User manual
AGRETO three-point-scale
Weighing indicator B400
06 April 2017
ATTENTION! Read the operating instructions in this user manual before operating the
ATTENTION
ATTENTION
ATTENTION
equipment for the first time, in order to prevent damage to your scale or implement!
© © © © A A A A G G G G R R R R E E E E T T T T O O O O e e e e l l l l e e e e c c c c t t t t r r r r o o o o n n n n i i i i c c c c s s s s G G G G m m m m b b b b H H H H
Advertisement
Table of Contents
Related Manuals for Agreto B400
Summary of Contents for Agreto B400
-
Page 1: User Manual
User manual AGRETO three-point-scale Weighing indicator B400 06 April 2017 ATTENTION ATTENTION! Read the operating instructions in this user manual before operating the ATTENTION ATTENTION equipment for the first time, in order to prevent damage to your scale or implement! -
Page 2: Table Of Contents
Maintenance and cleaning ................. 30 Warranty ......................30 Declaration of conformity ................... 31 Disposal ......................32 Contact information .................... 32 © © © © AGRETO AGRETO electronics GmbH electronics GmbH page page: : : : 2 2 2 2 AGRETO... -
Page 3: Introduction
B300 weighing indicator) Connecting cable to the signal socket for the speed signal (only in combination with the B400 weighing indicator) GPS speed sensor for the speed signal (only in combination with the B400 weighing indicator) © © © © AGRETO... -
Page 4: Intended Use
AGRETO three-point scale 3 Intended use The AGRETO three-point scale is a scale for weighing three-point implements and/or their loads. It's mounted at the three-point linkage between tractor and implement. Tractors with Category II and III top links and lower links are suitable, but only Category II implements can be attached. -
Page 5: Safety
AGRETO three-point scale 4 Safety Safety guidelines for the purchaser IMPORTANT! Make sure that every person who works with the AGRETO three- point scale for the first time, has read and understood this user manual. Safety guidelines for operating and assembling personnel Appropriate equipment must be used when employing lifting machinery for transport. - Page 6 The scale must not be stored or used in a potentially explosive environment. Be careful not to trip over parts or tools that could be lying around you. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page page: : : : 6 6 6 6...
-
Page 7: Specifications
Horizontal distance top link pins-implement pins (top link shifted backwards): 130 mm or 160 mm depending on the mounting brackets Net weight approx. 80 kg including pins Dimensions: 104x84x20 cm (LxWxH, lying down) © © © © AGRETO AGRETO electronics GmbH electronics GmbH page... - Page 8 Shockproof and spraywaterproof Stabilized indicator for reading while driving OPTIONAL: Two-line weighing indicator with 30 / 20 mm high digits and special programming to display the spread rate per hectare © © © © AGRETO AGRETO electronics GmbH electronics GmbH page...
- Page 9 Deviation on slopes: hardly noticeable up to 5% Deviation when inclined sidewards: hardly noticeable up to 5% Deviation when not attached vertically: hardly noticeable up to 5%, can be compensated through calibration © © © © AGRETO AGRETO electronics GmbH electronics GmbH page...
-
Page 10: Getting Started
This will make sure that the load's position doesn't influence weighing accuracy. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page page: : : : 10... - Page 11 © © © © AGRETO AGRETO electronics GmbH electronics GmbH page...
-
Page 12: Mounting The Three-Point Scale
Connect the weighing signal cable to the plug on the three-point scale. You could run the cable along the hydraulic tubes to prevent damage. © © © © AGRETO AGRETO electronics GmbH electronics GmbH... - Page 13 Function EX - Supply - EX + Supply + SI - Signal - SI + Signal + © © © © AGRETO AGRETO electronics GmbH electronics GmbH page page: : : : 13 AGRETO AGRETO electronics GmbH electronics GmbH page...
