Compact Reach Xtend
Zigbee®, 802.11 b/g/n WLAN
Fractus Antennas specializes in enabling effective mobile communications. Using Fractus
technology, we design and manufacture optimized antennas to make your wireless devices
more competitive. Our mission is to help our clients develop innovative products and accelerate
their time to market through our expertise in antenna design, testing and manufacturing.
Compact Reach Xtend
FR05-S1-N-0-102
Compact Reach Xtend
TM
(FR05-S1-N-0-102) –
TM
Last updated on June 2017
(FR05-S1-N-0-102)
TM
Some Fractus Antennas products are
protected by
Fractus
patents.
All
information
contained
document is property of Fractus Antennas
and is subject to change without prior
notice. Information is provided "as is" and
without warranties. It is prohibited to copy
or reproduce this information without prior
approval.
Fractus Antennas is an ISO 9001:2008
certified company. All our antennas are
lead-free and RoHS compliant.
USER MANUAL
Bluetooth®,
within
this
1
© 2016 FRACTUS ANTENNAS, S.L. -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Compact Reach Xtend FR05-S1-N-0-102 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fractus Antennas Compact Reach Xtend FR05-S1-N-0-102

  • Page 1 Bluetooth®, Zigbee®, 802.11 b/g/n WLAN Fractus Antennas specializes in enabling effective mobile communications. Using Fractus technology, we design and manufacture optimized antennas to make your wireless devices more competitive. Our mission is to help our clients develop innovative products and accelerate their time to market through our expertise in antenna design, testing and manufacturing.
  • Page 2: Table Of Contents

    INDEX OF CHAPTERS ANTENNA DESCRIPTION ....................4 QUICK REFERENCE GUIDE ..................... 4 ELECTRICAL PERFORMANCE ..................6 MECHANICAL CHARACTERISTICS .................. 9 MATCHING NETWORK ....................10 ASSEMBLY PROCESS ....................11 PACKAGING ........................13 Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
  • Page 3 4.1. DIMENSIONS AND TOLERANCES ................9 4.2. SPECIFICATIONS FOR THE INK ................9 4.3. ANTENNA FOOTPRINT ................... 10 MATCHING NETWORK ....................10 ASSEMBLY PROCESS ....................11 PACKAGING ........................13 Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
  • Page 4: Antenna Description

    Dimensions (L x W x H) 7.0 mm x 3.0 mm x 2.0 mm Table 1 – Technical Features. Measures from the evaluation. See Figure 1 and picture on page 6. Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
  • Page 5 USER MANUAL Compact Reach Xtend (FR05-S1-N-0-102) Please contact info@fractusantennas.com if you require additional information on antenna integration or optimization on your PCB. Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
  • Page 6: Electrical Performance

    Figure 1 – Compact Reach Xtend Evaluation Board. 3.2. VSWR AND EFFICIENCY VSWR (Voltage Standing Wave Ratio) and Total Efficiency versus Frequency (GHz). Figure 2 – VSWR and Efficiency (%) vs. Frequency (GHz). Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
  • Page 7: Radiation Patterns, Gain And Efficiency

    Efficiency Range across the band (min, max) Table 2 – Antenna Gain and Efficiency within the 2.4 – 2.5 GHz band. Measures made in the evaluation board and in the Satimo STARGATE 32 anechoic chamber. Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
  • Page 8: Capabilities And Measurement Systems

    3.4. CAPABILITIES AND MEASUREMENT SYSTEMS Fractus Antennas specializes in the design and manufacture of optimized antennas for wireless applications, and with the provision of RF expertise to a wide range of clients. We offer turn-key antenna products and antenna integration support to minimize your time requirements and maximize return on investment throughout the product development process.
  • Page 9: Mechanical Characteristics

    (RoHS). The RoHS certificate can be downloaded from www.fractusantennas.com. 4.2. SPECIFICATIONS FOR THE INK Next figure shows the correct colors of the antenna: Acceptable color range Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
  • Page 10: Matching Network

    MATCHING NETWORK The specs of a Fractus Antennas standard antenna are measured in their evaluation board, which is an ideal case. In a real design, components nearby the antenna, LCD’s, batteries, covers, connectors, etc affect the antenna performance. This is the reason why it is highly recommended placing pads compatible with 0402 and 0603 SMD components for a PI matching network as close as possible to the antenna feeding point.
  • Page 11: Assembly Process

    12. 3. After soldering the antenna to the circuit board, perform a cleaning process to remove any residual flux. Fractus Antennas recommends conducting a visual inspection after the cleaning process to verify that all reflux has been removed.
  • Page 12 8 minutes max Table 3 – Recommended soldering temperatures. Next graphic shows temperature profile (grey zone) for the antenna assembly process in reflow ovens. Figure 7 – Temperature profile. Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
  • Page 13: Packaging

    Figure 9 – Images of the tape. Measure A max 330.0 ± 1.0 17.5 ± 0.2 t max 21.5 ± 0.2 Reel Capacity: 2500 antennas Figure 10 – Reel Dimensions and Capacity. Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
