Summary of Contents for BXB Electroics EDC-1051

  • Page 1 BXB ELECTRONICS CO., LTD. 1/23 www.bxb.tw...
  • Page 2: Table Of Contents

    BXB ELECTRONICS CO., LTD. Contents page Overview ....................... 3 Safety Instructions ....................5 Installation ......................6 Connection between main control unit & microphone units ......... 6 EDC 1051 Operation and Function ............... 7 Front Panel Description ..................7 Rear Panel Description ..................8 Turn On ........................
  • Page 3: Overview

    BXB ELECTRONICS CO., LTD. Overview Thank you for purchasing EDC 1000 conference system from BXB Electronics Co. EDC1000 is the easiest digital conference system with superb performance and elegant design which can be used in various conference rooms. EDC1051 main control unit has the latest built-in digital control module which can control up to 10 chairman units and 127 delegate units.
  • Page 4 BXB ELECTRONICS CO., LTD. System Features Main Control Unit 1. Auto-detect connection 2. Digital control capability: 10 chairman units and 127 delegate units 3. 1(20*4) LCD screen and 3 conference mode setting buttons: MODE, UP, DN 4. built-in digital volume control module 5.
  • Page 5: Safety Instructions

    BXB ELECTRONICS CO., LTD. Safety Instructions 1. Please read and observe these instructions before installing and using the apparatus. Use only accessories specified by the manufacturer. The manufacturer is not liable for damage caused by the use of non-specified accessories. 3.
  • Page 6: Installation

    BXB ELECTRONICS CO., LTD. Installation Connection between main control unit & microphone units CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: . TO PREVENT ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK) . NO USER SERVICEABLE PARTS TO QUALIFIED SERVICE PERSONNEL MADE IN TAIWAN http://www.bxb.com.tw IOIOI...
  • Page 7: Edc 1051 Operation And Function

    BXB ELECTRONICS CO., LTD. EDC 1051 Operation and Function Front Panel Description Conference System Control Unit Power Mode Down 1. Power switch 2. Conference mode setting buttons MODE Mode select button Mode parameter increase / volume up Mode parameter decrease/ volume down 3.
  • Page 8: Rear Panel Description

    BXB ELECTRONICS CO., LTD. Rear Panel Description CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: . TO PREVENT ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK) . NO USER SERVICEABLE PARTS TO QUALIFIED SERVICE PERSONNEL MADE IN TAIWAN http://www.bxb.com.tw IOIOI DC FUSE L.
  • Page 9: Turn On

    BXB ELECTRONICS CO., LTD. 1. Turn On 1.1 After confirming all the wiring is done, switch on the main controller and the LCD will display following information: B X B E D C 1 . 0 V e r s i o n C o n f e r e n c e S y s t e m...
  • Page 10: Lcd Instructions

    BXB ELECTRONICS CO., LTD. 2. LCD Instructions ○ N O : ○ M O D E : N o r m a l ○ O P E N - M I C : ○ A U T O - O F F : S e c ○...
  • Page 11: System Operations & Settings

    BXB ELECTRONICS CO., LTD. 3. System Operations & Settings 3.1 Talking Microphones Display 3.1.1 When conference microphone is using, the red light ring on it will be on. Meanwhile, its ID code will be displayed on the LCD on main control unit. 3.1.2 Three using microphones codes can be shown on the preset menu.
  • Page 12: Conference Mode Setting

    BXB ELECTRONICS CO., LTD. 3.2 Conference Mode Setting 3.2.1 Press MODE button  move “◘” icon to 2. MODE  Normal (flashing)  press “UP” or “DN” to change the conference mode. 0 0 1 N O : 0 0 2 0 0 3 ◘...
  • Page 13: Open Microphone Number Setup

    BXB ELECTRONICS CO., LTD. 3.3 Open Microphone Number Setup 3.3.1 Select “Open- Mic”: ALL Mic/ 1-9 microphones. 3.3.2 Press MODE button  move” ◘” to OPEN - MIC  03 Mic will be flashing press UP or DN to change numbers. N O : 0 0 1 0 0 2...
  • Page 14: Volume Setting

