- Page 1 TM Model “G” Gesture Model Touch Screen Monitor TMG Series Instruction Manual 10.4” TMG-310-DC00-01 12.1” TMG-312-DC00-01 Seedsware Corporation http://www.seedsware.co.jp/global/ 16A4A4-00007E-1...
- Page 2 ■ Seedsware shall not be held liable in any way for damages or losses, nor be held responsible for any claims by a third party as a result of using this product. ■...
- Page 3 Warnings Warnings for Design Designing switches that might cause human injuries and/or property damage on the touchscreen is strictly prohibited. Unintentional output signals due to malfunction of the main body, units, and/or cables can cause serious injuries. Design the system so that switches with major functions are equipped on devices other than the TM itself.
- Page 4 Cautions Cautions for Disposal When disposing the product, please treat is as industrial waste. Precautions for Safe Use Do not press the display with strong pressure or hard objects. It may break the LCD panel and cause injuries. Please use this product within the specified ambient temperature and humidity range. If not used properly, it may cause malfunctions.
- Page 5 Handling of LCDs The LCD display contains skin-irritating materials. If liquid materials flow out due to damage and comes in contact with skin, wash the area under water for at least 15 minutes and consult a doctor. The LCD display might have uneven brightness according to the contents being displayed. This is not a malfunction.
-
Page 6: Table Of Contents
Table of Contents Features ........................1 Features ............................. 2 Product Configuration ....................3 Standard Accessories ......................... 4 Names and Functions of Each Parts ................... 5 Panel Installation ........................6 Installing to Stands ........................9 Wiring ............................10 Operations ..........................13 OSD .......................... 14 OSD Menu ..........................15 OSD Menu Operation ........................16 Touch Screen Setting Tool .................. -
Page 7: Features
Features Chapter Contents Features ....................2... -
Page 8: Features
Features n 2 Signal input interfaces ・DVI Interface (DVI connector) ・Analog RGB Interface (D-Sub15 pin (mini) connector) n DC power input (12V/24V) compliant n USB (Type B) for the touch screen interface n Long life for industrial equipment/ high luminance LCD n Projected capacitive touch screen as standard ・2 point touch complaint ■... -
Page 9: Product Configuration
Product Configuration Chapter Contents Standard Accessories ................4 Names and Functions of Each Parts ............5 Panel Installation ................... 6 Installing to Stands ................9 Wiring ....................10 Operations ..................13... -
Page 10: Standard Accessories
Standard Accessories ・Accessory list ・Installation Guide 2pc ・Mounting Bracket 1set (4pcs) ・Power Connector 1pc ・Gasket 1pc (preinstalled to unit) -
Page 11: Names And Functions Of Each Parts
Names and Functions of Each Parts ⑩ ⑩ ② ③ ① ⑩ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ Displays power and input signal status Green: Power is ON with input signal ① Power indicator Red: Power is ON without input signal Unlit: Power not applied ②... -
Page 12: Panel Installation
Panel Installation Design referring to the panel opening measurement specified in product specification and the outline diagrams. Make sure power is not applied when installing Make sure the unit is not deformed or contorted when installing. Any contortion or deformation may result in insufficient protection. - Page 13 ■ TM should be installed perpendicular. When installing in an angle, angle shall be no more than 30°. Tilt of 30°or less ■ When installing the TM in a slanted panel in an angle of more than 30 degrees, use forced air cooling and design so that the monitor display area is within the specified operation temperature.
- Page 14 Tighten screw of mounting bracket and slide the bracket. Tighten the screw a little at a time in four locations working diagonally. Appropriate torque for tightening varies depending on the model. Please refer to below chart. Model Appropriate torque TMG-310-DC00-01 0.7N･m TMG-312-DC00-01 1.0～1.2N･m Note ・...
