- Page 1 Sumo Assembly Instructions...
- Page 2 Contents In the Box Tools Required Configuration Options Configuration A Configuration B...
- Page 3 In the Box Sumo Case Sumo Stalk Surface Clamping Plate Case Clamping Plate Case Keys x2 12mm M6 x Button-head Security Screw x4 15/32” M6 Split Washers x5 T30 Security Driver Bit Nyloc Nuts x5 40mm M6 x Socket Set-screw x5...
- Page 4 Key Number Need advice if you’re using custom fixings? Give us a call.
-
Page 5: Tools Required
Tools Required Pencil Tape Measure Drill Drill Bit 1/4” 16mm Drill Bit 5/8” 10mm Spanner Socket Screwdriver... - Page 6 Configuration Options...
- Page 7 Fixing From Below If fixing your Sumo from below your mounting surface follow: A The mounting surface must not be thicker than 25mm or 1” for this option.
- Page 8 Fixing From Above If fixing your Sumo from above your mounting surface follow: B Screws must be no shorter than 30mm or 1 1/4” for this option. *(screws not supplied)
- Page 9 Ensure that you follow the correct section for your chosen mounting configuration.
- Page 10 Fixing From Below The mounting surface must not be thicker than 25mm or 1” for this option.
- Page 11 If your Sumo Stalk Base Rotation is configured to off, follow steps . Mark out the positions for the Mounting Holes. Please note that your chosen rotate configuration will determine the minimum distance you can mount Sumo from a wall.
- Page 12 Cable Slot...
- Page 13 If your Sumo Stalk Base is configured for a 70° Rotation follow . Mark out the positions for the Mounting Holes. Please note that your chosen rotate configuration will determine the minimum distance you can mount Sumo from a wall.
- Page 15 If your Sumo Stalk Base is configured for a 180° Rotation follow . Mark out the positions for the Mounting Holes. Please note that your chosen rotate configuration will determine the minimum distance you can mount Sumo from a wall.
- Page 16 Screen Direction Screen Direction...
- Page 17 If your Sumo Stalk Base is configured for a 270° Rotation follow . Mark out the positions for the Mounting Holes. Please note that your chosen rotate configuration will determine the minimum distance you can mount Sumo from a wall.
- Page 19 Drill the mounting holes in your surface using the appropriate Below Surface Mounting Template for your rotate configuration - these guidelines can be found on the previous pages of this booklet.
- Page 20 Attach the socket set-screws into the base of the Sumo Stalk. These screws must be tightened by hand to the full depth of the internal thread - do not over tighten.
- Page 21 Attach the Sumo Stalk to your surface. Tighten the Nyloc Nuts to 4Nm or 2.9 ft-lb. The fixings must be installed in the correct order.
- Page 22 Unpeel the adhesive pads on the Stalk Base and carefully slide the Stalk Cover onto the Stalk Base. Tear off the protective netting. Ensure that the Stalk Cover is securely stuck down.
- Page 23 Locate the Sumo Case onto the Sumo Stalk using the metal locating pins on the Sumo Stalk. Please refer to the guidelines to correctly configure the case orientation according to your chosen switch configuration.
- Page 24 Follow the guidelines below to correctly orientate your Sumo Case - appropriate to your specified Switch Configuration and chosen Case Orientation. Lock at Top Lock on Right Hint: Switch Configuration means whether the Neck of the Stalk allows the screen to...
- Page 25 Secure the Sumo Case onto the Sumo Stalk. Ensure the Case Clamping Plate is orientated correctly - it must sit flush with the case. Tighten the screws ( ) to 2Nm or 1.5 ft-lb. Small Hole Large Hole...
- Page 26 Unlock and remove the Sumo Faceplate.
- Page 27 Feed your tablet cabling through the centre of the case and Case Clamping Plate. Clip the cable into place. Where the power cable is connected to a power transformer, the cable must be fed from below.
- Page 28 Connect the cable to your tablet and place into the secure case. Your Sumo is configured to house the tablet as specified within your order. If you need to use a different tablet, please contact us.
- Page 29 Attach the Sumo faceplate securely onto the main case body. Press the faceplate onto the case - ensuring all edges are locked securely in place. Click Click...
- Page 30 Finally, connect your tablet to its power source. You have assembled your Sumo enclosure and it is now ready for use.
- Page 31 If you have any queries, please contact our Customer Care Team.
- Page 32 Fixing From Above Screws must be no shorter than 30mm or 1 1/4” for this option. *(screws not supplied)
- Page 33 If your Sumo Stalk Base is configured for a 0° Rotation follow . Mark out the positions for the Mounting Holes. Please note your chosen rotate configuration will determine the minimum distance that you can mount Sumo from a wall.
- Page 34 Cable Slot...
- Page 35 If your Sumo Stalk Base is configured for a 70° Rotation follow . Mark out the positions for the Mounting Holes. Please note your chosen rotate configuration will determine the minimum distance that you can mount Sumo from a wall.
- Page 37 If your Sumo Stalk Base is configured for a 180° Rotation follow . Mark out the positions for the Mounting Holes. Please note your chosen rotate configuration will determine the minimum distance that you can mount Sumo from a wall.
- Page 38 Screen Direction Screen Direction...
- Page 39 If your Sumo Stalk Base is configured for a 270° Rotation follow . Mark out the positions for the Mounting Holes. Please note your chosen rotate configuration will determine the minimum distance that you can mount Sumo from a wall.
- Page 42 If required, drill pilot holes appropriate for your mounting material and screw type. Use the correct template for your rotate configuration - these guidelines can be found on the previous pages. If you wish to insert the tablet cabling through your surface, drill position...
- Page 43 Feed your tablet cable through the Sumo stalk. Ensure the cable locates and remains within the cable slot in the base. Where the power cable is connected to a power transformer, the cable must be fed from below.
- Page 44 Attach the Sumo stalk to your mounting surface using countersunk screws. The screws must not be shorter than 30mm or 1 ¼ inches. For additional security, use anti-tamper screws. Screws not supplied...
- Page 45 Unpeel the adhesive pads on the Stalk Base and carefully slide the Stalk Cover onto the Stalk Base. Tear off the protective netting. Ensure that the Stalk Cover is securely stuck down.
- Page 46 Locate the Sumo Case onto the Sumo Stalk using the metal locating pins on the Sumo Stalk. Please refer to the guidelines to correctly configure the case orientation according to your chosen switch configuration.
- Page 47 Follow the guidelines below to correctly orientate your Sumo Case - appropriate to your specified Switch Configuration and chosen Case Orientation. Lock at Top Lock on Right Hint: Switch Configuration means whether the Neck of the Stalk allows the screen to...
- Page 48 Feed the tablet cable through the Case Clamping Plate and attach the Sumo case to the Stem. Ensure the metal Case Clamping Plate is orientated correctly - it must sit flush with the case. Tighten the screws to 2Nm or 1.5 ft-lb.
- Page 49 Unlock and remove the Sumo Faceplate.
- Page 50 Connect the cable to your tablet and place into the secure case. Your Sumo case is configured to house the tablet as specified in your order. If you need to use a different tablet, please contact us.
- Page 51 Attach the Sumo faceplate securely onto the main case body. Press the faceplate onto the case - ensuring all edges are locked securely in place. Click Click...
- Page 52 Finally, connect your tablet to its power source. You have assembled your Sumo enclosure and it is now ready for use.
- Page 53 If you have any queries, please contact our Customer Care Team. www.bouncepad.com © 2015 Bouncepad Spotspot Ltd. All rights reserved.
