PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 1 Safety Precautions 1.1. General Guidelines · For continued safety, no modification of any circuit must be attempted. · Unplug the power cord from the power outlet before disassembling this projector.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 2 Ext Option This projector has EXT OPTION in addition to standard on-screen menus. · There are SELF CHECK and TEST PATTERN for service, etc. 2.1. Procedure to enter EXT OPTION 1.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA according to connected equipment. In this case, set HPLL to OFF. · EMULATE Switching the operation of RS-232C command to communicate with models other than F100 series. − − − − DEFAULT: F100/F100NT standard, D3500 −...
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 3.3. Canceling the self-check mode Press "MENU" button on the main unit or remote control unit. 4 Test Pattern This projector displays seven kinds of test patterns [Horizontal lines, Vertical lines, Dots, Crosshatch, White cross, Black cross and White (No pattern)] in the four colors (White, Red, Green and Blue).
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 6 Using the SERIAL Connector The serial connector which is on the back connector panel of the projector conforms to RS-232C standard. This projector can be controlled by a PC which is connected as shown in "6.1. Connection".
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 6.4. Control commands 6.5. Communication Cable Specifications 6.6. Signal Selector Connecting Cable Specifications When connecting to a signal selector (ex. TW-SWS62J), use a cable with specifications below. Connecting method: Connects a video signal cable from the signal selector to "VIDEO IN", and an RGB signal cable to "COMPUTER 1 IN".
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 7 Disassembly Instructions Warning: · Be sure to unplug the power cord from the power outlet before disassembling this projector. Caution: · While turning over a printed circuit board, be sure to put a insulating material under it to prevent a short circuit.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 7.2. Removal of Upper Case 1. Turn the projector upside down. 2. Unscrew the 8 screws. Note: · When reassembling, confirm the interlock switch is normal status (the switch is in "ON" position).
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA "Removal of ARF Drive Unit". 2. Unscrew the 1 scre remove the F-P.C.Board 6. Disconnect the flexible cable between G-P.C.Board and A- 7.6. Removal of G-P.C.Board P.C.Board (A20). 7. Disconnect the connector between R-P.C.Board and A- 1.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 7.11. Removal of S1-P.C.Board 1. Remove the upper case according to the section 7.2. 7.8. Removal of L-P.C.Board "Removal of Upper Case". 1. Remove the block of Analysis Block, LCD Block and 2.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA P.C.Board. 3. Unscrew the 2 screws and remove the S2-P.C.Board. 7.13. Removal of Z-P.C.Board 7. Unscrew the 2 screws and remove the exhaust fan. 1. Remove the upper case according to the section 7.2.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Note: 12. Unscrew the 4 screws and remove the B/Q-Module. · When installing the lamp unit in the main unit, place it in a specified position and press the right and left...
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA panel. 7.19. Replacement of LCD Panel (B) 8. Unscrew the 3 screws and remove the block of Analysis 1. Remove the LCD block according to the section 7.18. Block, LCD Block and Projection Lens.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA shifted by your fingers. · Since the ID-tag seal is pasted to the FPC of LCD Panel, (R), (G) or (B) can be easily identified by the color of the Note: seal.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Note: · Be careful not to touch the surface of incidence polarizer. 7.24. Replacement of Projection 7.23. Replacement of Incidence Polarizer Polarizer (R and B) · The procedure is described as an example of projection 1.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 3. Loosen the 1 screw until it idles, remove the ARF unit while sliding the lock lever. 7.25. Replacement of PBS Array (Analysis Block) 1. Remove the analysis case (upper) according to the steps 1 through 3 in the section 7.23.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 8 Measurement and Adjustments 8.1. Adjustment Procedure Flowchart 8.2. Cautions for Adjustment · Never unplug the power cord until the power indicator on the projector illuminates red. · To maintain and ensure safety, always use the designated components for replacement parts.
Page 23
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Note: · See figures in the section 7.19. "Replacement of LCD Panel (B)" for 2 screws fixing the panel adjuster and 2 screws fixing the panel attachment. 2. Reassemble the projector in the reverse order of disassembling, but leave the upper case and the screws fixing the A- P.C.Board block as they are removed.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Repeat steps (1) to (3) until the green and blue crosshatch patterns merge into a cyan pattern. 8. After the adjustment, reassemble the projector according to the steps 8 through 9 in the section 7.19. "Replacement of LCD Panel (B)".
Page 25
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 8.5.3. Adjustment Procedure 8.5.3.1. Outline When the lighting area is off from the adjustment and color unevenness appears, adjust the lighting area into correct position. Symptom Measure Magenta unevenness G Reflector Adjustment...