-
Page 15: Installing To Stands
Installing to Stands Installing to “VESA Standard” Arms 2.4.1 TM can be installed to a commercially available Video Electronics Standards Association (VESA) arm. If a stand is used, it must meet the UL1678 standard. Refer to manual of arm or stand for installation procedures. Mounting hole dimension is as below VESA Standard 100mm×100mm Use M4 screws and tighten with torque of 0.7 to 0.8N･m. -
Page 16: Wiring
Wiring Be sure no power is applied when making connections to avoid the risk of human injury or damage to equipment due to electrocution. Do not turn the power on until all connections have been made. Prepare the cables to be used according to the specifications. 2.5.1 Connecting Input Power ■... - Page 17 ■ Cautions for Power Supply Wiring (1) Wire the power source, input/output device, and power device of the TM isolating each by sequence. (2) Do not bundle main circuit (High voltage, high current) wires, signal wires, and power cables, nor put them close to each other. (3) Twist the power cable as short as possible to improve noise immunity.
- Page 18 2.5.2 Wiring Procedure Make sure all powers are off and there is no electricity flow to either the TM or the computer. Connect the TM and the computer as the following diagram. Please connect to the power source last. Install the Ferrite Core to the cable if noise measures are necessary. Computer USB Cable Analog RGB Cable...
-
Page 19: Operations
Operations The dial switch on the back side of the TM can be used to operate the OSD （On Screen Display） and turn the power ON or OFF. Press Turn 2.6.1 POWER ON/OFF Press switch to turn on the monitor. Press and hold the switch for more than two seconds to turn the power off. -
Page 20: Osd
Various configurations and adjustments can be made with the OSD (On Screen Display). OSD is operated with a dial switch. The value set will be retained and will not be deleted when power is shut down and until setting is changed intentionally. Chapter Contents OSD Menu .................. -
Page 21: Osd Menu
OSD Menu Top menu icons Adjustment Main Menu Submenu Initial Value Description range 0 ～ 100 Brightness Adjust brightness of display PICTURE 0 ～ 100 Contrast Adjust contrast of display 0 ～ 4 Sharpness Adjust sharpness of display Exit Go back to main menu Auto Adjustment Automatically adjust DISPLAY items DISPLAY... -
Page 22: Osd Menu Operation
OSD Menu Operation 3.2.1 Basic Functions Displaying the OSD Press the dial switch to display the main menu of the OSD. (No actions will be performed by turning the dial switch without displaying the OSD) Selecting with the OSD Choose the item (icon) on the OSD by turning the dial switch while OSD is displayed. The item in yellow is the item in the selected state. - Page 23 3.2.3 Adjusting Brightness 1) Open the OSD menu. 2) Select [Picture] > [Brightness]. 3) Turn the dial switch to adjust the “Bar Meter” value. (The screen brightness will change with the turn of the dial.) 4) Press the dial switch to determine the brightness you desire. 5) End OSD.
-
Page 24: Touch Screen Setting Tool
Touch Screen Setting Tool Download the “Touch Screen Setting Tool (DMT-DD)” via our website: http://www.seedsware.co.jp/support/download/ Chapter Contents System Requirements ................. 19 Installing ..................... 20 Setting ....................24 Sensor Calibration ................26... -
Page 25: System Requirements
System Requirements 4.1.1 System Configuration Supporting OS： Windows 7 (32bit/64bit) Windows 8/8.1 (32bit/64bit) Windows 10 (32bit/64bit) Note: 2 point touch and gesture operations are possible with the Windows 7/8/8.1/10. 4.1.2 Installment Requirements n Software .Net Framework3.5 must be preinstalled. n Hard Disc There must be 10MB of free space and data file storing capacity in the system drive. -
Page 26: Installing Procedures
Installing Procedures Instaling the “Touch Screen Setting Tool” 4.2.1 1) Unzip the driver compressed file downloaded to the computer to be used. 2) Double click the “DMT-DDSetup.msi”. 3) Set up Wizard will start. Click [NEXT] and start the installation. Read the License Agreement and select [I Agree] and click [Next]. - Page 27 4) You may see a message dialog as below several times during the installation. Click [Install] or [Continue Anyway]. For Windows 7/8/10 For Windows XP...
