  • Page 2: Table Of Contents

    FX1-1052 APLICATION .............. 2 DESCRIPTION (FIG. A) ..........2 PACKAGE CONTENT LIST ..........2 EXPLANATION OF SYMBOLS ........2 GENERAL POWER TOOL SAFETY WARNINGS ....3 Work area ..................3 Electrical safety ................3 Personal safety ................3 Power tool use and care ............... 4 Service ..................

  • Page 3: Aplication

    FX1-1052 HAMMER DRILL 750 W FX1-1052 1 APLICATION The power tool is intended for driving and drilling through wood, metal, plastics and masonry. It is not designed for commercial use. WARNING Please read and understand this operating manual before use and keep it for your future reference.

  • Page 4: General Power Tool Safety Warnings

    FX1-1052 5 GENERAL POWER TOOL SAFETY WARNINGS Read all safety warnings and all instructions. Failure to follow all warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains operated (corded) power tool or battery operated (cordless) power tool.

  • Page 5: Power Tool Use And Care

    FX1-1052 Power tool use and care Do not force the power tool. Use the correct power tool for your application.The correct power tool will do the job better and safer at the rate for which it was designed. Do not use the power tool if the switch does not turn it on and off.Any power tool that cannot be controlled with the switch is dangerous and must be repaired.

  • Page 6: Before Starting Work

    FX1-1052 Always disconnect the hammer drill from the electric supply before you change a chisel or drill bit. Protect your eyes and other workers from flying particles and splinters. Wear a helmet! Set up partition walls! Wear work gloves to protect fingers from bruising and grazing.

  • Page 7: Fitting The Auxiliary Handle (Fig. 5)

    FX1-1052 Fitting the auxiliary handle (Fig. 5) The auxiliary handle can be fitted to suit both right-handed and left-handed users. Always use the tool with the auxiliary handle properly assembly. Loosen the auxiliary handle by unscrewing it. For right handed users,slide the auxiliary handle clamp over the collar behind the bit holder, handle at the left.

  • Page 8: Forward/Reverse Lever

    FX1-1052 If you press the lock-on button (9) while the on/off switch is depressed, the on/off switch is kept in the operating position. To release the on/off switch (8) again, press it briefly to and turn the tool off. The harder you squeeze the on/off switch (8) the faster the tool will operate.

  • Page 9: 12 Warranty

    FX1-1052 12 WARRANTY This product is warranted for a 12-month period effective from the date of purchase by the first user. This warranty covers all material or production flaws excluding : batteries,chargers, defective parts subject to normal wear & tear such as bearings, brushes,cables,and plugs, or accessories such as drills, drill bits, saw blades, etc.
