Apex Digital AIS750 Series User Manual

Alarm annunciator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AIS750 Series Annunciators
AIS750 Series
Alarm Annunciator

User Manual

(Ver. 2.3 / JUNE. 2014)
3-350 John Street, Thornhill, Ontario L3T 5W6
Phone: 289 597 APEX (2739)
Fax: 289 597 2200
Toll Free: 1 866 776 2943
Email: mail@annunciator.ca
Web: www.ANNUNCIATOR.ca
(1)

Advertisement

Table of Contents
loading

Related Manuals for Apex Digital AIS750 Series

Summary of Contents for Apex Digital AIS750 Series

  • Page 1: User Manual

    AIS750 Series Annunciators AIS750 Series Alarm Annunciator User Manual (Ver. 2.3 / JUNE. 2014) 3-350 John Street, Thornhill, Ontario L3T 5W6 Phone: 289 597 APEX (2739) Fax: 289 597 2200 Toll Free: 1 866 776 2943 Email: mail@annunciator.ca Web: www.ANNUNCIATOR.ca...
  • Page 2 AIS750 Series Annunciators Introduction The AIS750 Series Alarm Annunciator system is an unparallel, modular and dual operation mode Annunciator, designed to give indication of an alarm condition, or equipment status, where a high degree of reliability and fl exibility is required.
  • Page 3 AIS750 Series Annunciators Technical Specifi cation PUSHBUTTONS DISPLAY INPUTS Confi guration: Isolation and Polarity: “Acknowledge”, Reset”, “Test” and “Mute” - One single large window: pushbuttons are supported by the system - Each input is optically isolated up to (H11 type): 75x50mm (WxH) with two choices;...
  • Page 4 AIS750 Series Annunciators AIS750 is an unparallel, modular, dual operation mode Annunciator. The annunciator is made up of windows, window being 75 x 50mm (3``x 2``). The type of cards installed dependent on system specifi cation and the required options.
  • Page 5 AIS750 Series Annunciators Window/Cell Confi guration The AIS750 is modular and window based designed. It is manufactured from 75x50mm windows which can be assembled in an array to provide the number of rows and columns required to suit individual panel designs.
  • Page 6 AIS750 Series Annunciators Logic Card & Repeat Relay Module Depend on window type (H11, H21, H44, H12, V21), each Logic card supports 1, 2 or 4 inputs. Each logic card can be assigned to two different groups (Critical or Non-critical).
  • Page 7 AIS750 Series Annunciators Logic Card Settings in Stand-alone Mode: Operation Mode Setting APEX Automation Solutions AIS Logic card Switch 1 On: Stand-alone Switch 1 Off: Serial Mode Stand-alone Mode DIP Switch setting: Sequence switch 2 switch 3 switch Manual Reset (M)
  • Page 8 AIS750 Series Annunciators Logic Card Settings in Stand-alone Mode: Operation Mode Setting Switch 1 On: Stand-alone Switch 1 Off: Serial Mode APEX Automation Solutions AIS Logic card Alarm Group & Repeat Relay Setting 1,2 Open:  Alarm Group 1 (Non-critical)
  • Page 9 AIS750 Series Annunciators Logic Card Settings in Serial Mode: In Serial operation mode, each Logic Card in the system has its own unique address. This unique address is set using the switches 2-8 located on DIP switch as shown below.
  • Page 10 AIS750 Series Annunciators Relay Module (Repeat Relays) - optional: Individual channel Repeat Relays Each 4 channel Logic Card can be supplied with an optional 4 channel Relay Module (RM) which plugs into Logic Card and provides the user with a dry contact (potential free contact) per alarm channel for use with 3rd party devices.
  • Page 11 AIS750 Series Annunciators Interface & Communication Module Interface module communicates with Logic Cards and supports internal and external pushbuttons and provides common outputs such as internal buzzer, common alarm outputs such as First-up output, common Alarm Horn, etc. It also manages common functions such as system confi...
  • Page 12 AIS750 Series Annunciators Interface Module Settings: The AIS750 supports two operation modes; Stand-alone (standard) and Serial mode. Stand-alone mode is recommended if no serial communication needed with other devices. The operation mode of Interface Module should be set as bellow table.
  • Page 13 AIS750 Series Annunciators Interface Module Settings: Interface Module Jumper settings for both operation modes (Stand-alone and Serial Modes): There are two relays on Interface module. Function of relays can be set by jumpers as showing bellow allowing the relays to operate as:...
  • Page 14 AIS750 Series Annunciators Interface Module Setting in Serial Mode: For operation in Serial mode, Interface module DIP switch must be set (switch1, Off). For Multi-Drop connection (connecting up to 7 units), each Interface Module in the system requires a unique address therefore the fi rst unit in any given system is address 1, the second one address 2 etc, as shown bellow.
  • Page 15 AIS750 Series Annunciators Communication Module (Com. Module) - optional: Com. Module provides two individual ports, Com 1 and Com. 2 via a 4 pin pluggable connector (Com 2 is disabled in this system). Each port can be set as RS485 or RS232 as shown below.