-
Page 14: Connecting The Distance Sensor (If Available)
(=valve open) or unplugged. The amount of impulses per 100 m is set in the weighing indicator. © © © © AGRETO AGRETO electronics GmbH electronics GmbH... -
Page 15: Connecting The Gps Speed Sensor (If Available)
When there are separate adjustment mechanisms for the left and right side, mount the sensor and magnet on the side that opens when spread width is halved. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page... -
Page 16: Weighing Indicator
The [ZERO] button resets the indicator's zero point. Use this function for zeroing the scale with an attached and raised implement. This puts the zero point on the implement's empty weight, after which a load's weight can be read directly. © © © © AGRETO AGRETO electronics GmbH electronics GmbH... -
Page 17: Standard Weighing Procedure
You can repeat this process as often as you like. Switching off the weighing indicator Keep the button on the far left pressed until the weighing indicator switches off. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page... -
Page 18: Settings For Displaying The Spread Rate/Ha
1/32. In practice many signal sockets do not provide the signal according to standard, with values varying between 200 and 450. It's best you enter 400 and synchronize the displayed driving speed with the tractor's speedometer. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page... - Page 19 [OK] button. Press the [ZERO] button until it says END on the display. By pressing the [TARE] button the settings are stored, and the indicator restarts. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page page: : : : 19...
-
Page 20: Calculating The Spread Rate
It is therefore recommended to press the [F3] button as soon as you start the application process, and have already reached the desired driving speed. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page... - Page 21 The [F2] button can be pressed as often as desired. Every time the updated quantity will be displayed. You can press the [F1] button to start, and the [F2] button to read the result while driving. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page...
- Page 22 When the driving speed or settings change, a new cycle has to be started to obtain meaningful average results. Pressing the [F3] button ends manual mode and the indicator switches back to automatic mode. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page...
-
Page 23: General Settings
(calibration value at 0.8 mV) Calibration When the AGRETO three-point scale is operated vertically or with a slight slant forward or backward, the factory-set calibration is correct and the scale is ready for direct use. If this isn't possible, the weighing indicator must be calibrated, depending on how the scale is employed. - Page 24 Press the [OK] button. SPAN appears on the display. Press the [ZERO] button until it says END on the display. Press the [TARE] button, the settings are stored, the indicator restarts. © © © © AGRETO AGRETO electronics GmbH electronics GmbH...
-
Page 25: Summing Function
Press the [OK] button on the numeric keypad. Press the [ZERO] button until END appears on the display. Press the [TARE] button, the settings are stored, the indicator restarts. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page... -
Page 26: Performing A Summation
ALL.TOT and “Clear?” Appear on the display. Confirm by pressing the [OK] button. The summation memory is now cleared. Press the [OK] button to return to normal display mode. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page... -
Page 27: Error Messages
Turn off the indicator Connect the scale Turn on the indicator E2000 Weighing signal out of range Check cable and plugs for damage © © © © AGRETO AGRETO electronics GmbH electronics GmbH page page: : : : 27 AGRETO AGRETO... -
Page 28: Troubleshooting
Stand on the left and then the right side of the linkage. If the difference is larger than 5 kg, one of the load cells is malfunctioning or load cell © © © © AGRETO AGRETO electronics GmbH... - Page 29 If you can't slide them any further, you have to remove the scale and insert the upper link pin in the next hole. © © © © AGRETO AGRETO electronics GmbH electronics GmbH page...
-
Page 30: Maintenance And Cleaning
AGRETO three-point scale 9 Maintenance and cleaning Clean the AGRETO three-point scale together with your implement. High- pressure cleaning must be done from a distance of at least 0.5 m. Store the machine in a dry and safe place. When you don't use the machine for a longer period, treat it with a suitable anticorrosive agent. -
Page 31: Declaration Of Conformity
3820 Raabs Submitted by: Anton Eder Managing director Pommersdorf 27.01.2014 ___________________ ________________ ______________________ legally binding signature © © © © AGRETO AGRETO electronics GmbH electronics GmbH page page: : : : 31 AGRETO AGRETO electronics GmbH electronics GmbH page page... -
Page 32: Disposal
Despite careful treatment and examination of the contents, no warranty is made with respect to information in this user manual. Any liability of the author is excluded. Copyright © 2017, AGRETO electronics GmbH AGRETO electronics GmbH Pommersdorf 11 A-3820 Raabs Tel.: +43 2846 620 0...
