  • Page 1 FCC ID : BEJL3000A APPENDIX G : USER’S MANUAL...
  • Page 2 Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 4: Using The Computer

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Using the Computer Connect the signal cable. When attached, tighten the thumbscrews to secure the connection. Connect the power cord into a proper power outlet that is easily accessible and close to the display.

  • Page 5: Front Panel Controls

    Control Panel Functions Front Panel Controls Bottom Control Function Power Button Use this button to turn the display on or off. Power (DPMS) This Indicator lights up green when the display Indicator operates normally. If the display is in DPM (Energy Saving) mode, this indicator color changes to amber.
  • Page 6 Control Panel Functions Control Direct Access Function • Bring up Contrast and Brightness adjustment. VOLUME: Use these buttons to decrease or increase the volume level. AUTO adjustment function When adjusting your display settings, always press the AUTO/SELECT button before entering the On Screen AUTO IN PROGRESS Display(OSD).

  • Page 7: Screen Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.
  • Page 8 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Using the computer Main menu Sub menu Reference BRIGHTNESS To adjust the brightness and BRIGHTNESS contrast of the screen CONTRAST CONTRAST PRESET 9300K...
  • Page 9 On Screen Display(OSD) Selection and Adjustment Using the VCR/DVD/HDTV Main menu Sub menu Reference CONTRAST ADJUSTMENT To improve the clarity and stability of the screen BRIGHTNESS SHARPNESS COLOR TINT VOLUME To adjust the audio function AUDIO BASS TREBLE MUTE SOUND LANGUAGE To customize the screen status SETUP...
  • Page 10 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. To adjust the screen when using the computer To adjust the brightness and contrast of the screen OSD Adjust...

  • Page 11: To Adjust The Position Of The Screen

    On Screen Display(OSD) Selection and Adjustment To adjust the position of the screen OSD Adjust Description Horizontal Position IMAGE POSITION To move image left and right. R G B Vertical Position To move image up and down. HORIZONTAL VERTICAL To improve the clarity and stability of the screen OSD Adjust Description This function is suitable for analog signal...
  • Page 12 On Screen Display(OSD) Selection and Adjustment To customize the screen status for a user's operating environment OSD Adjust Description LANGUAGE To choose the language in which the SETUP control names are displayed. R G B LANGUAGE ENGLISH FULL IMAGE SIZE This function displays the image in its IMAGE SIZE OSD POSITION...
  • Page 13 On Screen Display(OSD) Selection and Adjustment To adjust the PIP of the screen OSD Adjust Description This PIP (Picture-in-Picture) function allows the image from the HDTV, VCR or DVD to be displayed on a sub- screen while you are using a computer. R G B PIP ON/OFF PIP SOURCE...
  • Page 14 On Screen Display(OSD) Selection and Adjustment To adjust the screen when using the VCR/DVD/HDTV To improve the clarity and stability of the screen OSD Adjust Description To adjust the contrast of the screen. CONTRAST ADJUSTMENT To adjust the brightness of the screen. BRIGHTNESS CONTRAST BRIGHTNESS...
  • Page 15 On Screen Display(OSD) Selection and Adjustment To customize the screen status for a user's operating environment OSD Adjust Description LANGUAGE To choose the language in which the SETUP control names are displayed. ENGLISH LANGUAGE IMAGE SIZE FULL IMAGE SIZE This function displays the image in its OSD POSITION original size or enlarged size so as to fit TRANSPARENCY...

  • Page 16: No Image Appears

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator Press the Power button.

  • Page 17: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is Press the AUTO/SELECT button to incorrect. automatically adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. Check Control Panel -->...

