  • Page 1: User Manual

    DIGITAL MEDIA RECEIVER DL14DAB USER MANUAL...

  • Page 3: Table Of Contents

    Installation ....................... Troubleshooting .................... Thank you for buying this XTRONS product. Please read through these instructions so you will know how to operate this unit properly. After you have finished reading the instructions, keep this document in a safe place for future reference.

  • Page 4: Precaution

    Precaution Before installing this product - Use this unit with a 12-volt battery and negative grounding only. Failure to do so may result in a fire or malfunction. - To avoid shorts in the electrical system, be sure to disconnect the (-) battery cable before installation.
  • Page 5 - Do not disassemble or modify this product, as there are high-voltage components inside which may cause an electric shock. Be sure to consult your dealer for internal inspection, adjustments or repairs. Before using this product, be sure to read and fully understand the following safety information: - Do not operate this product or any applications if doing so will divert your attention in any way from the safe operation of your vehicle.

  • Page 6: To Ensure Safe Driving

    To ensure safe driving WARNING - LIGHT GREEN LEAD AT POWER CONNECTOR IS DESIGNED TO DETECT PARKED STATUS AND MUST BE CONNECTED TO THE POWER SUPPLY SIDE OF THE PARKING BRAKE SWITCH. IMPROPER CONNECTION OR USE OF THIS LEAD MAY VIOLATE APPLICABLE LAW AND MAY RESULT IN SERIOUS INJURY OR DAMAGE.

  • Page 7: Part Names And Functions

    Part Names and Functions 1. Power button Press to turn on or turn off the power. 2. MODE/Answer button Press to select Radio, DAB, USB, SD, AUX Input, or Bluetooth mode. Press to answer an incoming call in Bluetooth telephone mode. 3.
  • Page 8 a. Turn the ignition switch OFF. b. Press the reset button with a pen tip or other pointed implement. 5. Clock button Press to display the time. Press again to hide the time. When the time is displayed, press and hold the M.C. dial, and then turn right or left to set the time.
  • Page 9 button Press to perform manual seek tuning or skip to the next track/chapter. 18. AMS button Automatic memory storing Press and hold the button until the radio begins to search through the band of all available stations. Once the cycle is complete, the tuner will automatically store the 6 strongest stations into available presets.

  • Page 10: Remote Control

    Remote Control...
  • Page 11 1. MODE Press to select Radio, DAB, USB, SD, AUX Input, or Bluetooth mode. 2. MUTE Press to mute. Press again to unmute. 3. VOL+ Press to turn up the volume. 4. AMS/Answer Automatic memory storing Press and hold the button until the radio begins to search through the band of all available stations.
  • Page 12 9. INT/Number 2 button 10. RPT/Number 3 button Repeat play. RPT ONE: Repeat the current file. RPT ALL: Repeat all files. 11. -10/Number 5 button 12. +10/Number 6 button 13. RDM/Number 4 button RDM ON: Play files in random order. RDM OFF: Does not play files in random order.

  • Page 13: Radio

    Use the remote control Point the remote control in the direction of the front panel to operate. - The remote control may not function properly in direct sunlight. - Do not store the remote control in high temperatures or direct sunlight. - Do not let the remote control fall onto the floor, where it may become jammed under the brake or accelerator pedal.

  • Page 14: Usb/Sd

    Seek a service component 1. Press MODE to select DAB. 2. Press BAND to select the band. 3. Press to select a service component. Store service components While receiving the service component you want to store, press and hold one of the number buttons to store the service component.

  • Page 15: Bluetooth

    Connections Important safeguards WARNING XTRONS does not recommend that you install this product yourself. This product is designed for professional installation only. We recommend that only those service personnel, who have special training and experience in mobile electronics, set up and install this product. NEVER SERVICE THIS PRODUCT YOURSELF.
  • Page 16 Precautions before connecting the system WARNING - Do not take any steps to tamper with or disable the parking brake interlock system which is in place for your protection. Tampering with or disabling the parking brake interlock system could result in serious injury or death. - The black cable is ground.

  • Page 17: Installation

    insulation heats up, wires may become damaged, resulting in a short circuit or malfunction and permanent damage to the product. - Do not shorten any leads. If you do, the protection circuit (fuse holder, fuse resistor or filter, etc.) may fail to work properly. - Never feed power to other electronic products by cutting the insulation of the power supply lead of this product and tapping into the lead.

  • Page 18: Troubleshooting

    Make sure that the unit is installed securely in place. An unstable installation may cause skipping or other malfunctions. Removing the unit 1. Remove the trim ring. 2. Insert the supplied extraction keys into both sides of the units until they click into place.
