RivieraPool Starto 2.0 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Technical Information WP 11 B
Version: 11/10/2016
Instruction Manual
AT T E N T I O N :
This is a preliminary version;
subject to modifications. If you have
any questions please contact our
service department.
P O R T A B L E S P A S
R I V I E R A S P A S
S T R A T O , W A V E
. w
P
S
r e fa b r i c at e d
w i m m i n g P o o l S
h i r l P o o l S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Starto 2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for RivieraPool Starto 2.0

Summary of Contents for RivieraPool Starto 2.0

  • Page 1 Technical Information WP 11 B Version: 11/10/2016 Instruction Manual AT T E N T I O N : This is a preliminary version; subject to modifications. If you have any questions please contact our service department. P O R T A B L E S P A S R I V I E R A S P A S S T R A T O , W A V E r e fa b r i c at e d...

  • Page 2: Table Of Contents

    Content Technical Drawings Strato 2.0 ..............................Page Strato 2.3 ..............................Page Wave 2.0 ..............................Page General Information / Requirements on site Specific use and purpose ........................Page Power supply ............................Page Fresh water..............................Page Waste water ............................... Page Delivery ............................... Page Noise insulation ............................

  • Page 3: Technical Drawings

    RivieraSpas - Portable 1. Technical Drawings Strato 2.0 Required space for pool with extracted supports for the pool cover Aufstellbereich mit ausgezogenen Hardtopauflagen ca. 3190 2110 Technik technique 1060 (incl. Daybed) (inkl. Daybed) Information: Additional information is available from our technical customer service department. We reserve the right, to perform production changes and improvements without prior notice In terms of technical progress.
  • Page 4 RivieraSpas - Portable Strato 2.3 Required space for pool with extracted supports for the pool cover Aufstellbereich mit ausgezogenen Hardtopauflagen ca . 3640 2420 technique Technik 1070 (incl. Daybed) (inkl. Daybed)

  • Page 5: Wave 2.0

    RivieraSpas - Portable Wave 2.0 Required space for pool with extracted supports for the pool cover Aufstellbereich mit ausgezogenen Hardtopauflagen ca. 3640 2390 technique Technik 1070 (incl. Daybed) (inkl. Daybed)

  • Page 6: General Information / Requirements On Site

    General Information / Requirements 2. General Information / Requirements on site 2.0 Specific Use and Purpose Portable spas with the appropriate equipment and accessories are warm water bubble pools, that are designed for private and family use and are installed in fitness centers, hotels and large bathing areas.

  • Page 7: Waste Water

    General Information / Requirements 2.4 Waste water The whirlpool should be emptied into the public sewage system (see diagram for he proper connection). Strato 2.0 Strato 2.3 Wave 2.0 1 = Power connection 2 = Water connection 2.5 Delivery The whirlpool is delivered on a pallet. The whirlpool should be transported to its destination completely packed, to avoid damage during transporation to the installation site.

  • Page 8: Positioning The Spa

    Commissioning and Operation 3. Commissioning and Operation Positioning the spa The hot tub should be positioned on a flat firm surface. Support should be given to the whole of the underside of the spa. For best results ensure that the surface is flat and level across the diagonals of the base.

  • Page 9: Start-Up And Operation

    Commissioning and Operation 3.3 Start-up and Operation The drain valves for emptying the hot tubs are factory closed. Before filling the spa, this has to be rechecked. The valves are closed when the rotary handle is across the direction of the line. The valves are open when the handles are in the direction of the line.

  • Page 10: Operation Of The Massage Jets

    Commissioning and Operation Exiting Priming Modus The system will automatically enter the normal heating and filtering at the end of the priming mode, which lasts 4-5 minutes. You can manually exit Priming Mode by pressing the “Exit” button on the Priming Mode Screen.

  • Page 11: Operating The Digital Display

    Commissioning and Operation 3.6 Operating the digital display 3.6.1 Operating the digital display SPA status Important information about spa operation can be seen on the Main Screen. Most features, including Set Temperature adjustment, can be accessed from this screen. The actual water temperature and Set Temperature can be seen, and the Set Temperature can be adjusted (see page 22).
  • Page 12 Commissioning and Operation Navigation Navigating the entire menu structure is done by touching the screen. When a text item is shown in white on the main screen, it is selectable. The menu selections on the right side of the screen can be selected. Select one of these to enter a different screen with additional controls.

  • Page 13: Setting The Temperature

    Commissioning and Operation 3.6.2 Setting the temperature Navigation Navigating the entire menu structure is done by touching the screen. When a text item is shown in white on the main screen, it is selectable. The menu selections on the right side of the screen can be selected. Select one of these to enter a different screen with additional controls.

  • Page 14: General Keys

    Commissioning and Operation 3.6.4 Command Buttons Exiting Screens When you see both of these buttons, whether they are labeled or not, they always mean Save and Cancel. They appear on most editing screens once you have changed the value on that screen.
  • Page 15 Commissioning and Operation Invert Page Up/Down If an Up or Down button is shown and pressed when in a Menu List, the list can be scrolled a page at a time. The scroll bar on the right side of the screen indicates the relative position of the page.

  • Page 16: Screenshot: Settings

    Commissioning and Operation 3.6.5 Screenshot: Settings Programming, Etc. The Settings Screen is where all programming and other spa behaviors are controlled. This screen has several features that can be acted on directly. These features may include Temp Range, Heat Mode, Hold, and Invert Panel. When one of these items is selected, it will toggle between two settings.
  • Page 17 Commissioning and Operation Heizmodus - Bereit vs. Ruhe Damit das SPA heizen kann, muss eine Pumpe Wasser durch die Heizung pumpen. Die Pumpe, die diese Funktion ausführt, ist die „Heizungspumpe“. Die Heizungspumpe kann entweder eine 2-Geschwindigkeitspumpe (Pumpe 1) oder eine Zirkulationspumpe sein. Wenn die Heizungspumpe eine 2-Geschwindigkeitspumpe ist, wird im „BEREIT“- Modus alle 1/2 Stunde Pumpe 1 mit geringer Geschwindigkeit laufen, damit die Wassertemperatur konstant bleibt, bei Bedarf geheizt wird und die Tempe-...

  • Page 18: Filling The Spa

    Commissioning and Operation 3.6.7 Spa-Befüllung Fill it up! Fill the spa to its correct operating level. Be sure to open all valves and jets in the plumbing system before filling to allow as much air as possible to escape from the plumbing and the control system during the filling process. After turning the power on at the main power panel, the top-side panel will display a splash screen or startup screen.

  • Page 19: Filtration Einstellen

    Commissioning and Operation 3.6.8 Filtration Main Filtration Using the same adjustment as Setting the Time, Filter Cycles are set using a start time and a duration. Each setting can be adjusted in 15-minute increments. The panel calculates the end time and displays it automatically. Filter Cycle 2 - Optional Filtration Filter Cycle 2 is OFF by default.

  • Page 20: Auxiliary Control Panel (S)

    Commissioning and Operation conditions. In colder climates, an optional freeze sensor may be added to protect against freeze conditions that may not be sensed by the standard sensors. Auxiliary freeze sensor protection acts similarly except with the temperature thresholds determined by the switch. See your dealer for details. Clean-up Cycle (optional) When a pump or blower is turned on by a button press, a clean-up cycle begins 30 minutes after the pump or blower is turned off or times out.

  • Page 21: The Fault Log

    Commissioning and Operation Unlocking To unlock either Settings or Panel first select Settings (if it says “On”) or Panel (if it says “On”), than press in the middle of the screen for at least 5 seconds. 3.6.12 The Fault Log The Fault Log is a record of the last 24 faults that can be reviewed by a service tech.

  • Page 22: Information

    Commissioning and Operation 3.6.13 Informations System informations The System Information Menu displays various settings and identification of the particular system. As each item in the menu is selected, the detail for that item is displayed at the bottom of the screen. Software 10 (SSID) Displays the software ID number for the System.

  • Page 23: The Cleaning Cycle

    Commissioning and Operation When a pump or blower is turned on by a button press, a clean-up cycle begins 3.6.14 The cleaning cycle 30 minutes after the pump or blower is turned off or times out. The pump and the ozone generator will run for 30 minutes or more, depending on the system.

  • Page 24: General Information

    Commissioning and Operation 3.6.16 General Information Most messages and alerts will appear at the bottom of the normally used screens. Several alerts and messages may be displayed in a sequence. The water is too hot – M029* The system has detected a spa water temp of 110°F (43.3°C) or more, and spa functions are disabled.

  • Page 25: Error Messages For Heating

    Commissioning and Operation 3.6.17 Error messages for heating The water flow is low – M016** There may not be enough water flow through the heater to carry the heat away from the heating element. Heater start up will begin again after about 1 min. See “Flow Related Checks”...