  • Page 18: Have You Installed The Display Driver

    Troubleshooting “IMAGE SIZE” function on OSD menu does not work. “IMAGE SIZE” function Check if the resolution is set as 1280x768 or less on OSD menu does not than 512x360. work? The optimal resolution is 1280x768 and the image is fully displayed on the monitor and is not converted as 1:1 image size.
  • Page 19 Specifications 30 inches (76.2cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating 30 inches viewable 0.5025 x 0.5025 mm pixel pitch Horizontal Freq. Analog:30 - 66kHz (Automatic) Sync Input Digital:30 - 63kHz (Automatic) Vertical Freq. 56 - 85Hz (Automatic) Input Form Separate TTL, Positive/Negative Composite TTL, Positive/Negative SOG (Sync On Green)
  • Page 20 Specifications Operating Conditions Environmental Conditions Temperature 10˚C to 35 ˚C Humidity 10 % to 80 % non-Condensing Storage Conditions Temperature -20˚C to 60 ˚C Humidity 5 % to 95 % non-Condensing Attached( ), Detached ( O ) Signal cable Wall-outlet type or PC-outlet type Power cord Regulations TCO99...

  • Page 21: Display Modes (Resolution)

    Specifications Display Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 640 x 350 31.468 720 x 400 640 x 480 31.469 37.500 VESA 640 x 480 VESA 43.269 640 x 480 VESA 37.879 800 x 600 VESA 800 x 600 46.875...

  • Page 22: Signal Connector Pin Assignment

    Specifications Signal Connector Pin Assignment & " DVI-D Connector Signal(DVI-D) Signal(DVI-D) T. M. D. S. Data2- Hot Plug Detect T. M. D. S. Data2+ T. M. D. S. Data0- T. M. D. S. Data0+ T. M. D. S. Data2/4 Shield T.

  • Page 23: Remote Control

    : SMALL -> LARGE -> OFF PLAY VCR Buttons STOP P/STILL These buttons are available for LG VCR remote controls only. Refer to the Owner’s Manual for your VCR . LIGHT VIEW This function optimizes the brightness, contrast or color value LIGHT VIEW...

  • Page 24: Preparing The Remote Control

    Using the Remote Control Insert the batteries into the remote This section shows you how to use control to operate the monitor. the remote control. Preparing the Remote Operating with the Remote Control Control Open the battery cover. Point the remote control at the remote sensor and press the buttons.
  • Page 25 Connection of external equipment Connecting the VCR/DVD Connect the each audio/video output jack of the VCR/DVD to the corresponding input port as shown on the Display. If you connect the S-Video input port to external equipment, you can have an improved definition image.
  • Page 26 Connection of external equipment Watching HDTV Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect both HDTV cable (Y/Pb/Pr) and audio cable (Audio L/R) to the monitor jack and the Set-top box jack.

  • Page 27: Reference Guide

    Reference Guide for Precaution, Service, Warranty and Diskette Install English Deutsch Français Italiano Español Nederlands Português...
  • Page 28 nglish egulatory Information Important Precautions ..........1 FCC Compliance Statement ........11 DDC (Display Data Channel) ........1 Canadian DOC Notice ..........11 Energy Saving Design ..........2 CE Conformity Notice (for Europe) ......12 Service ................2 Low Radiation Compliance (MPR II)......12 TCO95 ................12 eutsch TCO99 ................13 Wichtige Hinweise ............2 EPA (U.S.A only)............14 DDC (Display Data Channel) ........3...
  • Page 29 English Important Precautions Monitors are provided with ventilation openings in the cabinet to allow the release of heat generated during operation. If these openings are blocked, built-up heat can This unit has been engineered and manufactured to cause failures which may result in a fire hazard. Therefore, assure your personal safety, but improper use can NEVER: result in potential electrical shock or fire hazard.

  • Page 30: Energy Saving Design

    English Deutsch Energy Saving Design Wichtige Hinweise This monitor complies with the EPA's Energy Star program, Bei der Konstruktion bzw. Herstellung dieses Monitors which is a program designed to have manufacturers of wurde insbesondere auf eine höchstmögliche computer equipment build circuitry into their products to Betriebssicherheit geachtet.

