Model Numbers/ No. de Modelos:
AIR CONDITIONER
AIRE ACONDICIONADO
CAUTION:
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la página 17.
Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications
without notice.
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Avanti Products, A Division of the Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 331 52
www.avantiproducts.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Air Conditioner and is the answer not in the manual?

Questions and answers

Related Manuals for Avanti Air Conditioner

Summary of Contents for Avanti Air Conditioner

  • Page 1 INSTRUCTIONS. La sección en español empieza en la página 17. Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice. Avanti Products, A Division of the Mackle Co., Inc.

  • Page 2: Registration Information

    ? Protect your product: We will keep the m odel number and date of purchase of your new Avanti product on file to help you refer to this information in the event of an insurance claim such as fire or theft.

  • Page 4: Help Us Help You

    FIRST, contact the people who serviced your air conditioner. Explain why you are not pleased. In most cases, this will solve the problem. HELP US HELP YOU...

  • Page 5: Parts And Features

    P ARTS AND FEATURES 1. INTERIOR AIR INLET GRILLE 2. FRONT PANEL 3. CABINET 4. AIR FILTER 5. INTERIOR AIR OUTLET 6. EXTERIOR AIR INLET 7. POWER SUPPLY CORD 8. FRESH AIR VENT LEVER 9. CONTROL PANEL 10. AUTO SWING SWITCH...

  • Page 6: Table Of Contents

    Select The Best Location ______________________________________________________________8 Window Installation Steps _____________________________________________________________9 Installation of Mounting Brackets Installation Of The Cabinet___________________________ _____________________________10 Electrical Connection___________________________________________________________ _11 Operating Your Air Conditioner _______________________________________________________10 Care And Maintenance _______________________________________________________________11 Cleaning The Air Filter _______________________________________________________________13 End-Of-Season Care_________________________________________________________________13 Troubleshooting Guide ______________________________________________________________ 14...

  • Page 7: Important Safety Instructions

    Read all instructions before using the air conditioner. If the air conditioner has a serial plate rating of 115 Volts ~ AC and up to and including 7.5 amps the unit may be on a fuse or circuit breaker with other devices.

  • Page 8: Window Kit Installation

    WINDOW KIT INSTALLATION Installation Accessories (See Fig 1) Flexible exhaust hose with adapters - 3 pieces Window exhaust adapter - 1 piece Adjustable window slider kit – 1 piece Window KIT Installation: Kit provided has been designed to fit most standard vertical and horizontal window applications.

  • Page 9: Window Installation Steps

    This air conditioner requires a standard 115/120 Volt~AC/60Hz electrical outlet with three -prong ground. Never unplug the air conditioner by pulling the power cord. Always grip the plug firmly and pull straight out from the receptacle. Do not use plug adapters or an extension cord with this appliance. If the power cord is too short, have a qualified electrician or service technician install an outlet near the appliance.

  • Page 10: Installation Of The Cabinet

    OPERATING YOUR AIR CONDITIONER Control Panel Key Pad TEMPERATURE Press up and down keys to select a suitable temperature setting. The temperature selected will be displayed in the LCD window. Temperature settings are adjustable between 15ºC (58ºF) to 31 ºC (90ºF).
  • Page 11 AUTO Display When this sequence is selected after pressing the MODE button, the corresponding signal indiactor is lit. In this mode, your unit will logically choose a desired room temperature. If the temperature is not comfortable for you, the desired MODE can be select manually. FAN Display When this sequence is selected the corresponding signal indicator is lit, after pressing the mode button.

  • Page 12: Remote Control Operation

    Replace the batteries when the transmission indicator light fails to appear. ON/OFF Button: Press ON/OFF button when the portable air conditioner is ready for use. The unit is ready to be programmed in auto mode. The LCD window will display “AUTO”.

  • Page 13: Care And Maintenance

    CARE AND MAINTENANCE When servicing the air conditioner, be sure to turn the operation switch to the “OFF” position and disconnect the power cord from the electrical outlet. Do not use gasoline, benzine, thinner or other chemicals on the air conditioner as these substances may cause damage to the paint finish and deformation of plastic parts.