  • Page 26: Error Messages For Sensors

    Commissioning and Operation 5.4.18 Error messages for Sensors are out of sync – M015** sensors The temperature sensors MAY be out of sync by 3°F. Call for Service if this message does not disappear within a few minutes. Sensors are out of sync -- Call for service* – M026** The temperature sensors ARE out of sync.

  • Page 27: Error Messages For The Main System

    Commissioning and Operation 5.4.19 Error messages for the Program memory failure* - M022** main system At Power-Up, the system has failed the Program Checksum Test. This indicates a problem with the firmware (operation program) and requires a service call. The settings have been reset (Persistent Memory Error)* - M021** Contact your dealer or service organization if this message appears on more than one power-up.

  • Page 28: Things To Remember

    Commissioning and Operation General maintenance helps. 3.6.20 Reminder Messages Reminder Messages can be suppressed by using the Preferences Menu. See Page 18. Reminder Messages can be chosen individually by the Manufacturer. They may be disabled entirely, or there may be a limited number of reminders on a specific model.

  • Page 29: Audiosystem

    Commissioning and Operation Change the filter May appear on a regular schedule, i.e. every 365 days. Filters should be replaced occasionally to maintain proper spa function and sanitary conditions. Reminder messages can be reset from the panel. Messages that can be reset will appear with a “right arrow” at the end of the message. Press the message text to reset the message.

  • Page 30: Care And Maintenance

    Care and maintenance 4. Care and maintenance 4.1 Care manual whirlpool covers The cover One hot tub is designed for indoor and outdoor use. But even the best material and best processing are weather affected. Therefore, proper care should be exercised. It can sometimes happen that the hardtop slightly discolored or brighter or darker.

  • Page 31: Care Of Headrest And Pillows

    Care and maintenance 4.2 Care of headrest and Headrests and neck pillows can remain in the pool below the cover. These are pillows subjected to high humidity and water. This can lead to accelerated wear and contamination. Therefore, headrests and covers should be taken out and stored dry when not using the spa.

  • Page 32: Water Maintenance

    Care and maintenance 4.3.1 Water maintenance Thorough water maintenance forms the basis for a hygienic whirlpool. Clean and clear water is visually appealing and contributes considerably to the overall feeling of well being. Inadequate water maintenance can have an adverse effect on one’s health.

  • Page 33: Ph Values

    Care and maintenance The pH-value in the whirlpool should be between 7.2 and 7.4. This is the 4.3.4 pH Values ideal level for a disinfectant to work most efficiently and the water feels soft to the skin and is not corrosive. The strong addition of air when the massage jets are in use means that there can very quickly be a big increase in the pH value.

  • Page 34: Care And Cleaning Of The Resysta Panels

    Care and maintenance Care and Cleaning of the The Resysta surface of your hot tub is coated with a 2K Sealer RFS from Salamander Resysta panels sealers. The 2K Sealer forms a highly resistant transparent paint film, protecting it from mechanical and chemical damage. Resistance of the paint film provides protection against penetration from stains caused from external sources of fats, oils or other contaminants.

  • Page 35: Complete Winterisation

    Care and maintenance 4.5.2 Complete winterisation For this purpose, the power supply in the house should be switched off at the mains switch. All drain valves opened, leave the pool and piping completely empty. - Open the drain screw on the massage pump. - Remove, clean and dry the filter cartridge.

  • Page 36: Instructions For Bathing

    Instructions for bathing 5. Instructions for bathing Water temperature Water temperatures in whirlpools are significantly higher than those for instance of swimming pools. This is so, because it is through the combination of heat and the movement of the water that the desired feeling of relaxation can be achieved.

  • Page 37: Schematics

    Schemeatics 8. Schemeatics Platine BP2100G1 – PN 56389 – 02 Switch control BP2100 from 230V to 3 x 230 V All pins in the coloured areas are linked together. Thus it does not matter if the pin J79, J78 or J77 in the green area is used.
  • Page 38 Schematics Platine BP2100G1 – PN 56389 – 02 Connection points...

  • Page 39: Checklist

    Checklist 7. Checkliste für die Auslieferung von Whirlpools Customer was sent : 1. Filling and emptying of the pool • Check drain valves and gate valves open/close and are working � � • Air locks have been cleared � � •...
