a similar editing window will open. If you click the Reset
button, all changes will be reverted to the previous saved state.
Default Call Destination
After registered the TrueConf Server on the external gatekeeper, you can make calls to the server using
its registration data (h323-id and/or Dialed Digits (E.164)). This section is used to determine the
recipient of these numbers. Enter the TrueConf ID or Conference ID (CID) of the recipient in the input
field and press "Apply". If left empty, calls to the client application of the TrueConf Server will be
rejected.

3.2.4.1. How Can a TrueConf User Make a Call to an H.323 Endpoint?

The administrator of a server must register an H.323 endpoint first. For information about how to do
this, see a detailed instruction. Enter the H.323 endpoint data in the Address Book. The ID of an H.323
endpoint should look like this:#h323:@IP, where IP is its address:
