- Page 1 OWNER'S MANUAL LS6500 AM/FM Stereo Receiver and Auto Reverse Cassette Player Designed for In-Wall Installation of All Recreational Vehicles, Motor Homes and Mobile Housings 12 Volts DC A Registered Trademark of Magnadyne Corporation...
-
Page 2: Controls And Functions
INTRODUCTION WARNING! To prevent fire or electrical shock hazard, do not Please read all of the information in this booklet before using this unit to insure that you fully understand the capabilities of expose this product to rain or moisture, or remove cover or this unit. - Page 3 To release the fast The digital display is an information center for the many forward and rewind buttons once they have been pressed, functions of the LS6500. See "Digital Display Detail" for more press the stop/eject button (8). information.
-
Page 4: Recalling Memorized Stations
CD player as this connection will insure the 5. Repeat the procedure to store up to 6 radio stations for FM1 best performance and sound quality. The LS6500's volume, and AM1 then press AM/FM band selector button again to balance and tone controls will operate normally when the advance to FM2. -
Page 5: Operation And Maintenance
Note: the LS6500 clock is the 24 hour type. When setting the 6. To stop the tape play, press the stop/eject button (8) once. hours, make sure that the correct indicator (AM or PM) is 7. -
Page 6: Care And Maintenance
If a poor quality tape or a 120 minute tape is used in this unit the tape may become entangled with the capstan and break. We recommend no longer than 90 minute, good quality brand name cassettes be used in the LS6500. Figure A Loose Tape... -
Page 7: Installation
INSTALLATION Wall Panel C T IO F U N A U X R A D T A P V O L H IG L O W End Caps A N C R S E O R T B A L N S P E V E T R A... - Page 8 POWER CONNECTIONS This unit for use only with a 12 volt DC power source with a negative ground Aux Input Cables Connect to "line outputs" of external cassette deck, CD player, VCR or TV. Units can be AC or DC operation. PINK Wire (+) Memory to Battery RED Wire (+) To 12 Volt DC Power BLACK Wire (-) Ground...
-
Page 9: Speaker Connections
SPEAKER CONNECTIONS Left Speaker (A) Right Speaker (A) BROWN Wire GRAY Wire ORANGE Wire WHITE Wire GREEN Wire BLUE Wire Left Speaker (B) Right Speaker (B) Speaker Connections: Do not confuse the A and B speaker sets... -
Page 10: Antenna Connections
Plug the male plug from the DP36AXT plug from the antenna into the female receptacle provided on the unit. into the female receptacle of the LS6500 unit and allow the cable of the antenna to lay inside the wall. -
Page 11: Safety Instructions
SAFETY INSTRUCTIONS Read Instructions: All the safety and operating instructions should be Damage Requiring Service: The appliance should be serviced by read before the appliance is operated. qualified service personnel when: A. The power supply cord or the plug has been damaged; or Retain Instructions: The safety and operating instructions should be B. -
Page 12: One (1) Year Limited Warranty
WARRANTY ONE (1) YEAR LIMITED WARRANTY Magnadyne Corporation or its authorized agents will within 1 year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the Magnadyne Corporation or its authorized agents, if said product or part is found defective in materials or workmanship, when properly connected and operating on the correct power requirements designated for the specific product.
