THE "GO TO" GUYS IN ELECTRIC POWER
THE "GO TO" GUYS IN ELECTRIC POWER
KATANA 10e INSTRUCTION MANUAL
Aircraft Length:
Wing Span:
Wing Area:
Flying Weight:
E5-L-13 Common Sense RC Brushless Motor
11.1v 2100mAh 15C Common Sense RC LiPo Battery Pack
SPECIFICATIONS
33 in. / 838mm
33.5 in. / 851mm
272 sq. in.
20 oz. / 567g
REQUIRED
4 Channel Radio, 4 Micro Servos
Z-35 Common Sense RC 35 Amp ESC
10x5 E APC Propeller
www.CommonSenseRC.com
(Katana10E_manual_2-21-08_V1)

Advertisement

loading
Need help?

Need help?

Do you have a question about the KATANA 10e and is the answer not in the manual?

Questions and answers

Related Manuals for Common Sense RC KATANA 10e

Summary of Contents for Common Sense RC KATANA 10e

  • Page 1 Flying Weight: 20 oz. / 567g REQUIRED 4 Channel Radio, 4 Micro Servos E5-L-13 Common Sense RC Brushless Motor Z-35 Common Sense RC 35 Amp ESC 10x5 E APC Propeller 11.1v 2100mAh 15C Common Sense RC LiPo Battery Pack www.CommonSenseRC.com (Katana10E_manual_2-21-08_V1)

  • Page 2: Parts List

    PARTS LIST: 12. WOODEN PARTS: PLYWOOD 212 x 12 x 3mm -- 1 pc. (Wing Joiner) 1. FUSELAGE-- 1pc. PLYWOOD 15 x 15 x 2mm -- 2 pcs. (For Wheel Pants) 2. MAIN WING / WING FILLET-- 1 pair 13. PLASTIC PARTS: 3.
  • Page 3 Install the aileron hinges with thin CA, and attach the wing fillet as shown with epoxy. 2 Aileron Aileron Pushrod, 3 X4mm Rudder Pushrod, Elevator Pushrod Set up the aileron linkages as shown. 2 mm PM2x16mm 1.5mm Horn a. Install your aileron servos. b.
  • Page 4 Assemble the horizontal tail as shown, using the same techniques as with the vertical tail. Insert elevator into fuselage, then stabilizer, then install hinges. B = B' A = A' Make sure to insert the elevator and stabilizer into the fuselage BEFORE gluing hinges! Assemble the rudder linkage as shown, using the same technique as with the ailerons.

  • Page 5: Main Landing Gear

    Main Landing Gear Assemble the landing gear as shown. Install the motor as shown. Cowling & Canopy Install the cowl as shown. Magnetic Latch...
  • Page 6 Install the main wing using epoxy. 90mm 3.5in.