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 3. Adjust the mirror adjusting lever A position to minimize color unevenness on the screen by shifting the lever in arrow directions. 4. Tighten the 1 screw. 8.5.3.3. R Reflector Adjustment 1.
Page 27
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Model: Model name of projectors Data: Displays the data transmission/reception menu. Adjustment: Displays the adjustment menu. Exit: Exits this application. 8.6.4. Data Transmission/Reception Menu 8.6.4.1. Explanation of Buttons Micom Data Transmission: Reads the microcomputer data from the file and transmits it to the projector.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 8.6.5. Adjustment Menu 8.6.5.1. Explanation of Buttons Input Level Adjustment RGB: Displays the RGB input level adjustment menu. Model Info Setup Displays the model information setup menu. Exit: Exits this application.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA · Use the window pattern of XGA (1 024 × 768). 3. Click the OK button. 8.9. Model Information Setup 8.9.1. Adjustment Menu 8.9.2. Explanation of Buttons Executes model information setup, then closes this dialog.
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 11 Block Diagram 11.1. Power Supply Power Supply COLD +17 V MAIN INTERLOCK F9101 POWER Q206 SWITCH Q207 POWER SWITCHING LINE LINE D9101 RECTIFIER FACTOR STB 3.4 V TRANSFORMER...
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA 16 Replacement Parts List Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TEJC034 FRONT PANEL ARM R [MECHANICAL PARTS] TEJC035 FRONT PANEL ARM L...
Page 71
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TMKG809 SPONGE 4 TXFEJ02QEXZ OPERATING UNIT ASSY TMKG811 INLET SPONGE TXFEJ04QEXZ SUPPORT UINT ASSY...
Page 72
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description IC1002 C3EBCC000052 IC3001 C0JBAR000367 IC1005 C1AB00002684 IC3002 C1AB00002428 IC1006 C3ABPJ000071 IC3003 C0ZBZ0001361 IC1007 C0DBEKG00004...
Page 73
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description D1018 MA8056M DIODE L1025 J0JCC0000168 FILTER D1020 MA8056M DIODE L1026 J0JCC0000168 FILTER D1021 MA8056M...
Page 74
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description FL1004 J0HAYY000046 FILTER R1065 ERJ3EKF1473 M 147KOHM, 0.063W FL1005 J0HAYY000012 FILTER R1066 ERJ3GEYJ102...
Page 75
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R1168 ERJ6ENF75R0 M 75 OHM, 1/10W R1263 ERJ3EKF1004 RESISTOR R1169 ERJ3GEYJ102 M 1K OHM,J,1/16W R1264 ERJ2GEJ220 M 22 OHM, 0.063W...
Page 76
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R1352 ERJ3GEYJ331 M 330 OHM,J,1/16W R1437 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R1353 ERJ3GEYJ331 M 330 OHM,J,1/16W...
Page 77
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R1704 ERJ2GEJ223 RESISTOR F100NTU/E/EA R1802 ERJ3GEYJ102 M 1K OHM,J,1/16W F100NTU/E/EA R1705 ERJ2GEJ101 M 100 OHM, 0.063W...
Page 78
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R1888 EXB2HV220JV RESISTOR ARRAY F100NTU/E/EA C1011 ECJ1VF1E104Z C 0.1UF, Z, 25V R1889 EXB28V220J...
Page 79
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C1084 ECJ0EF1C104Z C 0.1UF, 16V C1158 ECJ1VF1E104Z C 0.1UF, Z, 25V C1085 ECJ0EF1C104Z C 0.1UF, 16V...
Page 80
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C1252 ECJ0EF1C104Z C 0.1UF, 16V F100NTU, F100U C1338 ECJ0EB1C103K C 0.01UF, 16V C1253 ECJ1VF1C104Z C 0.1UF, Z, 16V...
Page 81
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C1753 ECJ1VB1C104K CAPACITOR F100NTU/E/EA C1832 ECJ0EF1C104Z C 0.1UF, 16V F100NTU/E/EA C1754 ECJ1VB1C104K CAPACITOR...
Page 82
PT-F100NTU / PT-F100NTE / PT-F100NTEA / PT-F100U / PT-F100E / PT-F100EA Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C9610 F0C2E1050008 CAPACITOR TXANP02QEXZ CIRCUIT BOARD-K ASSY C9615 F0C3C4720003 CAPACITOR ETXMM659MCH CIRCUIT BOARD-P...
