ENA-001-010 | ENA-MINI-010
WyreStorm Enado™ Controller with IR, RS-232 & IP control
Installation Guide
Release Date:
Supported Firmware:
Thank you for choosing this WyreStorm product.
Please read these instructions carefully before installing to avoid complications later.
Copyright © 2016 WyreStorm Technologies |
[Date of Release]
4.0.0
wyrestorm.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENA-001-010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wyrestorm ENA-001-010

Summary of Contents for Wyrestorm ENA-001-010

  • Page 1 ENA-001-010 | ENA-MINI-010 WyreStorm Enado™ Controller with IR, RS-232 & IP control Installation Guide Release Date: [Date of Release] Supported Firmware: 4.0.0 Thank you for choosing this WyreStorm product. Please read these instructions carefully before installing to avoid complications later.

  • Page 2: Important! Safety Information

    Do Not Hot swap connections - Please insert and extract cables carefully with the power SWITCHED OFF. Power is passed along transmissions so connecting and disconnecting cables while powered can result in damage to circuitry or possible injury. 2 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 3: Table Of Contents

    Custom Image Will Not Upload ...................................31 Contacting Technical Support .....................................31 7 Warranty and Service ..............................32 Warranty Limits & Exclusions ....................................32 Obtaining Warranty Service ....................................32 Publication Disclaimer ..............................34 3 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 4: Introduction

    1 Introduction This Installation Guide will guide the installer through the process of installing and configuring a WyreStorm ENA-001-010 or ENA- MINI-010 controller. Print out this page to use as a checklist for items required to install this WyreStorm product.

  • Page 5: Product Overview

    The powerful software can run on any client device that offers a compatible web interface making the controller ideal for both professional and residential control. For further information on this product and other WyreStorm ranges, visit our website or download our latest product guide at wyrestorm.com Key Features ...

  • Page 6: Ena-001-010 Enado Control Solution

    Sensor I/O Are used to triggered open or closed circuits. Requires 12volt input USB 2.0 Port Can be used for an EasySync USB to RS485 adapter. 6 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...
  • Page 7 Maximum BTU 4.77 BTU/hr Dimensions and Weight Rack Units/Wall Box Height 26mm/1.03in Width 141mm/5.56in Depth 115mm/4.53in Weight 0.42kg/0.92lbs Regulatory Safety and Emission CE | FCC 7 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 8: Ena-Mini-010 Enado Mini Ip Control Solution

    10/100 Mbps Ethernet port. Connects to a LAN with a DHCP server for Enado to acquire an IP address. RS-232 Service For WyreStorm use only. Port Power Supply Connects to a 5v 2A power supply. Adapter 8 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 9: Specifications

     ENA-001-010  Cable/Satellite Box(es) & Bluray player(s)  Network router/switch  WyreStorm MX-0404-HDBT-H2-KIT with POH receivers 9 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...
  • Page 10 Basic Wiring Diagram 10 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...
  • Page 11 ENA-MINI-010 with Global Cache Adapater 11 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 12: Installation

    IR Wiring The below diagram shows the pinout for the WyreStorm CAB-IR-LINK integration cable. The mono tip plugs into one of the 16 IR outputs of the ENA-001-010 and the stereo tip into the IR RX port on a WyreStorm matrix, switcher or extender.
  • Page 13 Local Area Network (LAN) Wiring 13 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 14: Configuration

    Network Configuration Both the ENA-001-010 and the ENA-MINI-010 initially require a connection to a DHCP server to acquire an IP address. Once the connection is made the Enado Discover Tool can be used to quickly find the IP address assigned to the Enado and launch the web interface.

  • Page 15: Product Operation

    5 Product Operation This section outlines how to operate the ENA-001-010 or ENA-MINI-010 through the User Interface. Accessing the Configuration UI Initially when using the Discover Tool to launch the Enado user interface you will be directed to a page stating that No Published Projects Exist.

  • Page 16: Creating A Project

    Navigate to the Tools menu and select I/O Connectivity Settings  Adjust RS-232 settings by selecting the Edit button next to the appropriate RS-232 port (ENA-001-010 only)  Adjust IR port aliases by selecting the Show Outputs button and then clicking the Edit button next to the appropriate IR output (ENA-001-010 only) ...