  • Page 31: Wartung

    Deutsch Betreiden Sie den Monitor nicht in der Nähe von Wasser Anmerkung (Waschbecken etc.) bzw. in Räumen mit überdurchschnittlich Der PC muß für DDC Funktionen eingerichtet sein. hoher Luftfeuchte. Energieversorgung Die Schlitze im Monitorgehäuse dienen der Belüftung des Geräts. Dieser Monitor entspricht den Richtlinien des EPA Energy Star Diese Öffnungen dürfen auf keinen Fall blockiert oder vedeckt Program.

  • Page 32: Consignes De Sécurité

    Français Consignes de Sécurité pas le moniteur à un endroit où le cordon d’alimentation risque d’être endommagé. Cet appareil a été conçu et fabriqué de façon à vous Ne placez pas le moniteur à proximité d’endroits humides, par garantir une sécurité optimale, mais une utilisation exemple baignoire, lavabo, évier de cuisine, machine à...

  • Page 33: Precauzioni Importanti

    Français Italiano Caractéristique D’économie D’énergie Precauzioni Importanti Ce moniteur a été conçu en conformité avec le programme Questa unità è stata progettata e realizzata per garantire la Energy Star de l’EPA, qui est un programme destiné aux massima sicurezza personale dell'utente, tuttavia un uso fabricants d’équipement informatique, les incitant à...

  • Page 34: Manutenzione

    Italiano Non utilizzare questo monitor in prossimità dell'acqua, per Modello Conforme alla Normativa sul esempio vicino a vasche da bagno, lavandini, lavelli, vasche da Risparmio Energetico bucato, superfici bagnate o vicino a una piscina. La struttura dei monitor è dotata di fessure di ventilazione che Questo monitor è...

  • Page 35: Precauciones Importantes

    Espanõl Precauciones Importantes No use este monitor cerca del agua o cerca de una bañera, lavamanos, fregador de cocina, fregador de ropa o en un sótano húmedo, o cerca de una piscina. Esta unidad ha sido diseñada y fabricada para asegurar su Los monitores tienen ranuras de ventilación en su gabinete para seguridad personal, pero el uso indebido puede resultar en permitir la liberación de calor generada durante su operación.
  • Page 36 Espanõl Nederlands Diseño de Ahorro de Energía Belangrijke voorzorgsmaatregelen Este monitor cumple con el programa EPA'S Energy Star el cual Dit apparaat is zodanig ontworpen en geproduceerd es un programa diseñado para que fabricantes de equipo de dat uw persoonlijke veiligheid is gewaarborgd. Bij computadora fabriquen sistema de circuitos en sus productos onjuist gebruik bestaat er echter gevaar voor para reducir el consumo de energía durante el tiempo que no...
  • Page 37 Nederlands Installeren OPMERKING Dit kan alleen als de PC DDC ondersteunt. Zorg dat er niets op het netsnoer wordt geplaatst of er over heen Energiebesparingssysteem wordt gerold en zet de monitor niet op een plaats waar het netsnoer makkelijk kan worden beschadigd. Deze monitor voldoet aan het Energy Star-programma van EPA.

  • Page 38: Precauções Importantes

    Português Precauções Importantes Os monitores possuem frestas para ventilação. Se estas frestas são bloqueadas, o calor gerado pelo monitor pode causar falhas de funcionamento que podem gerar um Este monitor foi projetado e fabricado de forma a incêndio. Portanto, NUNCA: assegurar a sua segurança pessoal, porém o uso ou Bloqueie as frestas de ventilação colocando o monitor operação inadequada podem resultar em risco...

  • Page 39: Canadian Doc Notice

    Português Regulatory Information Sistema de Gerenciamento de FCC Compliance Statement Energia This equipment has been tested and found to comply within the limits of a Class B digital device pursuant to Part 15 of Este monitor está de acordo com o programa Energy Star the FCC Rules.

