Summary of Contents for Ford FE1-13
-
Page 2: Table Of Contents
FE1-13 APPLICATION ............2 DESCRIPTION (FIG A) ..........2 PACKAGE CONTENT LIST ......... 2 SYMBOLS ..............3 GENERAL POWER TOOL SAFETY WARNINGS .... 3 Working area ................3 Electrical safety ................3 Personal safety ................4 Power tool use and care ............... 4 Service .................. -
Page 3: Application
FE1-13 IMPACT DRILL 1050W FE1-13 1 APPLICATION The power tool is intended for driving and drilling through wood, metal, plastics and masonry. It is not designed for commercial use. WARNING! Please read and understand this operating manual before use and keep it for your future reference. Your power tool should only be passed on together with these instructions. -
Page 4: Symbols
FE1-13 4 SYMBOLS The following symbols are used in this manual and/or on the machine: Warning / Danger! Wear noise protection Read manual before use. Wear eye protection accordance with essential applicable safety Double insulated standards European directives 5 GENERAL POWER TOOL SAFETY WARNINGS Attention ! Read all safety warnings and instructions. -
Page 5: Personal Safety
FE1-13 edges or moving parts. Damaged or entangled cords increase the risk of a lethal electric shock. When operating a power tool outdoors, use an extension cable suitable for outdoor use. Using a cord suitable for outdoor use reduces the risk of a lethal electric shock. -
Page 6: Service
FE1-13 power tool. If it is damaged, the power tool must be repaired. Many accidents are caused by using poorly maintained power tools. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to jam and are easier to control. -
Page 7: Operating Instructions
FE1-13 8 OPERATING INSTRUCTIONS Selecting the operation mode Select the required operating mode before use (drilling or hammer drilling). For drilling in wood, metal, plastics and soft stone, push the switch (3) to the drill position. For drilling in concrete or hard stone, push the switch (3) to the hammer position. -
Page 8: Technical Data
FE1-13 TECHNICAL DATA Model FE1-13 Nominal voltage 230V-50Hz Power consumption 1050W Chuck capacity Max.13 mm No load speed 0 – 2800/min SOUND EMISSIONS Noise values measured according to relevant standard. (K = 3) Acoustic pressure level LpA 97 dB(A) Acoustic power level LwA... -
Page 9: Environment
FE1-13 given in the manual), inexpert assembly, lightning strike, erroneous net voltage. This list is not exhaustive. Acceptance of claims under warranty can never lead to the prolongation of the warranty period nor commencement of a new warranty period in case of a device replacement. -
Page 10: Declaration Of Conformity
BORUN AGRO CHEMISTRY Ltd, Kvemo Ponichala, Marneuli Street N°44, Tbilisi, Georgia, declares that, Product : Impact drill 1050W Trade mark : Ford-tools Model : FE1-13 Is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards.
