- Page 1 EM Series Gesture Model 7”Wide Windows CE Embedded Panel Computer EMG7 EMG7-W207A8-0024-x11-01 Instruction Manual Seedsware Corporation http://www.seedsware.co.jp/global 12A4A4-00023E-5...
-
Page 2: Table Of Contents
Table of Contents Introduction ............................4 Notes ..............................4 Precautions for safe use ........................4 3-1 Warnings ............................5 3-2 Cautions ............................6 3-3 Handling of LCDs ..........................8 3-4 Handling of Touch Screens ......................8 3-5 Handling of SD card ......................... 9 3-6 Handling of Batteries ........................ - Page 3 Connecting and Changing of Batteries .................... 26 11-1 Battery Connecting and Changing Procedure ................26 Applying Protection Sheet ....................... 28 12-1 Application Procedure ........................28 Calibration ............................29 13-1 Sensor Sensitivity Calibration ....................... 29 13-1-1 Sensor Sensitivity Calibration Procedure (by switch)............. 29 13-2 Coordinate Calibration ........................
-
Page 4: Introduction
Seedsware shall not be held liable in any way for damages or losses, nor be held responsible for any claims by a third party as a result of using this product. -
Page 5: Warnings
EMG7. It can cause human injuries and/or property damages. Do not use EMG7 as a major warning device that may cause injuries/serious material damages, and or production stoppage. Control devices related to critical warning displays and warnings should be structured on an independent, redundant hardware system or a mechanical interlock. -
Page 6: Cautions
Make sure cables are securely connected to connectors to avoid wrong input and output due to loose connection. Cautions for Applying Current and Maintenance During access to SD card, do not turn off the EMG7 or pull out the SD card. It might damage the data inside of the SD card. Cautions for Wiring Use D type grounding dedicated to EMG7 for FG terminals. - Page 7 Precautions for Safe Use Do not press down hard on the display area of EMG7 with hard objects. It may break the LCD panel and may cause injuries. Also, do not press down on the panel with sharp objects such as mechanical pencils or drivers.
-
Page 8: Handling Of Lcds
3-3 Handling of LCDs The LCD display contains skin-irritating materials. If liquid materials flow out due to damage and comes in contact with skin, wash the area under running water for at least 15 minutes and consult a doctor. The LCD display might have uneven brightness according to the contents being displayed. This is not a malfunction. -
Page 9: Handling Of Sd Card
3-5 Handling of SD card Use a computer for important data and take backup to an outside media (hard disc, CD-R, etc.) regularly. We will not be held liable for any data lost or changed that is registered in the SD card. Do not remove the SD card or turn the unit power off during write or read. -
Page 10: Items Included In Package
*1. 1 English version and 1 Japanese version. ＜Note＞ Although efforts have been made to ensure quality and packaging at shipment, should you notice any damage or a shortage of parts, please contact a dealer or Seedsware for additional instructions before use. -10- 12A4A4-00023E-5... -
Page 11: Names Of Parts
Names of Parts 5-1 Front Status LED The status LED displays the state of the EMG by the LED color shown below: LED State EMG State Power not applied Amber, steady OS starting Green, steady Normal operating state Backlight off Green, blinking (Normal Operation) 5-2 Back... -
Page 12: Right
5-3 Right SD Card Slot USB Device Audio Interface (LINE OUT) Audio Interface (MIC IN) 5-4 Top Mounting Holes 5-5 Bottom Power Input Ethernet USB Host Serial Port（COM1） Mounting Holes -12- 12A4A4-00023E-5... -
Page 13: External Interface
External Interface 6-1 SD Card Slot Connector : SD / SDHC memory card (Push-in/push-out method) Corresponding media : SD/SDHC memory card Maximum capacity : 32GB 6-2 Serial Port (COM1) Serial port : RS232C Connector : Euro terminal connector (<Tyco Electronics> 284539-5) Recommended cable connector : SWCN-01-05(<Tyco Electronics>284510-5) *Included as accessory. -
Page 14: Usb Host Port
6-4 USB Host Port Interface : USB2.0 Number of Ports Connector : Type-A Maximum supply current: 0.5A / Port PIN No. Signal Schematic (All ports common) USB_VCC 6-5 USB Device Port Interface : USB2.0 Connector : Type-B Mini connector PIN No. Signal Schematic USB_VCC... -
