2. Connector Panel

2
1 3
2 8 9
Items
HDMI OUT Displays whatever is on the screen, including Android annotation.
1
Connect USB devices such as mobile hard disk, U disk, USB keyboard
USB
2
and mouse, USB drives, etc.
HDMI IN
HDMI input
3
TOUCH Touch signal output for connection to external computer
4
DP DisplayPort input
5
Line level audio input
AUDIO IN
6
VGA input
VGA IN
7
Composite video + audio input - 3.5mm 4-conductor
AV IN
8
Digital audio output - "RCA" connector
COAX OUT
9
Control interface
RS-232
10
AUDIO OUT Output to an external amplifier and speaker
11
LAN RJ-45 connector
12
13 AC SWITCH Master power switch
AC IN AC power input
14
HDMI = High-definition multimedia interface
3 4 3
LAN
10 11 12
Function description
3
5 6 7
13 14
