- Page 1 Electric 260km/h Blower & Vacuum WEEBV260 1938111001 Operator’s Manual & Parts List Please read & understand this manual, paying particular attention to the safety instructions, before use. 12 Sept 2016 WEEBV260 IM.indd 1 17/01/2017 11:22...
- Page 2 WEEBV260 IM.indd 2 17/01/2017 11:22...
- Page 3 CONTENTS SAFETY INSTRUCTIONS SPECIFICATIONS COMPONENTS ASSEMBLY OPERATION MAINTENANCE, CLEANING & STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST DECLARATION OF CONFORMITY WARRANTY WEEBV260 IM.indd 3 17/01/2017 11:22...
-
Page 4: Safety Instructions
Always wear gloves to protect your Wear appropriate close fitting closing hands. at all times, to avoid suction into the SHARP ROTATING BLADES machine Always TURN OFF THE MOTOR & Keep all bystanders & animals at least REMOVE ELECTRICAL PLUG FROM 15 metres away from the machine SOURCE, ensuring the machine has during operation. stopped, before cleaning, removing or If approached, stop the machine adjusting the machine tubes. immediately. Moving Parts Rotating parts can contact or entangle hands, feet, hair, clothing or accessories. Traumatic amputation or severe laceration can result Safety alert symbol. Used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury. DANGER Indicates an imminently hazardous situation which, if not avoided, will result in serious injury. WARNING Indicates a potentially hazardous situation which, if not avoided, could result in serious injury CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. CAUTION Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage. WEEBV260 IM.indd 4 17/01/2017 11:22... - Page 5 Know how to stop the product in an 12. Always wind the cable carefully, avoiding emergency kinking. On slopes, be careful of your footing and wear 13. Use only on AC mains supply voltage shown non-slip footwear on the product label Walk, do not run 10. Keep all bystanders at a safe distance when PREPERATION using your product. Always wear suitable clothing, gloves and 11. Keep loose clothing & jewelry away from the shoes. Do not wear open toe footwear. air inlet. The use of eye protection is recommended 12. Do not attempt to use the product without The use of ear protection is recommended the fully assembled collection bag fitted. To prevent dust irritation, the wearing of a 13. Never blow debris in the direction of face mask is recommended. bystanders. Do not wear loose clothing or jewelry that can 14. Store is a cool, dry place and out of reach of be drawn into the air inlet children. Do not store outdoors. WEEBV260 IM.indd 5 17/01/2017 11:22...
- Page 6 Keep your work area clean with sufficient light. Keep area around the machine clear of obstructions, stones, sticks, wires and other debris or foreign bodies which could cause damage to the machine. DO NOT SMOKE, whilst using the machine. INSPECT YOUR MACHINE Check all bolts, nuts, and screws for tightness before each use, especially those securing guards and drive mechanisms. Vibration during use may cause these to loosen. Replace damaged, missing or failed parts before using. Warning labels carry important information. Replace any missing or damaged warning labels. DRESS PROPERLY Do not wear loose clothing, gloves, scarfs, neckties or jewellery (rings, wrist watches), which can be caught in moving parts. ALWAYS wear protective eye and ear wear. Appropriate gloves are also recommended. Wear protective hair covering to contain long hair, preventing it from getting caught in machinery. DO NOT use whilst barefoot or wearing open toed footwear. KEEP BYSTANDERS AND CHILDREN AWAY Keep unauthorised persons or animals a minimum distance of 15 metres away from the mower. Do not allow children to handle, use, or climb on the lawnmower. DO NOT OVERREACH Keep proper footing and balance at all times, particularly if using on slopes. The machine should not be used on steep slopes and always be sure of footing. AVOID INJURY FROM UNEXPECTED ACCIDENT Keep hands out of the way of moving parts, particularly the engine and rotating cutting tool. DO NOT FORCE TOOL Always work within the rated capacity. Do not use the machine for a purpose for which it was not intended. Always use the correct handles and shoulder straps provided with the machine. MAINTAIN YOUR MACHINE WITH CARE Clean the machine immediately after use. Keep the machine clean to ensure it operates to its full and safest performance. When maintaining this machine, only the manufacturer’s original replacement parts should be used. The use of non-original manufacturer parts may invalidate your warranty. STORE IDLE EQUIPMENT When not in use, the machine should be stored in a dry location. Keep the machine away from children and others not qualified to use it. DO NOT STORE FUEL IN THE MACHINE, fuel over 30 days old can become stale and if used, damage the carburetor, which is not covered by the manufacturer’s warranty. WEEBV260 IM.indd 6 17/01/2017 11:22...
