Electrical Data - Altivar Process ATV630 Function Manual

Electrical Data

Logic Type
Safety function must only be used in Source mode: current flows to input.
Cabling Label
Input Signal Safety Function
Input Signals Safety Function
Logic 0 (Ulow)
Logic 1 (Uhigh)
Current (at 19 Vdc)
Delay between STOA and STOB
Response time of safety function
22
Units Value for STO
Vdc < 5 or open
Vdc > 11
mA 11
s < 1
ms < 10
EAV64334 06/2017
