LED States and Their Meaning

No LEDs Drive locked, power switch is off, device unplugged
Blinking RED Error / incorrect button entry; Mode Not Available;
User PIN Change
RED
Solid Locked / Standby state; Awaiting PIN entry
Blinking GREEN Button-entry accepted
Solid BLUE / Waiting for New User or Admin PIN to be
Blinking GREEN established
Solid BLUE

Admin Mode

Solid GREEN Drive unlocked
Slow Blinking BLUE Drive unlocked in Lock-Override Mode
Solid GREEN / Drive unlocked in Read-Only Mode
Slow Blinking RED
Alternating Indicates a mode has been entered that can result
RED BLUE
/ in the deletion of a User or the data on the drive
(depending on the mode chosen.)
Also used when setting Auto-lock feature
One second of RED Self-test mode to ensure all components are ready
followed by one and working properly
second of GREEN
followed by one
second of BLUE
Three Seconds of During Reset Process, indicates successful
Solid RED / GREEN resetting of cryptographic security parameters

Locking the Drive

To lock the drive, press the button. When successfully locked, The
steadily, indicating that it's returned to its standby state.
If data is still being written to the drive, the Fortress will wait until all data has been written to
the drive and then it will lock automatically.
Note: The Aegis Fortress will not be recognized by any operating system in its standby state.

Unlocking the Drive

Enter either a User PIN or Admin PIN and press the
GREEN LED will blink three times, then will rapidly blink for a short time, followed by steady
glowing, indicating that it's now unlocked and ready for use. If the PIN is incorrect, the
LED will blink.
Admin Mode
To set up any of the drive's Admin functions and features, the Admin mode must first be
entered. Once in the Admin mode, each of the drive's functions can be addressed with the
appropriate button commands. Also note that while in the Admin mode, the actual data on
the drive will not be accessible.
To return to the Admin mode for future setups, perform the following steps below.
1. Press and hold + 0 for five seconds until the
(This indicates that the drive is prepared to accept the correct Admin PIN.)
2. Enter the Admin PIN and press the
3. Successfully entering the Admin Mode is indicated by a solid
4. To exit the Admin Mode, either allow 30 seconds of inactivity or press the

Changing the Admin PIN

Changes to the Admin PIN can only be made while the drive is in the Admin mode.
1. Enter the Admin mode. (Hold
the Admin PIN and press the
2. Press UNLOCK + 9. The
3. Enter the new Admin PIN and press the
three times.
4. Re-enter the new Admin PIN and press the
for two seconds and then return to the Admin mode, indicated by the
steadily.
8
RED
button. If the PIN is accepted, the
RED LED blinks.
button.
BLUE
+ 0 for five seconds – with the RED
button.) The BLUE LED will glow steadily.
BLUE LED will glow steadily and the GREEN
GREEN
button. The LED will blink
button. The GREEN
LED will glow
RED
LED.
button.
LED blinking, enter
LED will blink.
LED will glow steadily
BLUE LED glowing