- Page 28 5) Click [Close] and your installation is complete. 4.2.2 Installing the Touch Screen Driver 1) Connect the TM and the computer with an USB cable. 2) Click [DMT-DD] short cut and start the “Touch Screen Setting Tool”. ・ For Windows 7/8/10 You will need the administrative privilege when installing the driver of the Setting Tool.
- Page 29 5) Click [OK] and reboot your computer. 6) After rebooting your computer, star the “DMT-DD” If “USB Port” is replaced with “TP Driver”, then installation has completed successfully.
-
Page 30: Setting
Setting 4.3.1 Single Touch Setting file will not be registered in the initial value and will be touch output. If you will be using Windows XP or single touch, follow the below procedures to set the “Mouse Output” 1) Startup the “Touch Screen Setting Tool”. 2) Click and open [Basic Setting] >... - Page 31 4.3.3 Multi-monitor Setting When using the mouse output (single touch) in a multi-monitor environment, you will need to execute the below function. 1) Startup the “Touch Screen Setting Tool”. 2) Click [Device Addition] >[Monitor Configuration] 3) When using multiple monitors, a screen as below will be displayed from the far left monitor. Touch the touch screen on this monitor twice.
-
Page 32: Sensor Calibration
Sensor Calibration Due to the characteristics of the touch screen, its functions might become unstable according to the environment it is installed. For correct operations, perform sensitivity sensor calibration when building into a device. 4.4.1 Touch Screen Maintenance The selected driver or the touch screen controller can be maintnanced by below procedure. Startup the “Touch Screen Setting Tool”. -
Page 33: Maintenance
Maintenance Chapter Contents Maintenance ..................28... -
Page 34: Maintenance
Maintenance 5.1.1 Display If the display surface or the frame gets dirty, wipe with a soft cloth damped in mild detergent than wrung dry. Use of thinner, organic solvents, strong acidic detergents are prohibited. 5.1.2 Periodic Check To keep the product in its best condition, check periodically for below points. □... -
Page 35: Troubleshooting
Troubleshooting If problems still remain and cannot be solved, contact your dealer or refer “7.3 Inquiries” and contact us. Chapter Contents Display ....................30 Touch Screen ..................31... -
Page 36: Display
Display Symptoms Cause/Measures ・ Make sure the power cord is inserted securely. ・ No display (LED will not light) ・ Press the dial switch and turn ON the power of the TM. ・ Check that the image signal cable is inserted properly. ・... -
Page 37: Touch Screen
Touch Screen Symptoms Cause and Measures • Remove then insert again the USB Cable that connects to the computer. • • Cursor position is not correct Make sure that the FG (Frame GND) of the TM and the FG • Cursor jumps (Field GND) of the powers are connected. -
Page 38: Others
Others Chapter Contents Warranty and Repair................33 Production Discontinuance ..............34 Inquiries ....................35... -
Page 39: Warranty And Repair
(1) Only Seedsware products can be repaired. Options are exempt. (2) Repairs will be done in our workshop after it is sent back. All shipping fee will be charged. (3) Seedsware will have all ownership for parts exchanged at repair. 7.1.3 Inquireies for Repair If you have any inquiries concerning defects or repairs of our products, feel free to contact us. -
Page 40: Production Discontinuance
Production Discontinuance In the event of production discontinuance, an announcement will be made on our website six months prior to the last possible order reception date. -
Page 41: Inquiries
E-mail: sales@uscoamerica.com Business hours: 9:00a.m. to 5:45p.m. (Central Time) http://uscoamerica.com/ This document is protected by copyright law. Photocopying, duplicating, reproducing, and modifying of this product or document in part or by whole is prohibited. Copyright(C) 2016 Seedsware Corporation. All Rights Reserved...
