Service Manual
SM 8000-100-01 Ed 04
Hydraulic Specification
Actuator type Oil displacement
ml
BRC 125* 26
BRC 250 50
BRC 500 102
BRC 1000 209
BRC 2000 400
BRC 4000 800
BRC 8000 1600
BRC 16000 3100
KC 65 21
KC 125 82
KC 250 428
KC 325 793
KC 400 1700
Actuator type Oil displacement
BRCF 125* 26
BRCF 250 50
BRCF 500 102
BRCF 1000 209
BRCF 2000 400
BRCF 4000 800
BRCF 8000 1600
BRCF 16000*** 3100
KF 65 21
KF/KFR 125 82
KF/KFR 250/150 265
KF/KFR 250 428
*) Only bulkhead mounted on LPU. Please note that min. time is calculated value. BRCF spring and value differ-
ence can change the actual time.
**) The Standard minimum closing time is listed without QCB and based on an ordinary tank design, except for
the BRCF 16000 which only operates with a pressure tank. In case of LPU-S equipped with Pipes to actuator and/or
Pressure Tank an extensively increased closing time should be expected, please ask for guidance's.
***) BRCF 16000 should always be equipped with a Pressure tank.
114
Min. operating time (sec.) open/close for LPU-D
50 Hz
1.6
3.0
6.1
13
24
48
96
186
1.35
4.9
25.6
48
102
Min. operating time (sec.) open for LPU-S
50 Hz
4
8
15
31
60
120
240
465
1.2
4.9
15.9
25.6
Damcos LPU: LPU Technical Data
60 Hz
1.3
2.5
5.1
10
20
40
80
154
1.1
4.1
21.2
40
85
60 Hz
3
6
13
26
50
100
200
388
1.1
4.1
13.2
21.2
February 2017
Min. closing time**
N/A
1
2
4
8
16
32
64
248
1
3
10
17
