JVC HA-E9-SL Service Manual

Stereo headphones.
Hide thumbs


Advertisement

SERVICE MANUAL
STEREO HEADPHONES
HA-E9-SL(K)
The "Product Exchange System" is applicable to this product.
For limited spare parts, refer to the parts list.
Specifications
Type
Frequency response
Nominal impedance
Sensitivity
Max.input capability
Cord length
Mass
Design and specifications subject to change without notice.
COPYRIGHT C 2000 VICTOR COMPANY OF JAPAN. LTD
: Moving coil
: 8 Hz-24 000 Hz
: 32 ohms
: 98 dB/1 mW
: 30 mW
: 1.2 m (3.94 ft) with 3.5 mm dia.stereo miniplug
: 36 g (1.27 oz) (without cord)
50 g (1.77 oz) (with cord)
HA-E9-SL(K)
No.70250
Nov.2000