Page 15: Audio Interface (Line Out)
6-6 Audio Interface (LINE OUT) Interface : LINE OUT (Stereo) : φ3.5 Stereo JACK Connector Maximum output level : 1Vrms Use built-in amplifier when connecting to speakers. PIN No. Signal Schematic Lineout R Lineout L 6-7 Audio Interface (MIC IN) Interface : MIC IN (Mono) : φ3.5 Stereo JACK... -
Page 16: Specification
FG (Frame GND) and SG (Signal GND) are connected internally. FG (Frame GND) and GND are not connected. ※1 Power consumption for EMG7 unit only. Consider the power consumption of USB devices when connecting the USB. 7-2 Environmental Specification Item... -
Page 17: Installation Specification
Please check the installation environment prior to the use of EMG7. Also, gaskets that have been used for a long time, or gaskets that have once been applied to panels, the original level of the protection cannot be guaranteed. -
Page 18: Installation
Inside Cabinet Panel surface ・EMG7 should not be mounted at an angle more than 30° from vertical state as illustrated in the following figure. 30°or less ・When installing the EMG7 in a slanted panel of angle 30 degrees or more, please use forced air cooling to... -
Page 19: Panel Mounting
8-2 Panel Mounting 8-2-1 Panel Dimension Panel thickness range: 1.0 ㎜ to 5.0 ㎜ Panel opening size：183.5×128.5mm 183.5 + 0 . 5 4-R3以 下 Under 4-R3 The material of the mounting panel, please use the metal. Be recommended panel thickness range, depending on material and size, may not maintain the strength when an impact is applied. -
Page 20: Installation Procedure
8-2-3 Installation Procedure ① Install unit (with gasket installed) to the panel from the front. *Make sure it is installed in the correct direction ② Insert mounting hook in the mounting holes in the four locations of the unit. Mounting holes Bottom Panel Mounting Bracket... -
Page 21: Mounting To A "Vesa" Arm
VESA is an abbreviation for “Video Electronics Standards Association”, an industry group that establishes standards concerning displays for computers. VESA establishes SVGA standards and VL Bus standards, and standardized below 2 types for the installation of LCD monitors. ●75mm×75mm pitch ●100mm×100mm pitch EMG7 complies with the VESA standard for75mm. -21- 12A4A4-00023E-5... -
Page 22: Wiring
Wiring Make sure power is not supplied when connecting to avoid the risk of human injury or damage to equipment due to electrocution. Do not turn the power on unitl all connections have been made. When connecting each interface, review each interface specifications. Prepare the cables to be used according to the specifications. -
Page 23: Cautions For Power Supply Wiring
9-2 Cautions for Power Supply Wiring (1) Wire the power source, input/output device, and power device of the EMG7 isolating each by sequence. (2) Do not bundle main circuit (High voltage, high current) wires, signal wires, and power cables, nor put them close to each other. -
Page 24: Inserting And Removing The Sd Memory Card
Inserting and Removing the SD Memory Card 10-1 Inserting the Memory Card (1) Insert the Memory card in the SD card slot on the right side of the unit. ※Make sure the SD memory card is inserted in the correct orientation. Connection terminal should come to the front when inserting. -
Page 25: Removing The Sd Memory Card
10-2 Removing the SD Memory Card (1) SD memory card will slightly pop out when pushed further into the slot. (2) Pinch and pull out the SD memory card. Note: ・Be sure to insert the SD memory card in the correct direction and do not insert in the wrong direction. ・Be sure to take back-up data of the SD memory assuming unexpected accidents. -
Page 26: Connecting And Changing Of Batteries
Connecting and Changing of Batteries SRAM, RTC can be backed up by connecting the battery. Batteries are not connected at purchase. If you need back-up, please connect the attached battery 11-1 Battery Connecting and Changing Procedure (1) Remove the battery cover by pushing down on the concave area and sliding outward. (2) Connect the harness of the battery as shown in the diagram. - Page 27 ・Please be careful of how the used batteries are handled. ・We will not be held liable for any data lost at battery exchange Please be sure to take SRAM data backup. ・Replace the battery with Seedsware part number SWBT-01. -27- 12A4A4-00023E-5...
