TriMetric TM-2030-RV Technical Manual

Battery system monitor, Models TM-2030-RV and TM-2030-A
IMPORTANT: The wiring installation for this meter, especially the shunt installation
must be performed by someone knowledgeable in proper wiring, electrical practices,
and safety. If you do not have this knowledge please have someone install it who does,
or at least get some competent help to supervise the installation.
To install:
1. Please read or scan two pages of introductory information in section A.
2. Consult drawings Figure 1 and 2 (pages 7-8).
3. Follow step by step installation instructions in section B.
4. Program the two most important parameters into meter (section C1).
A. Before installing the TriMetric meter:
B. How to Install Meter and Shunt:
C1. How to determine program item P3: "battery system capacity"
C2. How to program your meter for the 100A/100mV shunt.
C3. Optional: Now or later you may wish to program P4, P5, P6
Warranty and customer service
Limited warranty
The TriMetric TM-2030 is warranted for three years against any manufacturing defect. Any meter not meeting the
specification or rated performance shall be replaced or repaired, at Bogart Engineering's discretion, provided it has not
been subjected to abuse or misapplication. For warranty service, please email bogart@bogartengineering.com. A return
merchandise authorization is required for all merchandise to be returned to Bogart Engineering.
How to obtain customer service
Please review our support page before attempting to contact us. Our distributors are able to answer simple
questions about
bogart@bogartengineering and someone will assist you.
TriMetric
Technical Manual
INSTALLATION Page 1-7
USER GUIDE Page 8-23
Bogart Engineering
BOGART ENGINEERING
www.bogartengineering.com

TM-2030
revised June 2017
products. For technical
1
support, send an email to
