Summary of Contents for DMP Electronics LT-1461
-
Page 2: Fcc Information
FCC Information FCC compliance: Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 3: Table Of Contents
V-4408D SecureCom Video 8-Channel NVR User Guide Table of Contents Section Page Introduction ..............1 What is an SecureCom Video 8-Channel NVR ......1 Live View ..............2 Quick Setting Toolbar ..........3 Right-click Menu Options .......... 4 Menu ..................6 Playback ................6 Export .................8 Manual ................10 Configuration ..............10 Maintenance ..............10... - Page 4 SecureCom Video 8-Channel NVR User Guide...
-
Page 5: Introduction
Introduction What is an SecureCom Video 8-Channel NVR The SecureCom Video 8-Channel NVR is a Network Video Recording device with 1 TB of video storage. The eight channels represent eight network/IP SecureCom Video or ONVIF compatible cameras. Power up the SecureCom Video 8-Channel NVR. Live View displays what each camera is viewing, providing you with the latest in computer technology to create the most advanced, user friendly, wireless/wired security camera system available. -
Page 6: Live View
Live View • Live View is the first display you see when the NVR powers • All cameras connected to the NVR whether wireless or wired, will display immediately. • The default live view screen is 1+7 multi screen view (see below). -
Page 7: Quick Setting Toolbar
Quick Setting Toolbar Figure 2: Quick Setting Toolbar Figure 3: Instant Playback Slider The Quick Setting toolbar displays when a left-click on mouse is made on the Live View camera viewing window. The toolbar displays at the top or bottom of the selected camera screen. The tools when clicked controls the current active window. Tools that are unavailable will be grayed out. -
Page 8: Right-Click Menu Options
Right-click Menu Options Right-click on the mouse anywhere on the Live View screen and the Right-click Menu displays as shown in Figure 4. Menu Option Description Menu Displays a menu window with the following available options: Playback, Export, Manual, Maintenance and Shutdown. These options can control one or more cameras at the same time. - Page 9 Playback Short cut to the Menu>Playback option. Allows playback of previous recordings of one or more cameras set for a specified date and time. See Playback in the Menu Section. PTZ Control Only available on Pan and Tilt cameras. A set of controls will display providing the ability to move the camera view up, down, right and left.
-
Page 10: Menu
Menu The Menu displays with the following available options: Playback, Export, Manual, Configuration, Maintenance, and Shutdown. Figure 7: Playback Menu Figure 6: Menu Playback Playback menu option plays back video recorded on the NVR by each camera. You can view one or all cameras simultaneously by marking the check boxes of the cameras from the list on the right hand side of the screen. - Page 11 Playback Toolbar Detailed Explanation: This icon toggles to start and stop clipping creation. Click once to start the clipping then click it again to stop the clipping. When you leave the playback camera view, an Attention displays a message “There are some video clips to be saved.
-
Page 12: Export
Export Recorded clips can be exported to USB flash drives and hard disk drives (HDD). Enter the search criteria to find the recordings to export then click Export. Figure 10: Export IP Camera Click the check box next to IP Camera to select or deselect all cameras. Click the check box next each camera to select or deselect each camera individually. - Page 13 File Type All - All recordings of the camera Unlocked - Only unlocked recordings Locked - Only locked recordings Start Time Start date and time of the recording you are searching for on the NVR End Time End date and time of the recording you are searching for on the NVR Click on Search at the bottom of the screen.
-
Page 14: Manual
Manual Allows you to turn on and off recording for each or all cameras. In Figure 12, next to IP Camera, the setting is set to OFF. This button can be toggled on and off for manual recording for all cameras. The button next to a camera number such as D1, D2, etc. - Page 15 Log Information - A log of operation, exception and information of the NVR are stored in log files, which can be viewed and exported at any time. Log Information helps you search for log files with the listed criteria check marked.
- Page 16 Net Detect N et Traffic - You can view the sending rate and receiving rate information on the monitor. The traffic data is refreshed every second. Network Detection - You can obtain network connecting status of the NVR through the network detection function, including network delay, packet loss, etc.
- Page 17 Network Stat. 1. Check the bandwidth of IP Camera, bandwidth of Net Receive Idle and bandwidth of Net Send Idle. 2. You can click Refresh to get the newest status. Figure 16: Network Status Information on the NVR SecureCom Video 8-Channel NVR User Guide...
- Page 18 SecureCom Video 8-Channel NVR User Guide...
- Page 19 SecureCom Video 8-Channel NVR User Guide...
- Page 20 LT-1461 16525...
