STEP 5
Assure that the unit is square. Distance from corner to corner must be equal as shown.
Flush the bottom edge of the back panel (G) with the bottom edge of the bottom (C).
Attach the back panel as shown nailing straight into the raw edges.
systembuild.com
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT
AND MUST BE INSTALLED PROPERLY.
(x28)
#A21110
A
C
11
* raw surface is shaded
