- Page 1 FIREFIELD SIEGE MONOCULAR SERIES USER MANUAL FF12003, FF12004 & FF12004T...
- Page 2 The foundation of Firefield is built on patriotism and a squad approach to teamwork in order to achieve victory and preserve our way of life.
- Page 3 50mm objective lens designed for incredible light transmission and a crystal clear field of view even when dusk sets in. Rubber armor keeps this optic in great shape year after year while a ¼-20 bottom mount allows you to use the Firefield Siege 10x50 Monocular as a compact, on-the-go spotting scope.
-
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS Technical Specifications FF12003 FF12004 FF12004T Magnification (x) Objective lens diameter (mm) Exit pupil diameter (mm) .6 / 15.4 .6 / 15.4 Eye relief (in/mm) .51 / 13 Field of view (degrees) 367.21 367.21 Field of view (ft@1,000yds) Close focus distance (ft/m) - Page 5 • Fully multi-coated optics • Fully multi-coated optics • Roof prism optical system • Internal focusing • Straight eyepiece design • Rangefinding reticle* • Compact, lightweight design • Roof prism optical system • Twist-up eyecup • Straight eyepiece design • Straight eyepiece design •...
- Page 6 DIAGRAM FF12003 1) Eyepiece 2) Twist-up eyecup 3) Focus dial 4) Objective lens 5) Lanyard loop...
- Page 7 DIAGRAM FF12004/FF12004T 1) Eyepiece 2) Twist-up eyecup 3) Focus dial 4) Tripod mount 5) Objective lens 6) Lanyard loop...
-
Page 8: Focus Adjustment
FOCUS ADJUSTMENT The focus dial allows the Siege Monoculars to deliver a clear, sharp image. To focus the image: 1. Turn the focus dial (3) until the image is focused. Make sure the image is always well focused as this will prevent eye fatigue. -
Page 9: Mounting The Tripod
MOUNTING THE TRIPOD All Firefield Siege monoculars include a tripod that attaches to the built-in tripod mount. The built-in tripod mount also works with most aftermarket tripods and window mounts. The built-in tripod mount can be used with any tripod or window mount that uses a standard 1/4-20 UNC tripod screw. - Page 10 USING THE RANGEFINDING RETICLE The Firefield Siege 10x50R Tactical Monocular uses a mil reticle. Mil stands for millra- dian. A millradian is 1/6283.2th of a circle, or 3.438 MOA. The millradian represents 1 unit at 1000 yards. To simplify, a target that is one yard tall at 1000 yards would measure 1 millradian.
-
Page 11: Maintenance
MAINTENANCE Proper maintenance of the Firefield Siege monoculars is recommended to ensure longevity. It is recommended that when the monocular becomes dirty that it is wiped down with a dry or slightly damp cloth. Blow dirt and debris off all optics and then clean lenses with a lens cleaning cloth. -
Page 12: Troubleshooting
TROUBLESHOOTING Proper authorization is required before shipping any product back to Firefield. Failure to obtain authorization could result in your product being returned to the wrong address, lost, or damaged. Firefield is not liable for products returned without authorization. - Page 13 NOTES...
- Page 14 NOTES...
- Page 15 NOTES...
- Page 16 www.fire-field.com...