  • Page 16: Wiring Diagram

    AIS750 Series Annunciators Wiring Diagram Power Supply Wiring  Fuse 24VDC power supply An external FUSE is strongly recommended as shown above. Depend on system options, every 7-10 Logic Cards (usually each row) needs one 24VDC power connection. One power connection for Interface module is mandatory.
  • Page 17 AIS750 Series Annunciators Wiring Diagram Alarm Iuput Wiring  Depend on window type (H11, H21, H12, V21, H44), each Logic card supports 1, 2 or 4 inputs. Each Input should be confi gured individually to accept Dry (potential free) or powered contacts.
  • Page 18 AIS750 Series Annunciators Wiring Diagram Alarm Output Wiring  1 2 1 2 There are two relays on Interface module. Function of theses relays can be set allowing the relay to operate - Audible: Activates on alarm and remain active...
  • Page 19 AIS750 Series Annunciators Wiring Diagram External (remote) Pushbuttons Wiring  As an alternative, Pushbutton Module can be supplied as a remote item or 1 2 3 4 the user can use conventional panel mounting momentary/normally open pushbuttons to control the Annunciator.
  • Page 20 AIS750 Series Annunciators Wiring Diagram Repeat Relays Wiring  Individual channel Repeat Relays Each 4 channel Logic Card can be supplied with an optional 4 channel Relay Module (RM) to provide dry contact (potential free) contacts per alarm channel to be used with 3rd party devices. Each relay is equipped with a change-over contact and the user can select the contact state to NO or NC.
  • Page 21 AIS750 Series Annunciators Wiring Diagram Serial Communciation Wiring RS232 RS485 DB9 Standard RS232 and RS485 DB9 Female Connector Female Connector Pin Confi guration Serial port equvalent pin confi guration for DB9 female connector Slave (Annunciator) Slave (Annunciator) RS485 RS232 DB9 Female Connections...

  • Page 22: Multi-Drop Communication

    AIS750 Series Annunciators Multi-Drop Communication Serial communication wiring to Master MODBUS (RS485) MASTER For Multi-Drop connection (connecting up to 7 annunciators to another device), each Interface Module in the system (each Annunciator) requires a unique address (node address), starting with “1” for the fi rst up to 7 annunciators Annunciator, address “2”...
  • Page 23 AIS750 Series Annunciators Serial communication wiring to Master DNP3 (RS485)  RS485 (GND) To Master RS485 (Data-) (DNP3) RS485 (Data+)  To Master Ethernet (DNP3) +24VDC AIS750 supports Modbus RTU-Slave, DNP3 Serial, DNP3 Ethernet and many other protocols including; Modbus TCP, BACnet MS/TP, BACnet IP, AB EtherNet IP, Allen Bradley EtherNet,AB DF1, SNMP, GE-EGD, GE-SRTP, GE-SNP, OPC, Omron Fins, Metasys N2 Open,...
  • Page 24 AIS750 Series Annunciators Modbus and DNP3 Registers’ List and Spec.: Communication: RS485, 19200, No Parity, 2 stop bits Annunciators address (node address): 1 to 7 Modbus address same as Annunciator address Coil Address Read-Write Function DNP Data Class DNP3 Address...

  • Page 25: Lens Assembly

    AIS750 Series Annunciators Lens Assembly Each channel is equipped with its own removable lens assembly, which contains a clear lens, a laser printed fi lm legend (if applicable), a white or coloured lens and a plastic bezel on top of them.
  • Page 26 AIS750 Series Annunciators Window Lens Replacement Both Engraving and translucent fi lm can be used for alarm labeling (alarm legends). Both Engraving and translucent film can Lens (or fi lm) replacement doesn’t need any special tools. Each window has surrounded with a plastic bezel. There is a small slot at the bottom of each window (behind plastic bezel) which allows a fl...
  • Page 27 AIS750 Series Annunciators 7- Put the screwdriver inside the slot and push 6- Place the new lens inside the frame the lens in 9- Put the plastic bezel back in place 8- Secure the lens 10- Push the corners of plastic bezel...
  • Page 28 AIS750 Series Annunciators Plug-in LED Module Replacement To reduce the power consumption an to provide a maintenance free solution, Each window is illuminated by almost unlimited life time “plug-in” LED Modules. Each LED module comes with two high bright, 120°, long life LEDs.

  • Page 29: Alarm Sequences

    AIS750 Series Annunciators Alarm Sequences Manual Reset (Sequence Code M) Auto Reset (Sequence Code A) No Lock In P: Normal P: Normal P: Normal S: Normal S: Normal S: Normal V: Off V: Off V: Off A: Silent A: Silent...

  • Page 30: Order Number

    Integral Push Button & Buzzer Module (option) Standard AIS750 Series Annunciator supports four remote Pushbuttons (Acknowledge, Reset, Test, Mute) and two Horns. As an option, an integral “Pushbutton & Buzzer Module” can be fi tted in the bottom right window.