  • Page 14: Problems With Your Air Conditioner

    PROBLEMS WITH YOUR AIR CONDITIONER? You can solve many common air conditioner problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the service. PROBLEM Air conditioner does not operate.

  • Page 15: Service For Your Air Conditioner

    We are proud of our customer service organization and the network of professional service technicians that provide service on your Avanti air conditioner. With the purchase of your Avanti air conditioner, you can be confident that if you ever need additional information or assistance, the Avanti Products Customer Service Team will be here for you.

  • Page 16: Your Avanti Products Warranty

    In no event shall Avanti Products be liable for indirect, incidental, or consequential damages, even if advised in adva nce of the possibility of such damages, no warranties, express or implied, are made to any buyer upon resale.

  • Page 17: Wiring Diagram

    WIRING DIAGRAM...

  • Page 18: Instrucciones En Español

    INSTRUCCIONES EN ESPAÑOL INTRODUCCION Gracias por escoger este equipo de aire acondicionado para enfriar su hogar. Este MANUAL DE USO Y CUIDADO contiene información necesaria para el cuidado y mantenimiento apropiado de su nuevo aire acondicionado. Si lo mantiene apropiadamente, su equipo de aire acondicionado funcionará por muchos años sin presentar problemas.
  • Page 19 Tipos de receptáculo y fusibles Capacidad de enfriamiento Voltios AMPS Tomacorriente Tamaño de fusible Tabla 1 CONSEJOS ANTES DE LA INSTALACION Su equipo de aire acondicionado está diseñado para ser altamente eficiente y a la vez ahorrar energía. Para obtener una mayor utilidad, siga estas recomendaciones: Seleccione el nivel de temperatura que le brinde el confort que necesita.

  • Page 20: Instrucciones Para La Instalacion

    02 escuadras con ángulos 02 abrazaderas 01 cortina lateral derecha 01 cortina lateral izquierda 04 cintas de espuma selladora 02 tornillos niveladores Figura A. Herramientas necesarias para la instalación en ventanas: Destornillador : Philips y plano Taladro : 1/8” de diámetro Lápiz Cinta métrica Tijeras...
  • Page 21 20” mínimo 12” mínimo 20” mínimo Obstrucción lateral 30” mínimo Piso Figura B Requerimiento de apertura de ventanas Modelo Tamaño Estructura (aXhXf) 20.5”X14.8”X23.1” Apertura mínima de 24” ventana Apertura máxima de 38” ventana 2. Preparación para retirar la cubierta corrediza del aire acondicionado a.
  • Page 22 5. Debe usar dos (02) pernos por escuadra. Asegúrelos con las arandelas de 1/4” y con las tuercas de ¼”. NO ajuste inmediatamente los pernos ya que podría ser necesario ajustar las escuadras dependiendo de la medida del alfeizar. Figura 7. Instale los dos tornillos niveladores en los ángulos de soporte de 90º.

  • Page 23: Cuidado Y Mantenimiento

    equipo automáticamente. Figura 14. INSTRUCCIONES PARA OPERAR EL EQUIPO OPERATION (Operación) La perilla de operación controla la velocidad del ventilador y del aire acondicionado. Para seleccionar la temperatura deseada gire la perilla de operación hasta la opción de su preferencia. AUTO AIR SWING SWITCH (Llave de oscilación automática de aire) Cuando el interruptor del control de oscilación está...
  • Page 24 1. NO USE gasolina, bencina, tiner u otr os químicos en su equipo ya que estas sustancias pueden dañar la pintura y/o deformar los componentes plásticos. 2. Nunca intente verter agua directamente frente a su equipo ya que podría causar deterioros en el aislamiento eléctrico.
  • Page 25 sobrecargado. Equipo muy ruidoso Piezas flojas. Soporte inadecuado. Malos olores Formación de moho u otros en superficies húmedas Goteos exteriores Las fugas por condensación son normales durante climas calurosos y húmedos Goteos internos El ángulo en que se ubicó el equipo no permite que el agua drene al exterior.