-
Page 7: Specifications
SPECIFICATIONS Model WEEBV260 Product Number 1938111001 Motor Voltage 230-240V/50Hz Motor Power 1300W Actual Power 2800W Protection Class II – Double Insulated Max Blow Speed Km/h 260 Idle Speed (rpm) 8000-13000 Mulch Ratio 10:1 Sound Power Level dB(A) 104 Collection Bag Capacity (ltr) Electrical Cord Length (m) Dimensions (mm) L-580, W-355, H-370 Weight (kgs) N.W 4.5 - G.W 5.3 The manufacturer reserves the right to change the product specification and livery according to continued product improvements. This symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. For more detailed information about recycling of this product, please contact your local council office, your household waste disposal service or shop where you purchased the product. WEEBV260 IM.indd 7 17/01/2017 11:22... - Page 8 INSTRUCTION MANUAL COMPONENTS A. Wheels B. Blower Nozzle C. Suction Tube D. Front Handle On/Off Switch Speed Regulator G. Rear Handle H. Blow/Vac Selector Lever Collection Bag CASING TUBE WEEBV260 IM.indd 8 17/01/2017 11:22...
- Page 9 WEEBV260 IM.indd 9 17/01/2017 11:22...
-
Page 10: Vacuum Assembly
All Blowers can throw small stones, metal or small objects as well as other material. Do not allow anyone to enter the operating DANGER ZONE with you. The danger zone is an area 15 metres in radius. Insist that persons in the RISK ZONE beyond the danger zone wear eye protection from thrown objects. If the unit must be used where there are unprotected people, operate at a low throttle speed to reduce the risk of thrown objects. WARNING EXCESSIVE VIBRATION OF THE MULCHING FAN INDICATES IT HAS BEEN DAMAGED. CONSULT YOUR LOCAL APPROVED DEALER FOR ASSISTANCE GENERAL USE WARNING Prior to using the machine, ensure all hardware (bolts, screws & nuts) are securely tightened. Operate the trigger with your right hand & hold the Front Handle with your left hand. • • The trigger increases and decreases the power of the engine to the attachment, increasing the revolution/reciprocation of the attachment. WORKING PLAN • Blow material to a safe collection point, away from stones and other hard debris, which could damage the mulching fan within the machine. • Limit the amount of time the product is used continuously to a maximum of 30 minutes per session. Leave the machine to rest between sessions for between 5-10 minutes. • • Total amount of work performed per day with the machine, should be limited to 120 minutes’ maximum. Continuous use of the machine can cause “Repetitive Stress Injury (RSI)”. If you feel discomfort, redness or swelling of • your hands and fingers or any other body part, consult your doctor. • Check local regulations for sound level and hours of operation constraints. USING THE VACUUM When using the vacuum, ensure the bag is not damaged and the zip is in working order, to ensure debris is not thrown. • • When the bag is full, open the zip on the bag and tip the contents into a recycling bin or compost heap. WEEBV260 IM.indd 10 17/01/2017 11:22... -
Page 11: Maintenance And Cleaning
• invalidate your manufacturer’s warranty. • The engine must be switched off, with the spark plug cap removed, before the machine is unassembled, cleaned, serviced or maintained. CLEANING Keep your machine clean. Thoroughly clean the machine at the end of each use, paying particular attention to cuttings in and around the guard and cutting tool. Brush off coarse dirt. • • Wipe down the device with a slightly damp cloth. Clean the catch-sack regularly • SUCTION & BLOWER TUBES • It is advisable to remove the Suction & Blower tubes from the machine regularly for cleaning. • Use soapy water to remove any dirt or grime. MOVING THE COLLECTION BAG Push the unlocking button (11) and fold the handle (10) downwards. • • Shake out the collection bag thoroughly, turn inside out and brush the bag out. You may wash the bag with a very mild detergent BY HAND, but ensure it is completely dry before attaching to the • machine and use. • Regularly check the bag for rips, tears or holes and replace immediately if damaged. RECTIFY CLOGGING • Release the locking screw (13). Fold up the housing cover (14) and remove any blockage. • WEEBV260 IM.indd 11 17/01/2017 11:22... -
Page 12: Storage And Transport
Fault Cause Resolution Will not start No mains power (power failure). Check fuse Motor or switch defect. The cable should be checked and replaced if necessary by a qualified electrician. Contact the helpline number in the manual. Material is not being Suction tubes clogged or blocked. Switch to blow mode and clear the vacuumed properly blockage. Collection bag is full Empty the collection bag. Extension cable, if used, is too long, or Use a shorter extension cable with a the cable cross section is too small. cross section the same size or larger than the standard cable on the machine. Machine is vibrating abnormally The fan has become unbalanced due to The fan needs to be replaced by an the impact of a foreign object e.g. a approved service dealer. Please note stone or gravel. that this will not be covered under the warranty, as the warranty does not cover wear and tear or machines that are damaged by the user. WEEBV260 IM.indd 12 17/01/2017 11:22... - Page 13 PARTS DIAGRAM - WEEBV260 WEEBV260 IM.indd 13 17/01/2017 11:22...
