X Rocker ACB138 Manual page 3

B-Accessories Supplied
B1-3m RCA Stereo to RCA stereo plug cable(1 PC)
B2-1m 3.5mm stereo male to 3.5mm stereo male cable (1PC)
B3-RCA female to female barrel adapter (2 PC )
B4-0.15m RCA stereo male to 3.5mm stereo male cable (1PC)
B5-0.15m 3.5mm stereo male to 3.5mm stereo male cable (1PC)
B6-INPUT:100-240V AC 50/60Hz
OUTPUT:9V DC 1000mA 9W Main POWER Adapter. (EFFICIENCY LEVEL:
B7-TX Box
9.84ft/3m
B1
3 28ft/1m .
B2
B3
*SOME PARTS MAY VARY SLIGHTLY
Need Help? Email: service@acebayou.com Web:
S
0.492ft/0.15m
B4
0.492ft/0.15m
B5
B6
B7
115V )
C-Audio Specification
Ⅰ
. The unit specifications:
Signal-to-Noise Ratio(Amplifier):Subwoofer: 50dB
Frequency Response: 60Hz~15kHz
＜
Distortion: Subwoofer: 4% (F=100Hz)
＜
Satellite: 1% (F=1kHz)
Input: DC 9V/1A
Ⅱ
.TX / RX specification:
1) TX Power supply 3V DC
/200mA
2XAAA Batteries (BATTERIES ARE NOT INCLUDED )
2) TX Current: 40mA
3) RX Current: 20mA
4) TX Transmission distance: < 65.6 ft / 20 meters (No buildings
or other barriers)
5) Environmental temperature: 14 F~158
6) Modulation mode: FSK
7) TX Work frequency: 914, 914.5,915MHz
8) RX Work frequency: 914, 914.5,915MHz
＜
9) TX Power: 10dBM
10) RX Sensitivity:-100dBM
11) RX frequency range: 50Hz~13KHz
12) Second harmonic suppression: -40dB
13) Band quantity: 3 channels
www.thexrocker.com Phone: 866.969.2603
＞
＞
Satellite: 60dB
℃ ℃
0 0
F / -10 ~70
3