  • Page 40: Low Radiation Compliance (Mpr Ii)

    Regulatory Information cont. CE Conformity Notice scheme, which provides for international environmental (for Europe) labelling of personal computers. The labelling scheme was developed as a joint effort by the TCO (The Swedish Products with the “CE” Marking comply with the EMC Confederation of Professional Employees), Directive(89/336/EEC) and LOW VOLTAGE Directive Naturckyddsföreningen (The Swedish Society for Nature...
  • Page 41 Regulatory Information cont. Lead can be found in picture tubes, display screens, solder, TCO99 and capacitors. Lead damages the nervous system and in higher doses causes lead poisoning. The relevant bio- accumulative TCO’95 requirement permits the inclusion of lead, as no replacement has yet been developed. Congratulations! Cadmium is present in rechargeable batteries and in the You have just purchased a TCO’99 approved and labelled...
  • Page 42 Environmental requirements issued by the U.S. Environmental Protection Agency(EPA). Flame retardants As an ENERGY STAR Partner LG Flame retardants are present in printed circuit boards, Electronics U. S. A.,Inc. has cables, wires, casings and housings. Their purpose is to determined that this product meets the prevent, or at least to delay the spread of fire.
  • Page 43 MONITOR LIMITED WARRANTY LG Electronics will repair or at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use, during the warranty period listed below from the date of original purchase. This warranty is good only to the original purchaser of the product during the warranty period as long as it is in the U.S., including Alaska,...
  • Page 44 LCD MONITOR LIMITED WARRANTY LG Electronics, will repair or at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use, during the warranty period listed below from the date of original purchase. This warranty is good only to the original purchaser of the product during the warranty period as long as it is in the U.S., including Alaska, Hawaii, U.S.
  • Page 45 5. No retailer has authority to very the terms of the above within Australia of products purchased in Australia. warranty. 6. LG shall not be liable for the loss of use of product, inconvenience, loss or any other damages, direct or consequential arising out of the use, or the inability to...
  • Page 46 LCD Monitor: TERMO DE GARANTIA TERMO DE GARANTIA A LG Electronics de São Paulo Ltda. garante este produto A LG Electronics de São Paulo Ltda. garante este produto pelo período de 3(três) anos, contados a partir da data de pelo período de 90 dias, mais 2 anos e nove meses contados emissão da Nota Fiscal de compra, desde que o mesmo...
  • Page 47 Garantia Limitada Para México POLIZA DE GARANTIA LG Electronics México, S.A. de C.V. GARANTIZA LOS MONITORES GOLDSTAR/LG POR EL TERMINO DE TRES AÑOS EN TODAS SUS PARTES Y MANO DE OBRA, CONTRA CUALQUIER DEFECTO DE FABRICACION A PARTIR DE LA FECHA DE ENTREGA DEL PRODUCTO BAJO LAS SIGUIENTES...
  • Page 48 Centro de Servicio Autorizado de Línea Electrónica RAC: Centro de Servicio Autorizado de Aire Acondicionado Centro de Servicio Autorizado de Multimedia IRAC: Instalador de Aire Acondicionado Acceso directo a la página de Internet de LG: Consumidores: http://mx.lgservice.com/ ASC: http://biz.lgservice.com/ Servicio Directo LG...
  • Page 49 The Backlight in these units is warranted for 1 year only. Replacements are 01475 744788 chargeable 6) LG Electronics reserves the right to collect repairs and Ireland 0044 1475 744788 return any monitor which has cabinet defilement, including security marking.

  • Page 50: Monitor Driver Installation

    Have Disk. ⑤ Insert the Monitor Installation Diskette into the floppy drive and click OK. ⑥ Under Model list, select your LG Monitor, then click OK. The monitor files are copied to the hard drive. ⑦ Click OK Close to save the settings.
  • Page 51 U.S. and Canada only: website: http://www.LGEservice.com e-mail: http://www.LGEservice.com/techsup.html Brazil only: LG Electronics de São Paulo LTDA. C.G.C. NO. : 011666 372/0001-55 AV. D. Pedro 1, W-7777, Jardim Silvia Maria, Taubate-SP Mexico only: LG Electronics México S.A. de C.V. Sor Juana Inés de la Cruz No. 555 Col. San Lorenzo Tlalnepantla, Edo.
