Fractus Antennas ALL mXTENDTM FR01-S4-220 User Manual

Chip antenna component

Advertisement

Quick Links

ALL mXTEND
TM
mobile frequency bands
Fractus Antennas specializes in enabling effective mobile communications. Using Fractus
Antennas technology, we design and manufacture optimized antennas to make your wireless
devices more competitive. Our mission is to help our clients develop innovative products and
accelerate their time to market through our expertise in antenna design, testing and
manufacturing.
TM
ALL mXTEND
chip antenna
component
FR01-S4-220
(FR01-S4-220) –
Last updated on June 2017
ALL mXTEND
A standard antenna solution for
Some Fractus Antennas products are
protected by
Fractus Antennas
All
information
contained
document is property of Fractus Antennas
and is subject to change without prior
notice. Information is provided "as is" and
without warranties. It is prohibited to copy
or reproduce this information without prior
approval.
Fractus Antennas is an ISO 9001:2008
certified company. All our antennas are
lead-free and RoHS compliant.
USER MANUAL
(FR01-S4-220)
TM
patents.
within
this
1
© 2017 FRACTUS ANTENNAS, S.L. -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALL mXTENDTM FR01-S4-220 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fractus Antennas ALL mXTENDTM FR01-S4-220

  • Page 1 A standard antenna solution for mobile frequency bands Fractus Antennas specializes in enabling effective mobile communications. Using Fractus Antennas technology, we design and manufacture optimized antennas to make your wireless devices more competitive. Our mission is to help our clients develop innovative products and accelerate their time to market through our expertise in antenna design, testing and manufacturing.
  • Page 2: Table Of Contents

    PRODUCT DESCRIPTION FR01-S4-220 ................4 EVALUATION BOARDS 1 PORT (698-960MHz and 1710-2690MHz) ........ 5 CAPABILITIES AND MEASUREMENT SYSTEMS ............10 MECHANICAL CHARACTERISTICS FR01-S4-220............11 ASSEMBLY PROCESS ....................13 PACKAGING ........................15 Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 3 DIMENSIONS, TOLERANCES, AND RoHS ............. 11 4.2. COLOR RANGE FOR THE INK ................11 4.3. RECOMMENDED FOOTPRINT FOR THE FR01-S4-220 ......... 12 ASSEMBLY PROCESS ....................13 PACKAGING ........................15 Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 4: Product Description Fr01-S4-220

    This project has received funding from the European Union’s Horizon 2020 research and innovation programme under grant agreement Nº 674491 Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 5: Evaluation Boards 1 Port (698-960Mhz And 1710-2690Mhz)

    PAT. US 9,130,259 B2; PAT. US 8,237,615 B2; and other domestic and international patents pending. Additional information about patents related to this product is available at www.fractusantennas.com/virtual-antenna/. Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 6 (FR01-S4-220) 2.2.1. MATCHING NETWORK The specs of a Fractus Antennas standard product are measured in their Evaluation Board, which is an ideal case. In a real design, components nearby the antenna, LCD’s, batteries, covers, connectors, etc. affect the antenna performance. This is the reason why it is highly recommended placing pads compatible with 0402 and 0603 SMD components for a matching network as close as possible to the feeding point.
  • Page 7 Figure 3 – VSWR and Total Efficiency for the 698 – 960 MHz frequency range and for the 1710 – 2690 MHz frequency range (from the Evaluation Board) (Figure 1). Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 8 Table 2 – Antenna Gain and Total Efficiency from the Evaluation Board (Figure 1) within the 698 – 960 MHz frequency range. Measures made in the Satimo STARGATE 32 anechoic chamber. Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 9 Table 3 – Antenna Gain and Total Efficiency for the Evaluation Board (Figure 1) within the 1710 2690 MHz frequency range. Measures made in the Satimo STARGATE 32 anechoic chamber. Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 10: Capabilities And Measurement Systems

    (FR01-S4-220) CAPABILITIES AND MEASUREMENT SYSTEMS Fractus Antennas specializes in designing and manufacturing optimized antennas for wireless applications and providing our clients with RF expertise. We offer turn-key antenna products and antenna integration support to minimize your time requirement and maximize your return on investment during your product development efforts.
  • Page 11: Mechanical Characteristics Fr01-S4-220

    (RoHS). For more information, please contact info@fractusantennas.com. 4.2. COLOR RANGE FOR THE INK Next figure shows the range of the colors in the ALL mXTEND chip antenna component: Acceptable color range Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 12: Recommended Footprint For The Fr01-S4-220

    PCB, see below the recommended footprint dimensions. Measure 18.0 Tolerance: ±0.05mm Figure 5 – Footprint dimensions for the single chip antenna component. For additional support in the integration process, please contact info@fractusantennas.com. Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 13: Assembly Process

    3. After soldering the ALL mXTEND chip antenna component to the circuit board, perform a cleaning process to remove any residual flux. Fractus Antennas recommends conducting a visual inspection after the cleaning process to verify that all reflux has been removed.
  • Page 14 Table 4 – Recommended soldering temperatures. Next graphic shows temperature profile (grey zone) for the ALL mXTEND chip antenna component assembly process reflow ovens. Figure 8 – Temperature profile. Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
  • Page 15: Packaging

    Figure 10 – Image of the tape. Measure 330  1.0 17.5  0.2 21.5  0.2 tMAX Reel Capacity: 1500 pcs Figure 11 – Reel Dimensions and Capacity. Last updated on June 2017 © 2017 FRACTUS ANTENNAS, S.L. -...
