Common Sense RC SNAP&FLY Owner's Manual

3-in-1 rtf modular airplane system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SNAP&FLY — Modularized RC Airplanes
SNAP&FLY Advantages:
Flight components sharing – Flying a variety of RC airplanes for the price of one,
Make and fly your choice of RC airplanes On-The-Go – Easy, convenient and fun,
Non-destructive structural disconnection – Crash damage resistant.
Disclaimer of Liability
The user understands that any and all items in this product and their operations including:
motors, propellers, lithium batteries, magnetic actuators, charger, transmitter and receiver, and
the combined systems and/or operations of these items/systems can be dangerous if used or
handled improperly. A thorough understanding is necessary before the user handles the items
and/or operates the systems in this product. ItCanFly, LLC cannot be responsible for any
improper use or handling of this product and its component items by the user. The user waives
all claims of damages against ItCanFly, LLC for any and all damages arising from the use of this
product by the user, including, but not limited to, any bodily injuries or property damages
sustained as a direct or indirect result of the user's use of this product.
(Patent pending)
Owner's Manual
www.itcanfly.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SNAP&FLY and is the answer not in the manual?

Questions and answers

Related Manuals for Common Sense RC SNAP&FLY

Summary of Contents for Common Sense RC SNAP&FLY

  • Page 1 SNAP&FLY — Modularized RC Airplanes (Patent pending) Owner’s Manual SNAP&FLY Advantages: Flight components sharing – Flying a variety of RC airplanes for the price of one, Make and fly your choice of RC airplanes On-The-Go – Easy, convenient and fun, Non-destructive structural disconnection –...
  • Page 2 SNAP&FLY -- Modularized RC Airplanes SNAP&FLY Quick Start Rotating propellers and moving airplanes can cause bodily injury or property damage. Do not operate this product in places where injury to people or damage to property might occur. For safe usage of LiPo batteries it is essential to follow the proper guidelines to handle them. Users are strongly recommended to read and understand the entire content of the “Owner’s Manual”.

  • Page 3: Table Of Contents

    SNAP&FLY -- Modularized RC Airplanes Page Contents Package Contents ………………………………………………………… Connecting Modules into Airplanes …………………………………… A. The Base Module B. The Airplane Modules C. Connecting Modules into Airplanes Radio System ……………………………………………………………. A. Transmitter B. Select Working Frequency C. Select Mixing Type D.

  • Page 4: Package Contents

    SNAP&FLY -- Modularized RC Airplanes 1. Package Content Photo 1. – Package Content (a) 1 Base module, (b) 1 Canard airplane module, (c) 1 Biplane module, (d) 1 V-tail airplane module, (e) 1 Radio transmitter, (f) 3 LiPo batteries, (g) 1 Spare motor, (h) 1 Spare motor mount, (i) 1 Spare propeller, 2.

  • Page 5: The Airplane Modules

    SNAP&FLY -- Modularized RC Airplanes The Base Module has a fuselage portion that houses the flight components: propeller, motor, receiver, actuators and push/pull rods. The magnetic connectors will connect the Base Module to an airplane module, and the magnetic connectors will ensure the control linkage connection between the Base Module and the airplane module.
  • Page 6 SNAP&FLY -- Modularized RC Airplanes connectors (g) and (h) of the Base Module (Photo 2A1). The push/pull rod linkages are formed by connecting the linkage rod connectors ( i) of the Base Module (Photo 2A1) to the matching connectors (c) of the airplane module (Photo 2B2). Photo 2B2.
  • Page 7 SNAP&FLY -- Modularized RC Airplanes Photo 2C1. – Hinge the Base Module to connect to the airplane module Photo 2C2. – Steps to connect modules into airplanes To disconnect the modules reverse the above steps: disconnect the module fuselages first, and disconnect the control linkage by separating the modules in a hinging motion. The magnetic connectors are designed to maintain the airplane integrity under normal flight conditions yet permit inter-modular disconnection under high impact events, such as a crash, to prevent the airplane from becoming damaged.

  • Page 8: Radio System

    SNAP&FLY -- Modularized RC Airplanes Photo 2C3. – The connected functional Canard Airplane Photo 2C4. – The connected functional Biplane Photo 2C5. – The connected functional V-tail Airplane Photo 2C3, 2C4 and 2C5 show the connected functional airplanes. 3. Radio System A.
  • Page 9 SNAP&FLY -- Modularized RC Airplanes Photo 3A – The transmitter overview (a) “On-Charge-Off” 3-position switch – Switch to the “On”(“Off”) position to turn the transmitter on (off); Switch to the “Charge” position to turn on the built-in dual-position LiPo battery charger;...

  • Page 10: Select Working Frequency

    SNAP&FLY -- Modularized RC Airplanes Transmitter Lever (e), Lever (e), Lever (f), Lever (f), Trimmer (g) Trimmer (h) Trimmer (i) Trimmer (j) - up/down - left/right - up/down - left/right mix0,1,2 mix3,4,5 mix0,1,2 mix3,4,5 CX9/860T Throttle +/- act. Turn L/R Elevator U/D Turn L/R act.

  • Page 11: Receiver

    SNAP&FLY -- Modularized RC Airplanes Select mixing type either before or after the transmitter is turned on. See section 5D for more details on control mixing selection. Refer to Table 3A for more control lever functions. The positions 6 and 7 on the mixing dial are reserved for transmitter analog control output and are unused in this product.

  • Page 12: Flying The Airplanes

    SNAP&FLY -- Modularized RC Airplanes Step 3. Turn on the transmitter – the transmitter LED (red) will flash for 4 seconds, the receiver will play music for 3 seconds, and both the transmitter and the receiver LEDs will become continuously lit. The frequency locking is then established. To prevent interference if the selected frequency is already occupied then the frequency- lock will not happen.

  • Page 13: Flying

    SNAP&FLY -- Modularized RC Airplanes iii. the control surfaces (elevon for the Canard plane, v-tails surfaces for the V-tail plane, and rudder/elevator for the Biplane) – verify the neutral positions (i.e. the control surface positions without any control lever inputs) and movement range and smoothness.

  • Page 14: Maintenance

    SNAP&FLY -- Modularized RC Airplanes Normal turn maneuver -- Initiate the turn by a moderate banking control input to induce the airplane banking, followed by a moderate up-elevator input to maintain the altitude while banking. A banking-alone turn will cause the airplane to lose altitude. The proper amount of elevator input for a turn depends on many factors, such as the airplane speed, the throttle and the degree of banking.

  • Page 15: Replacing The Propeller

    SNAP&FLY -- Modularized RC Airplanes 1) Align the LiPo battery’s magnetic connectors with the matching magnetic connectors of the charger, and connect the battery to the charger, as shown in Photo 5A; 2) Repeat 1) for the second battery at the second charging position if needed; 3) Close the charger cover;...

  • Page 16: Replacing The Motor

    SNAP&FLY -- Modularized RC Airplanes C. Replacing the Motor To remove the motor: 1) Slightly push the motor retaining lever backward to release the motor; 2) Remove the motor from the motor mount, as shown in Photo 5C1. Photo 5C1 – remove the motor To install a motor: Photo 5C2 –...

  • Page 17: Appendices

    SNAP&FLY -- Modularized RC Airplanes 6. Appendices A. Determine Control Mixing The mixing type selection of a certain airplane determines the responses of the actuators to the control inputs. To properly fly an airplane it is essential to select the control mixing type properly.