- Page 14 Lock Knob & Insert WE123-301019165 Front Vibration Sleeve WE123-301019155C Upper Adj Handle WE123-301019154C Left Housing WE123-301019156C Lower Adj Handle WE123-301019146 Left Decorative Cover WE123-103990566 Lock Knob Connector WE123-301019147 Right Decorative Cover WE123-103990565 Lock Pin WE123-301019168 Adjustable Shield WE123-301070606B Adj Handle Lock Knob WE123-301019169 Blow & Suction Switch WE123-301019158C On/Off Switch WE123-301019170 Leaf Exit WE123-102020111 Micro Switch WE123-104040097 Screw M5×25 WE123-301019161C Speed Control Knob WE123-4990115B Collection Bag Assembly WEEBV260 IM.indd 14 17/01/2017 11:22...
-
Page 15: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Electric Blower & Vacuum Model(s): WEEBV260 Product Number: 1938111001 Type/Serial No. As per rating label on machine Complies with the following directives: Machinery Directive 2006/42/EC The conformity assessment procedure followed was in accordance with EN 50636-2-100:2014, EN 60335:2012+A11:2014, EN 62233: 2008 Measured Sound Pressure Level: L = 93dB(A) Measured Sound Power Level: L = 104dB(A) Vibration Level: 4.31 m/s² Notified Body: Intertek Testing Services Shanghai Addresses: Building No. 86, 1198 Qinzhou Road (North), Caohejing Development Zone, Shanghai 200233, P.R.C Authorised signatory and technical file holder Date: 18/08/2016 Signature: Name: Mr Simon Belcher Position: Managing Director Company: Handy Distribution Ltd Address: Murdock Rd, Swindon, Wiltshire, SN3 5HY. WEEBV260 IM.indd 15 17/01/2017 11:22... - Page 16 INSTRUCTION MANUAL Notes WEEBV260 IM.indd 16 17/01/2017 11:22...
- Page 17 Notes WEEBV260 IM.indd 17 17/01/2017 11:22...
- Page 18 INSTRUCTION MANUAL INSTRUCTION MANUAL This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the 2 year conditional manufacturer domestic warranty*. * Commercial/Professional & Hire users receive a 90 day warranty Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
-
Page 19: Service Book
(c) Neither GJ Handy & Co Ltd nor any company affiliated with GJ Handy & Co Ltd shall be liable in any event or manner whatsoever for incidental or consequential damages or injuries, including, but not limited to, loss of crops, loss of profit, out of pocket expenses or profits, rental of substitute equipment or other commercial losses. WEEBV260 IM.indd 19 17/01/2017 11:22... - Page 20 It is the owner’s responsibility to ensure that their Webb machine is maintained at specific intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
- Page 21 SERVICE BOOK Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 1st Service This must be stamped by an approved service dealer to qualify for a free second year warranty.
- Page 22 INSTRUCTION MANUAL INSTRUCTION MANUAL 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date WEEBV260 IM.indd 22 17/01/2017 11:22...
-
Page 23: Warranty Registration
& services we provide, including information that we believe is relevant to your and/or your machine. We value your trust by giving us this information about yourself and we are committed to protecting your privacy. From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, offers, technical improvements or just opinions, which may be used for marketing, research or analysis purposes. - Page 24 Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY WEEBV260 IM.indd 24 17/01/2017 11:22...
