3-IN-1 PNEUMATIC NAILER
Stock Number M673
OWNER'S MANUAL
WARNING:
It is the owner and/or operators' responsibility to study all WARNINGS, operating, and
maintenance instructions contained on the product label and instruction manual prior to
operation of this product. The owner/operator shall retain product instructions for future reference.
The owner and/or operator are responsible for maintenance, maintaining all decals or warning
labels and while in use, maintaining the unit in good working order. If the owner and/or operator
are not fluent in English, the product warnings and instructions shall be read and discussed with
the operators' native language by the purchaser/owner or his designee. Make sure that the
operator comprehends its contents. Safety information shall be emphasized and understood prior
to usage. The product shall be inspected per the operating instructions.
Users of this product must fully understand these instructions. Each person operating this product
must also be of sound mind and body and must not be under the influence of any substance that
might impair their vision, dexterity or judgment.
Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage!
If you encounter any problems or difficulties, please contact our customer service department at:
1-800-426-1262 between 6:30 a.m. and 4:30 p.m. Pacific time.
Advertisement
Table of Contents
Related Manuals for Performance Tool M673
Summary of Contents for Performance Tool M673
- Page 1 3-IN-1 PNEUMATIC NAILER Stock Number M673 OWNER'S MANUAL WARNING: It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and maintenance instructions contained on the product label and instruction manual prior to operation of this product. The owner/operator shall retain product instructions for future reference.
-
Page 2: Specifications
SPECIFICATIONS Weight: ................2.93Ibs(1.33kg) Normal Operating Pressure: ........... 60-110PSI Magazine Capacity: ..............100 Nails Firing Mode: ..............Sequential Fire Fastener Size Range: 18 Gauge Brads: 3/8"-2"(10-50mm) 16 Gauge Finish: 3/4"-2"(19-50mm) 18 Gauge Staples: 1/2"-1-5/8"(13-40mm) Average Air Consumption (CFM) ............1 Air Inlet (NPT) ................. 1/4 in. Hose Size (ID) ................ - Page 3 IMPORTANT SAFETY INFORMATION IMPORTANT SAFETY INFORMATION 8. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts and increases the risk of injury. 9.
- Page 4 IMPORTANT SAFETY INFORMATION IMPORTANT SAFETY INFORMATION 26. Do not use the tool as a hammer. 27. Keep all screws and covers tightly in place. Keep face, hands and feet away from firing head at all times. Never place your face, hands or feet near the firing head.
-
Page 5: Product Description
PRODUCT DESCRIPTION WARNING: Disconnect the tool from the air source before making any adjustments, changing accessories o storing the tool. Such precautionary safety measures reduce the risk of unintentional tool operation. Fastener Size Range: 18 Gauge Brads: 3/8"-2"(10-50mm) 16 Gauge Finish: 3/4"-2"(19-50mm) 18 Gauge Staples: 1/2"-1-5/8"(13-40mm) Fastener Type Item #... -
Page 6: Operation
OPERATION Install a filter, regulator, lubricator unit and moisture trap on your air delivery system per the manufacturer's instructions for these devices. Additionally, install a pressure gauge as close as practical to the tool, preferably within 10 feet. Select hoses with a minimum inner diameter of 1/4 inches and a maximum length of 100 feet. - Page 7 OPERATION pressure exceeding 200PSI. Excessive pressure can cause abnormal operation or cause the tool to burst, resulting in personal injury. WARNING: Do not exceed maximum recommended air pressure marked on the tool. Verify prior to using the tool that the air source has been adjusted within the rated air- pressure rang.
- Page 8 OPERATION CONT. Nail Loading WARNING: When loading the tools magazine, check that the nail tips contact the wear rail and slide smoothly against the surface of the magazine. If the nails are not loaded properly, the tool will misfire and nails can be deflected, causing the tool to react in an unexpected manner, and damage the tool.
- Page 9 OPERATION CONT. This tool is equipped with the safety and does not operate unless the safety is depressed. The methods of operation to drive nails with this tool is single actuation mechanism. 1. Position the nail outlet on the workpiece with finger off the trigger. 2.
-
Page 10: Maintenance
OPERATION CONT. Adjusting the Exhaust The direction of the exhaust vent can be changed by turning the top cover. Nail Indicator The red indicator bars are used to show when the tool needs to be reloaded. When the tool is loaded with a nail strip, the red indicator bars will no longer be visible in the indicator window. - Page 11 MAINTENANCE CONT. Cleaning WARNING: When cleaning a tool be careful not to disassemble any portion of the tool since internal components may be misplaced or safety components may be improperly mounted. Certain cleaning agents such as gasoline, carbon tetrachloride, ammonia. etc. may damage plastic parts and o-rings.
-
Page 12: Year Limited Warranty
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in connection with its products.
