NetDisk User Manual
—————————————————————————————————————————————
NetDisk and NetDisk Mini Modes
•
NDAS Mode
In NDAS Mode, NetDisk / NetDisk Mini is directly
attached to a 100MB/ Full Duplex Fast Ethernet
Switch or Wireless Access Point. Each user on the
network can use NetDisk / NetDisk Mini as if it was
a local disk drive.
•
Ethernet Mode
In Ethernet Mode, NetDisk / NetDisk Mini is directly
attached to a PC's Ethernet Port using a crossover
CAT5 cable, without the need of a switch.
•
USB 2.0 Mode
In USB 2.0 Mode, NetDisk / NetDisk Mini is directly
attached to a PC's USB 2.0 Port.
In addition, each user can enjoy all of the advanced NDAS
features such as aggregation, back-up, mirroring and flexible
expansion
Package Contents
The following items are included in the NetDisk / NetDisk
Mini package:
or
NetDisk Mini NetDisk
Ethernet Cable
Power Adapter and Power Cord
XIMETA, Inc.
—————————————————————————————————————————————
Installation CD
USB Cable
Network Direct Attached Storage / NDAS
Hardware Requirements
•
Fast Ethernet -100BASE-T / Full Duplex / 802.3u,
for wired configuration.
•
Wireless - 802.11a, 802.11b or 802.11g, for wireless
configuration.
•
Direct connection to PC's Ethernet Port –
100BASE-T / Full Duplex / 802.3u.
•
Requires crossover CAT5 cable (not included).
•
Direct connection to PC's USB 2.0 Port
Software Requirements
May need to install USB 2.0 driver included in installation
CD.
3
Requirements
NDAS Mode
Ethernet Mode
USB 2.0 Mode
