Flag 3
Laser Distance Meter
User Manual
Overview
AdirPro Flag 3 laser distance meter measures up to 328' (100m)
with +/- 1/16" (1.5mm) accuracy, integrates a tilt sensor, and has an
HD full-color screen. The screen is specially designed for
professional users. It's powered on a li-ion battery, which greatly
enhances battery usage life, and can last for several years. In
addition, its green background color makes it visually pleasing to
look at
mOS V1.5, is an innovated and patented measuring system, which
has a vivid colorful screen, strong interactive interface, and
professional measuring functions. The various auxiliary functions
and unique personal settings provide an excellent measuring
experience.
The built-in Bluetooth module transfers data from the Flag 3 to
Android and iOS devices in real-time, and enables remote control
and photo-distance association.
The Flag 3 has the perfect combination of an ergonomic and
modern design that gives it a beautiful look and comfortable grasp. The Flag 3 is a leading laser distance
meter heralding a new era of professional measurement.
Power on and off
Power on
Long press
to power on the instrument and activate the laser. The single measuring interface will
be displayed on the screen.
Power off Manually
Advertisement
Related Manuals for AdirPro FLAG 3
Summary of Contents for AdirPro FLAG 3
- Page 1 The Flag 3 has the perfect combination of an ergonomic and modern design that gives it a beautiful look and comfortable grasp. The Flag 3 is a leading laser distance meter heralding a new era of professional measurement.
- Page 2 Long press to power off the instrument. Power off Automatically The instrument will be power off automatically after three minutes of inactivity. Keypad List OK / Confirm Return / Cancel Area/Volume/Pythagorean Tilt / Auto Level / Auto Height / Triangle area Go Left Go Right Go up/ Addition(+)
- Page 3 Press again to take the second side distance measurement (e.g. width). The results of length, width, perimeter, and area will be seen on the display. Volume Measurement Press twice to activate the volume measuring function. The symbol will appear on the display. Press to activate the laser, and aim at the target.
- Page 4 Points to calculate the height. 1. Press three times. The symbol will appear on display. 2. Press to activate the laser and aim at the point which is to be measured. 3. Press again to take the first measurement (1), and then again to take the second measurement (2).
- Page 5 Figure (B) Note: (1) The device will automatically determine the longer distance as triangle’s hypotenuse, and shorter distance as the right-angle side. (2) When measuring the right-angle side (Distance 2 in Figure B), the user should ensure that the laser beam is at a right-angle to the target line.
- Page 6 Bluetooth Flag 3 laser distance meter’s Bluetooth function is used for interactions with Android and iOS devices on their corresponding App. It can be used for data transfer, remote control, and more. The following information is a guide to how to enable the Bluetooth function. For more information and details on the function and operating steps, please refer the Android or iOS App.
- Page 7 Bluetooth APP downloading address: www.AdirPro.net Menu to go to the function menu, which lists all of Flag 3’s functions by 3x3 icons per page. Press Use the arrow keys to select the desired function.
- Page 8 3. Historical data lock / unlock Usually, the instrument saves a limited number of measurement data. It will automatically delete the oldest data when new data comes in. The “data locking” function enables the user to save data permanently unless the user deletes it manually from the memory. Press to browse the records.
- Page 9 . Use the arrow keys to navigate and select “Const”. Press Press Press to move the cursor and select corresponding number. Press to increase/decrease the exact value. Press to save the setting, or press to exit without saving. Note: All measuring results will be added or subtracted from the constant; tolerance will be calculated into the result.
- Page 10 Switch on/off the device several times. If the symbol still Hardware error appears, your instrument is defective. Please contact your distributor. Function List and Specifications Specification Flag 3 0.17’-328’ (0.05m-100 m) Typical measuring range ± 1/16” (1.5 mm) Typical measuring accuracy Measuring units m/in/ft/ft+in ...
- Page 11 Maintenance Do not use aggressive cleaning agents or solutions. Remove the battery before a long period of non-use. Warranty The AdirPro Flag 3 comes with a one year warranty from AdirPro. More detailed information is available at www.adirpro.com Contact AdirPro...
