- Page 1 Ballast Ballast Models 120v 50/60 Hz 230v 50/60Hz BIO 1.5 PWP 10-0518A 10-0514A Installation, Operation & Maintenance Read and Follow All Safety Instructions. Save These Instructions. Extensive Product Information Available at: ultraviolet.com buyultraviolet.com Document No. 98-1524D2 • May 2017 • ©2017 Atlantic Ultraviolet Corporation •...
-
Page 2: Table Of Contents
PRODUCT REGISTRATION ................................20 WARRANTY ....................................20 ....................................20 atent otiCe These instructions generally describe the installation, operation and maintenance of the Bio-Logic Pure Water Pack ® Questions that are not specifically answered by these instructions should be directed to the Factory. Atlantic Ultraviolet Corporation takes all possible precautions when packaging equipment to prevent damage. -
Page 3: Safety Warnings
SAFETY WARNINGS • All personnel should be alerted to the potential hazards indicated by the product safety labeling on this unit. • The following conventions are used to indicate and classify precautions in this manual and on product safety labeling. Failure to observe precautions could result in injury to people or damage to property. -
Page 4: Product Application
PRODUCT APPLICATION onstruCtion • All filtration and disinfection components of the Bio-Logic Pure Water Pack are conveniently mounted on a single, ® stainless steel, mounting bracket. • The system is designed to mount on a vertical surface, a secure (stud or concrete) wall or a cabinet wall, by the system- mounting bracket. -
Page 5: Installation
6-inches on the backside of the water purifier, and a minimum of 2-inches free space under the filter housings, to allow for housing removal, when changing filter cartridges. Figure 1 - Bio-Logic Pure Water Pack - Drinking Water System ®... -
Page 6: Addle Alve Nstallation
addle alVe nstallation IN ORDER TO PERFORM THIS TASK, BE SURE TO WEAR THE FOLLOWING SAFETY EQUIPMENT: SAFETY GOGGLES OR A FACE SHIELD, AS WELL AS GLOVES Check with the local public works department for plumbing codes. Follow all local plumbing codes when installing components of this system. -
Page 7: Ystem Nstallation
3. Tubing Connections: Run the tubing, connected to the saddle valve, to the inlet fitting of the sediment filter. Run the precut 24” tubing from the outlet of the carbon filter, to the inlet of the Bio-Logic water purifier. ®... - Page 8 It is recommended, when the carbon filter is new, to flush out the system thoroughly prior to use. Turn on the system’s faucet and allow water to run for 10 minutes to flush the filter and system. Figure 4 - Bio-Logic Pure Water Pack - Install ®...
-
Page 9: Ubing Nstallation
ubing nstallation • Measure and cut the tubing to desired length. Leave enough slack in the tubing so the system can be easily removed, if necessary. Cut the tubing square; remove all burrs and sharp edges. • Insert tubing into fitting; push until it reaches the tube stop. Avoid kinking or stretching tubing. Check that tubing is secure; gently pull on tubing, tubing should not pull free from fitting. -
Page 10: Maintenance
Shut off water supply to the system, by closing the supply valve. Open the system faucet and allow the system to drain. Release the pressure in the filter housing, by pressing the red pressure release button, located on top of each filter housing. See Figure 4 on page 8 - Bio-Logic Pure Water Pack - Drinking Water System for location. -
Page 11: Nstallation Or
Clean the inside of the filter housing before installing the new filter cartridge. Wash the inside of the filter housing with soap and hot water, rinse out thoroughly. Make sure the O-Ring is fully seated, in its groove. 7. Remove the wrapper from the new filter cartridge, and place into the filter housing. The filter cartridge will fit into the filter housing in either direction. -
Page 12: Leaning Or
Reinstall lamp in reverse order. Germicidal ultraviolet rays are harmful to eyes and skin. Do not restore power to water purifier until lamp and both EASY-OFF End Caps have been properly reinstalled. Reattach the ground connector to the grounding tab of the chamber, and restore power to the system. uartz leeVe nstallation... -
Page 13: Q Uartz
Disconnect power to water purifier Considerable force may be required to pull purifier from the mounting clips. Exercise extreme care when removing purifier. 2. Remove the tubing from the inlet and outlet fittings of the Bio-Logic Ultraviolet Water Purifier. See “Tubing Removal” for ®... -
Page 14: Isposal Of
13. Remount the water purifier to system-mounting bracket, by firmly pressing the purifier into the chamber brackets. 14. Reinstall the tubing; see “Tubing Installation” for the proper method of installing the tubing. Be sure that the tubing from the outlet of the carbon filter goes to the inlet of the water purifier, and the tubing from system faucet goes to the outlet of the water purifier. -
Page 15: Technical Specifications
. 10-0518a 10-0514a allast haVe roteCtion If power is applied to the ballast without a lamp connected to the circuit or if the lamp fails, the ballast’s lamp-out protection will prevent the ballast from operating, and a red LED light will illuminate and audio alarm will sound. To reset: disconnect the ballast from power and reconnect or replace the lamp. -
Page 16: Dimensional Data
DIMENSIONAL DATA Figure 10 - Dimensional Data All specifications, dimensional data, etc are approximate and subject to change without notice. -
Page 17: Replacement Parts
REPLACEMENT PARTS Figure 11 - Exploded View BIO-1.5 Water Purifier Table 4 - Replacement Parts BIO-1.5 BIO-1.5 Item No. Description Quantity Rubber O-Ring, Static Gland 00-1108B Steadfast Lamp Socket & Surelite 10-0518A Ballast, 120v 50/60Hz Steadfast Lamp Socket & Surelite 10-0514A Ballast, 230v 50/60Hz Steadfast... -
Page 18: Bio-Logic
REPLACEMENT PARTS Figure 12 - Exploded View of Bio-Logic Pure Water Pack ® Table 5 - Replacement Parts for Bio-Logic Pure Water Pack ® BIO-1.5 Item No. Description Quantity Filter Bracket 25-9132A ® 25-9125A1 Bio-Logic 1.5 120v 50/60Hz ® 25-9126A1 Bio-Logic 1.5 230v 50/60Hz... -
Page 19: Maintenance Notes
MAINTENANCE NOTES... -
Page 20: User Assistance
This manual Fax: 631.273.0771 describes the installation, operation and installation or use of this unit, contact E-mail: info@ultraviolet.com our offices, weekdays between 8:30 am maintenance of the Bio-Logic ® Website: www.ultraviolet.com Pure Water Pack and 5:00 pm Eastern Time, at: www.buyultraviolet.com PRODUCT REGISTRATION Please REGISTER your product immediately - you can do this in a number of ways.
