Safety

2.1 Observing instructions

This instruction is the >> Original Version << in your language.
Please read this manual carefully and thoroughly before pro-
ceeding with the installation or modification of the heating
system.
These instructions are intended for authorised and trained
heating and sanitation experts who have experience in the proper
installation and maintenance of heating systems and hot water
storage tanks by virtue of their technical training and knowledge.
This manual provides all the necessary information for instal-
lation, start-up and maintenance, as well as basic information on
operation and settings. Please go through the attached docu-
ments for a detailed description of operation and control.
All heating parameters needed for smooth operation are already
factory-set. Please refer to other relevant documents for infor-
mation on setting the control.
Relevant documents
– ROTEX GCU compact:
– For the operator
– Operating manual for the operator.
– ROTEX RoCon BF: Operating instructions.
– When connecting additional ROTEX components; the associ-
ated installation and operating instructions.
The guides are included in the scope of supply for the individual
units.

2.2 Warning signs and explanation of symbols

Meaning of the warnings
Warnings in this manual are classified according into their se-
verity and probability of occurrence.
DANGER!
Draws attention to imminent danger.
Disregarding this warning can lead to serious injury or
death.
WARNING!
Indicates a potentially dangerous situation.
Disregarding this warning can result in serious injury
or death.
CAUTION!
Indicates a situation which may cause possible
damage.
Disregarding this warning can lead to damage to
property and the environment.
This symbol identifies user tips and particularly useful
information, but not warnings or hazards.
ROTEX GCU compact -
Special warning signs
Some types of danger are represented by special symbols:
Electric power
Danger of explosion
Risk of burning or scalding
Risk of poisoning
Validity
Some information in this manual has limited validity. The validity
is highlighted by a symbol.
Pay attention to the stipulated tightening torque
(See chapter 12.3 "Tightening torque")
Only applies for units with unpressurised solar system
connection (Drain Back).
Only applies for units with a bivalent solar system con-
nection (BIV).
Order number
Information about order numbers are identified with the shopping
basket icon .
Handling instructions
Instructions on actions are shown as a list. Actions of which
the sequential order must be maintained are numbered.
Results of actions are identified with an arrow.

2.3 Avoid danger

ROTEX Gas Combi Unit compact conforms to the state-of-the-art
and meets all recognised technical requirements. However,
improper use may result in serious physical injuries or death, as
well as property damage. Install and operate only ROTEX Gas
Combi Unit compact to avoid danger:
– as stipulated and in perfect condition,
– with an awareness of the safety and hazards involved.
This assumes knowledge and use of the contents of this manual,
the relevant accident prevention regulations and the recognised
safety-related and occupational medical rules.

2.4 Proper use

The ROTEX GCU compact may only be used for the heating of
hot water heating systems. It may only be erected, connected
and operated only according to the indications in this manual.
The ROTEX GCU compact must only be operated with the inte-
grated circulation pump and only in connection with a control
system that has been approved by ROTEX.
Any other use outside the intended use is considered as improper
and leads to a loss of warranty. The operator alone shall bear re-
sponsibility for any resulting damage.
Proper use also includes observing the relevant maintenance
and servicing conditions. Spare parts must at least satisfy the
technical requirements defined by the manufacturer. This is the
case, for example, with original spare parts.
2 x Safety
5