-
Page 28: Applying Protection Sheet
Applying Protection Sheet 12-1 Application Procedure Apply the protection sheet accordingly to the exterior shape of the glass on the side to be applied. (1) Wipe any dust and fingerprints off the display side (side to be applied). (2) Peel part of the transparent back paper (about 2cm) off the protection sheet so adhesive area is visible. (3) Apply adhesive area on the display side (side to be applied) (4) Apply the whole protection sheet by peeling off the back paper little by little. -
Page 29: Calibration
Calibration There are two types of calibration to EMG7. One type is sensor sensitivity calibration to optimize the touch screen function by resetting the influence of ambient noise or metals of the installation environment, and the other is to set the value of coordinate with the pressed point. -
Page 30: Coordinate Calibration
(3) Once calibration starts, below window will appear. Do not touch the product until calibration ends normally. After a while calibration will end automatically. (4) After calibration ends, reboot and make sure the touch screen can be operated correctly. If it does not operate normally, go through the calibration process again. (5) Make sure the harness does not get caught when putting the battery cover back on. -
Page 31: Starting Method
(2) Mounting brackets are installed firmly without any looseness. 15-3 Changing of Batteries EMG7 has built in battery for back up of SRAM and clock data. If back-up battery needs to be exchanged, please return it to Seedsware or follow the instructions specified in this manual. -31-... -
Page 32: Compatible Standards
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user is required to correct the interference at their own expense. Changes or modifications to this unit that are not expressly approved by Seedsware could void the user’s authority to operate the equipment. -
Page 33: List Of Option
List of Option ■ Mounting brackets Model Description IS-TK-01 4pcs ■ Gasket Model Description SWPK-7W-01 1 pc ■ Protection sheet Model Description SWCA-7WS00-001 Package of 3pcs ■ Batteries Model Description SWBT-01 1 pc ■ Connector Model Description SWCN-01-03 Power connector 3Pin 1 pcs SWCN-01-05 Serial (COM1) 5Pin 1 pcs -33-... -
Page 34: Warranty And Repair
18-4 Repair Condition Only Seedsware products can be repaired. Options are exempt. Programs and data might be lost during repair. Please be sure to take back-up. Seedsware will not be held liable for any programs or data lost during repair. -
Page 35: Others
By Phone +1-630-832-0438 (Business Hours: 9:00a.m. ~5:45p.m. CT) By E-mail sales@uscoamerica.com www.seedsware.co.jp/global/support/faq/ Microsoft® 、 Windows® Embedded Compact7 is a registered trademark of Microsoft Corporation of the United States and other countries. Edition October 2016 USCO America Inc. 136 W. Valletts Street, Elmhurst, IL 60126 USA Phone: 630-832-0438/510-931-9046 E-mail: sales@uscoamerica.com... - Page 36 検 図 製 図 設 計 CAD FILE NAME RoHS compliant USBﾎｽﾄｲﾝﾀﾌｪｰｽ APPROVED CHECKED DRAWN DESIGNED ﾈｯﾄﾜｰｸｲﾝﾀﾌｪｰｽ USB host port Ethernet 製品名 EMG7-W207A8-0024-*1*-01 単 位 MODEL UNIT NOTES 図 名 ﾍﾟｰｼﾞ OUTLINE 1 /1 TITLE PAGE H.Tsuji 1. 指示なき寸法公差は一般寸法公差とする。 T.Okada S.Yoshimoto...
