Damall D-2304 User Manual

Hide thumbs Also See for D-2304:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Setup Manual
U
M
SER
ANUAL
D
D-2304
AMALL
IP
PHONE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D-2304 and is the answer not in the manual?

Questions and answers

Related Manuals for Damall D-2304

Summary of Contents for Damall D-2304

  • Page 1 ANUAL D-2304 AMALL PHONE...
  • Page 2 D-2304 AMALL © 2007 Damall Limited – All rights reserved. Total or partial reproduction of this document is prohibited without prior written consent of the publisher. Such consent will only be granted in those instances when the source of the document is clearly stated.

  • Page 3: Table Of Contents

    IP P AMALL HONES ANUAL Contents 1 Introduction ......................5 2 Security Information ....................5 2.1 Correct Usage ....................5 2.2 Qualified Personnel ..................5 2.3 Accessories....................... 5 2.4 Waterproofing ....................5 2.5 Other Devices ....................5 2.6 Device Environment ..................6 2.7 Power Supply ....................
  • Page 4 D-2304 AMALL 4.4 SMS Messaging ....................15 4.5 Do Not Disturb ....................15 4.6 Memory Key DM-2604 ................... 15 5 Phone LCD Interface ....................17 5.1 Display ......................17 5.2 Ring Tone ....................... 17 5.3 Volume ......................17 5.4 Phone Setup ....................17 5.4.1 Do Not Disturb..................
  • Page 5 IP P AMALL HONES ANUAL 6.7 Memory ......................29 6.7.1 Phone Book .................... 29 6.7.2 Memory Key DM-2604 ................29 6.8 Config Manager ..................... 30 6.8.1 Save Config ..................... 30 6.8.2 Backup Config ..................31 6.8.3 Clear Config .................... 31 6.8.4 File update ....................

  • Page 6: Introduction

    Do not allow for contact with liquid that may be damaging to the product. The device is not waterproof. 2.5 Other Devices If a Damall product is connected with other products, it is important to read the user guide of the other equipment. Do not connect the device to any incompatible products.

  • Page 7: Device Environment

    No water or moisture should enter the device. 2.9 Product Disposal Damall products are compliant with FCC Part 15B and European Directives 2002/95/CE, 2002/96/CE and 2003/108/CE regarding the limitation of use of lead, mercury, cadmium, chromium (VI), flame retardants and hazardous materials within electric and electronic equipment and disposal.

  • Page 8: Product Warranty

    This guideline pertains to Damall’s standard basic warranty. The Manufacturer, Damall Limited, warrants its products to be free from defects in material and workmanship during the warranty period. The product is covered by warranty only if it is used in compliance with the instructions and guidelines contained in this manual.
  • Page 9 • Damage caused by accident, fire, water, any acts of nature, insufficient ventilation or other causes that do not fall under the control of Damall. • Damage caused from any unintentional or deliberate human acts. •...

  • Page 10: General Information

    AMALL 3 General Information The D-2304 is a stand-alone device that requires no connection to a PC to make phone calls. As well as providing the same features of a traditional telephone, the D-2304 supports both data and reliable voice quality through an IP network. It is fully compatible with SIP industry standards and can interoperate with any IP PBX system.

  • Page 11: Getting Started

    See Sections 5 and 6 for details on how to connect the phone either using the Phone LCD Interface or the Web Interface. 3.4.3 LCD Display The D-2304 telephone has a backlit green LCD display with several indicators. Indicator Definition Indicates network status.

  • Page 12: Key Features

    Indicates a headset is plugged in and in use Indicates voice mail waiting 3.4.4 Key features The D-2304 provides the same functionalities of a traditional telephone, as well as providing a wide range of features when connected to a server. Some key features: •...
  • Page 13 IP P AMALL HONES ANUAL • Full duplex speakerphone, redial, call log, adjustable volume • Voice recording (with a server) • Standard encryption and authentication (DIGEST using MD5) • Many configuration options – keypad, LCD, web interface or Telnet • TFTP or HTTP configuration uploading •...

  • Page 14: Basic Operation

    D-2304 AMALL 4 Basic Operation 4.1 Getting Familiar See below a quick description of the functions linked to each button: Button Description 5 buttons – 4 directional buttons (U AVIGATE IGHT ) and a central OK button Go to the previous / next item in the interface .

  • Page 15: Placing Calls

    IP P AMALL HONES ANUAL Cancel functions or exit the interface menu. To dial or to see a redial list Transfer the active call to another number Puts the current call on hold Displays the onboard phone directory HONEBOOK Shows the incoming and outgoing call lists Switch to the headset EADSET Turns off the microphone...

  • Page 16: Attended Transfer

    4.6 Memory Key DM-2604 The D-2304 has an RJ-45 jack marked MOD, which can link it to a memory extension module. The DM-2604 module contains 20 configurable memory keys which can be used as quick call buttons, allowing new calls as well as showing (with their LED lamps) the state of any users linked over the same network.
  • Page 17 IP P AMALL HONES ANUAL To configure stored numbers through the LCD interface: • Press the M# memory key button • If assigned, the stored number will be shown on the LCD display • If not assigned the display will show ‘Null’ •...

  • Page 18: Phone Lcd Interface

    D-2304 AMALL 5 Phone LCD Interface The phone interface can be accessed by pressing M on the phone. Other navigation within the menu is done using the directional N keys, the OK AVIGATE button, and the M buttons directly beneath the LCD display. The menu...

  • Page 19: Call Waiting

    IP P AMALL HONES ANUAL Busy Forward calls only if the line is busy No Answer Forward calls if there is no answer on the line 5.4.3 Call Waiting Enable call waiting. 5.4.4 Autodial This option sets an outgoing number that the phone will automatically dial each time the receiver is lifted.

