- Page 1 CarConnect Bluetooth Interface Installation Manual...
- Page 2 CarConnect Smartphone Integration Interface Installation/Owner’s Manual Table of Contents 1. Wiring Overview 2. GM Vehicles - Page 3 3. Honda/Acura Vehicles - Pages 3-4 4. Toyota/Lexus/Scion - Page 4-5 5. Connecting the Factory Satellite Radio Tuner Accessory Wire (PGHSATR) - Page 6 6.
- Page 3 Interface. To complete the installation secure the CarConnect into the cavity in the dash behind the radio. Be sure that the cables and interface modules are not near moving parts or sharp metal edges as they may damage the cables. To prevent rattling noises inside the dash, use zip ties, tape, or other fasteners to mount the interface securely.
- Page 4 Plug the Black micro-fit 24-pin connector on the PGHHD1R harness into the CarConnect Interface. To complete the installation secure the CarConnect into the cavity in the dash behind the radio. Be sure that the cables and interface modules are not near moving parts or sharp metal edges as they may damage the cables. To prevent rattling noises inside the dash, use zip ties, tape, or other fasteners to mount the interface securely.
- Page 5 Plug the Black micro-fit 24-pin connector on the PGHTY1R harness into the CarConnect Interface. To complete the installation secure the CarConnect into the cavity in the dash behind the radio. Be sure that the cables and interface modules are not near moving parts or sharp metal edges as they may damage the cables. To prevent rattling noises inside the dash, use zip ties, tape, or other fasteners to mount the interface securely.
- Page 6 CarConnect Smartphone Integration Interface Installation/Owner’s Manual Connecting the Satellite Radio Tuner Accessory Wire **PLEASE NOTE: This only needs to be done in vehicles which have multiple factory peripherals such as Satellite Radio, Rear Seat Entertainment & a CD Changer** In some vehicles you will need to access the factory satellite radio tuner and connect the supplied PGHSATR wire to the tuner side of the accessory input wire.
-
Page 7: Fcc Statement
2. Switch the radio to the XM or CD Changer source (depending on how you have the CarConnect configured). 3. Pair your phone with the CarConnect. The CarConnect should be discoverable after the install. If it is not, follow the proce-dure listed below for your mode of operation to make the CarConnect discoverable.