  • Page 17: Downloading & Importing Device Commands

    Create a Command and choose the appropriate format for the commands (RS-232, IR or IP) Enter in the device command string in the Command Data section. 17 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...
  • Page 18 To view the commands and to ensure they have imported correctly navigate to the Tools menu and select Device Command Creator The below image shows an example XML file. Any XML created should follow the same formatting for proper import into Enado. 18 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...
  • Page 19 Command Editor that allows an existing command to be edited per byte and convert between ASCII and Hex. Command Generator that can be used to generate matrix switching and lighting commands. 19 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 20: Creating Rooms & Activity Buttons

    IR RX cable in to the IR IN port at the rear panel. Please note: IR Learning is only possible on the ENA-001-010. It may take multiple attempts to learn the correct IR command. It may be necessary to adjust the position of the IR remote for Enado to read the correct data.

  • Page 21: Creating Activity Layouts

    Edit Button/Row and adjusting the Row Height settings. The same can be adjusted for a button group’s width. Make this adjustment by left clicking a button group and choosing Edit Group. Then adjust the Width settings. 21 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...
  • Page 22 Global Buttons are located at the bottom right of the UI. Up to five Global buttons can be add per Zone/Room by simply clicking the white plus symbol at the bottom right of the configuration UI. 22 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 23: Adding Commands To Buttons

    Navigate to a different button and select Edit Properties Select the Pencil icon (Edit Properties) next to Command In the Command Clipboard section choose to either Paste Top or Bottom 23 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...
  • Page 24 Choose to overwrite, prepend or append any existing commands on existing Activity buttons Select the desired port for the commands to utilize Click the next button and select the desired commands for any existing Activity buttons 24 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...
  • Page 25 Please note: The initial state of a button group can be toggled between Visible and Hidden. By default a button group’s state will be visible. 25 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 26: Assigning Activity Layouts & Ports

    Please note: The size of this image will affect how quickly the Enado UI loads on the control device. Keep image size to a minimum. 26 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 27: Qr Codes

    Click Manage System Passwords then choose Create New Password Enter in the desired password and click confirm 10. Click the Enable button. A green “ON” indicator should appear 27 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 28: Triggered Commands

    Please note: For integration with IFTTT.com remote access will need to be configured. Please see the Integrating Enado & Amazon Echo Application Note, or the online user manual on the Help menu, for a detailed procedure on how to accomplish the integration. 28 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 29: Adding A Video Source

    Select the Pencil icon (Edit properties) next to Video Source Select the custom path video URL and click OK Publish the project for the video element to show in the Live UI 29 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 30: Publishing A Project

    Use “Room” or “Zone” in navigation Project & Controller Backup WyreStorm recommends always keeping a current backup of the Enado controller. To create a full controller backup perform the following steps. Navigate to the Tools menu and select Export/Backup Controller Allow the Enado to compile the controller backup and then click the download link To create project backups perform the following steps.

  • Page 31: Troubleshooting

    Ensure that the image is in a PNG format for buttons or PNG or JPG for Theme backgrounds. Contacting Technical Support Phone: UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) Email: Support@WyreStorm.com On Line Chat (Accessible through website): http://WyreStorm.com/Contact-Tech-Support 31 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 32: Warranty And Service

    Obtaining Warranty Service Prior to returning a WyreStorm product for factory service, a service authorization must be obtained from a WyreStorm technical support representative. At the time of contact an address for shipping and an authorization number will be supplied. Refer to Contacting Technical Support for contact information.
  • Page 33 33 of 34 ENA-001-010 | ENA-MINI-010Installation Guide | Copyright © 2016 WyreStorm Technologies | wyrestorm.com...

  • Page 34: Publication Disclaimer

    WyreStorm reserves the right to change software, control codes and specifications without notice. WyreStorm will not be liable for any use of this information or any changes it may make to those products. The use of this information constitutes an agreement by the user to these limitations and exclusions.