  • Page 20: Sip Setup (1 And 2)

    D-2304 AMALL the network gateway. Pressing ) displays the status and IP address of the IGHT SIP server. 5.5.1 SIP Setup (1 and 2) Configure the options to enable each SIP account: Enable Identity Enables the SIP account Server Address...

  • Page 21: Web Interface

    ANUAL 6 Web Interface 6.1 Basic Access To access the D-2304’s Web Configuration Menu enter the URL of the phone’s IP address in a web browser. To check the phone’s existing network settings use the navigation pad on the phone. Pressing ) displays the network mode (either DHCP or static), the IP address of the phone, and the network gateway.

  • Page 22: Login

    To activate some of the changes (e.g. IP and memory key assignments) the telephone may need to be restarted. 6.2 Login To login the web interface a username and password are required. The D-2304 default is: Username: admin Password: admin Press Enter or click ‘Login’ after typing the login data.

  • Page 23: Lan Config

    Firmware version is on the bottom of the page. 6.4 LAN Config To define the network settings for the D-2304 select the type of IP address used – either Static or DHCP. If DHCP is selected, the phone should automatically detect an IP address. When selecting Static IP address the phone’s IP address, the Subnet Mask and the DNS...

  • Page 24: Sip Config

    6.5 SIP Config This page is to enter details for logging into an SIP server. If the D-2304 is not logged into an SIP server, none of the D-2304 functions will be usable – including making and receiving calls.

  • Page 25: Advanced Configuration

    IP P AMALL HONES ANUAL Enable Identity Enable the SIP Identity Display Name Phone extension display text; must be defined on the server Account Name SIP Authorisation Username Password SIP password as configured on the server Timeout Registration expiry time Server Address SIP Server address Server Port...

  • Page 26: User Defined Rules

    D-2304 AMALL End with ‘#’ Calls are placed after the # key is pressed. This is the default setting for the device. Fixed Length Calls must be a set number of digits long. Calls are placed once a set number of digits have been entered.
  • Page 27 IP P AMALL HONES ANUAL In the text field, enter the desired rule and click ‘Add’ to save it. Use the syntax code explained in the table below set new rules. See the examples given for further clarification. Any digit between 0 and 9 A range of numbers This must be defined either by using the min/max or by listing the digits separated by commas.

  • Page 28: Call Options

    D-2304 AMALL 6.6.3 Call Options This page Enables and Disables some D-2304 services: Autodial This setting specifies a fixed number that is automatically dialled whenever the handset is lifted. Call Forwarding This configures call forwarding to a specified number. Enter the number calls should forward to, and select one of the four settings: •...

  • Page 29: Sound And Audio

    HONES ANUAL 6.6.4 Sound and Audio This configures audio codecs, signalling types and volume. These need to be configured on the server as well as on the D-2304. Codec Rules Codecs used for calls Signal Standard The signal produced after calls.

  • Page 30: Memory

    6.7 Memory 6.7.1 Phone Book The D-2304 has an onboard phone book. Add new entries with the ‘Add’ button and fill in the contact fields: Name, Number, and preferred ring tone. Click ‘Submit’ button to add. Click ‘Delete’ to remove.

  • Page 31: Config Manager

    Whether or not to display the name on the LCD screen when the number is dialling. If the D-2304 telephone is being used with a configured server, each LED lamp next to a memory key will show the status of the associated extension according to the server’s configuration.

  • Page 32: Backup Config

    Use this to export a text file copy of the firmware configuration. 6.8.3 Clear Config Use this to RESET the D-2304 to its original default settings. 6.8.4 File update Select a file containing firmware or configuration upgrades. During the upgrade the display of the phone shows “Download”...

  • Page 33: System Management

    Username and password for an FTP user Password Filename Firmware updates use the “.bin” extension Config updates use the “.cfg” extension. 6.9 System management 6.9.1 Account Configuration This modifies the usernames and passwords used to access the D-2304’s web interface. | 32...

  • Page 34: Syslog Configuration

    To modify a password click ‘Modify’. 6.9.2 Syslog Configuration The D-2304 can send information to a syslog server. Enable the Syslog server as a way of troubleshooting or when required by a network administrator. The syslog server must be running within the same LAN as the D-2304.

  • Page 35: Time Configuration

    ANUAL 6.9.3 Time Configuration This page contains all time and date settings. Either set the time manually, or specify an SNTP server that the D-2304 can use to synchronise with its internal clock. 6.9.4 Reboot Use the reboot button to restart the D-2304. Settings should be saved before a reboot.

  • Page 36: Advanced Configuration Methods

    The Phone can also be configured by dialling on the keypad. Please contact Damall for full reference information on Dialling Configuration Codes. 7.2 Telnet Configuration For users familiar with Telnet, the D-2304 has a telnet interface with all basic telnet commands to configure options. 7.3 Telnet Post Mode For users familiar with Post Mode, the D-2304 also has this option.

  • Page 37: Quick Reference

    IP P AMALL HONES ANUAL 8 Quick Reference 8.1 Default Configuration The default D-2304 static IP address is: 192.168.0.179 8.2 Default Passwords Phone Interface: 123 Web Interface: Username: Admin Password: Admin | 36...
  • Page 38 Damall IP Phones © 2007 Damall Limited All rights reserved. Subject to change without notice. To contact Damall by telephone: +1 646 328 2048 (North America) +39 0230 468670 (International) To contact technical support by email: support@damalltech.com Damall Headquarters: Via G. Pascoli 18, 60044 Fabriano (An) Italy...