    BXB ELECTRONICS CO., LTD. 3.5 Volume Setting To adjust system volume, please press UP button▲ or Down button▼ on the main control unit, the LCD will be shown as follow: V O I C E 6 0 % ※ When stop pressing buttons for 30 seconds, the system will save the setting automatically and goes back to default page.
  • Page 15: Microphone Description

    BXB ELECTRONICS CO., LTD. Microphone Description Tabletop Chairman Unit - EDC 1011 ○ 1  Talk button(with backlight indication) ○ 2  Chairman Control Button(with backlight indication) ○ 3  Build-in speaker for decentralized sound ○ 4  Built-in socket for DIN type microphone ○...
  • Page 16: Tabletop Delegate Unit - Edc 1012

    BXB ELECTRONICS CO., LTD. Tabletop Delegate Unit - EDC 1012 ○ 1  Talk button(with backlight indication) ○ 2  Build-in speaker for decentralized sound ○ 3  Built-in socket for DIN type microphone ○ 4  Recorder output plug ○...
  • Page 17: Flush-Mounted Chairman Unit - Edc 1021

    BXB ELECTRONICS CO., LTD. Flush-mounted Chairman Unit - EDC 1021 CONFERENCE SYSTEM CONTROL TALK ○ 1  Talk button(with indication LED) ○ 2  Chairman control button(with indication LED) ○ 3  Recorder output plug ○ 4  Earphone output plug and volume control ○...
  • Page 18: Flush-Mounted Delegate Unit - Edc 1022

    BXB ELECTRONICS CO., LTD. Flush-mounted Delegate Unit - EDC 1022 CONFERENCE SYSTEM TALK ○ 1  Talk button(with indication LED) ○ 2  Recorder output plug ○ 3  Earphone output plug and volume control ○ 4  Build-in speaker for decentralized sound ○...
  • Page 19: Flush-Mounted Chairman Unit - Edc 1023

    BXB ELECTRONICS CO., LTD. Flush-mounted Chairman Unit - EDC 1023 CONFERENCE SYSTEM CONTROL TALK ○ 1  Chairman control button(with indication LED) ○ 2  Talk button(with indication LED) ○ 3  Earphone output plug and volume control ○ 4  Recorder output plug ○...
  • Page 20: Flush-Mounted Delegate Unit - Edc 1024

    BXB ELECTRONICS CO., LTD. Flush-mounted Delegate Unit - EDC 1024 CONFERENCE SYSTEM TALK ○ 1  Talk button(with indication LED) ○ 2  Earphone output plug and volume control ○ 3  Recorder output plug ○ 4  Built-in sockets for XLR type microphone ○...
  • Page 21: Edc1051 Main Control Unit Technical Specification

    BXB ELECTRONICS CO., LTD. EDC1051 Main Control Unit Technical Specification TECHNICAL DATA ◎ Frequency response:100HZ~16KHZ ◎ Sensitivity:-60dB ◎ Total Harmonic distortion:≦0.5% ◎ S/N:90dB ◎ Conference microphone connection:D type express port x 3 sets ◎ 5 LED level display ◎ Power:AC110/220,50/60Hz,Power LED light PHYSICAL DATA ◎...
  • Page 22: Microphone Unit Technical Specification

    BXB ELECTRONICS CO., LTD. Microphone Unit Technical Specification Type: Heart type capacitance ◎ Frequency response: 100 Hz~ 16 KHz ◎ Sensitivity: -23 dBv/PaMax. ◎ Sound Voltage: 126 dB (3% THD) ◎ S/N ratio: >20 dB (1 kHz) ◎ Dimensions: 66 mm (2.5inch) ◎...
  • Page 23 BXB ELECTRONICS CO., LTD. BXB ELECTRONICS CO,LTD. http://www.bxb.tw 6F.-1, No.288-5, Xinya Rd., Qianzhen Dist., Kaohsiung City 806, Taiwan (R.O.C.) Post code: 80673 TEL:+886- 7- 970 3838 FAX:+886- 7- 970 3883 E-mail: bxb@bxb.tw 23/23 www.bxb.tw...
