Issue 27012009
HSDPA/UMTS/GSM/GPRS Terminal
ETM9900(J)
Quick Start Guide
Features:
◩ 3G (Tri-band HSDPA/UMTS) Connectivity
◩ Standard RS232 9DF serial port
◩ 6v to 35v power input on RJ12 connector
◩ 4(or 7) x digital, analogue or pulse I/O's on RJ45 connector
◩ SMA M antenna connector
◩ Sleep Mode for reduced power consumption
www.esis.com.au
Ph 02 9481 7420
Fax 02 9481 7267
esis.enq@esis.com.au
Cinterion
HC25(HC28) Inside
Advertisement
Table of Contents
Related Manuals for ETM ETM9900(J)
Summary of Contents for ETM ETM9900(J)
- Page 1 Issue 27012009 HSDPA/UMTS/GSM/GPRS Terminal ETM9900(J) Quick Start Guide Cinterion HC25(HC28) Inside Features: ◩ 3G (Tri-band HSDPA/UMTS) Connectivity ◩ Standard RS232 9DF serial port ◩ 6v to 35v power input on RJ12 connector ◩ 4(or 7) x digital, analogue or pulse I/O’s on RJ45 connector ◩...
-
Page 2: Table Of Contents
Page 2 of 16 Contents Introduction ............................4 Nomenclature ..........................4 Overview............................4 Applications ........................... 4 Interfaces ............................4 Power Supply ............................ 5 RJ45 I/O Connector .......................... 5 Serial (RS232) Port ........................... 6 Antenna ............................. 6 3V SIM Card ............................. 6 Indicator Lights .......................... - Page 3 Page 3 of 16 ETM9900(J) Quick Start Guide Issue 27012009...
-
Page 4: Introduction
Page 4 of 16 Introduction Nomenclature ETM9900 incorporates the Siemens HC25 engine and is intended for use within Australia, NZ and worldwide. The ETM9900J variant incorporates the Siemens HC28 engine and is intended for use within Japan on the Softbank network and global roaming. Overview. -
Page 5: Power Supply
Page 5 of 16 Power Supply The ETM9900(J) power connection is a 6 pin RJ12 connector, pin allocations are shown below. Function Power Supply (+6 to +35VDC) Not Used Not Used Not Used Not Used RJ45 I/O Connector 4 x I/O’s configurable as digital, analogue or pulse are available on the RJ45 connector, pin allocations are as shown below. -
Page 6: Serial (Rs232) Port
Page 6 of 16 Serial (RS232) Port The RS232 Port is the primary interface for the application software and connection to external devices. AT commands are used to communicate with the terminal. The RS232 interface is implemented as a 9-pin D-Sub socket with screw fittings. Function DCD Out RXD Out... -
Page 7: Indicator Lights
Page 7 of 16 Indicator Lights ETM9900 Status LEDs ETM9900-1/9900J Status LEDs YELLOW Green YELLOW Green UMTS MCU Status UMTS MCU Status Blue/RedLED Function (UMTS) Flashing LED flashes when the ME is registered to the UMTS network and either awake or in power saving state. While the STATUS1 (BLUE/RED) signal is active the STATUS0 (GREEN) signal is inactive. -
Page 8: Installation
Page 8 of 16 Installation 1. Connect a standard RS232 modem cable 9DF to 9DM between the ETM9900(J) Terminal and the external device or PC (a Serial/USB Adapter may be used if you computer does not have a serial port). 2. - Page 9 Page 9 of 16 Place curser in the black area of the terminal window and click mouse to ensure the terminal window is active. Connect the ETM9900(J) to your computer using the serial cable. Connect the power to the ETM9900(J) and repeatedly (usually three times) depress the ESC key on your computer.
-
Page 10: Modem Initialisation Settings - Main Init Tab
Circuit Switch Data Call. Control Via ET Commands As default the ETM9900(J) is set to ET Command Mode, ET Commands are specific to ETM terminals and allow for control, configuration and information requests to be sent to and from the terminal. - Page 11 Page 11 of 16 Command Command Action/Request/Notes Typical Response Format ETM9900 Send ETM9900 ID:”ID string” information information RTC: – Real Time Clock (Date and Time) REFDATE: – Reference date, Day counter TOTAL: – Total time since start RSTIN: – Time to SW reset RC SW: PU: –...
-
Page 12: Dry Contact Generated Sms Alarm
Page 12 of 16 Dry contact generated SMS alarm One or more of the four I/O’s can be used to generate an SMS alarm message from the ETM9900(J) unit. Typical applications include; ◩ Security, reed switch on a door/window or alarm relay from a security panel ◩... - Page 13 Page 13 of 16 2. Set I/O1 as Digital Low to High (NC), the message Tank Level Low will be sent to each phone number when I/O1 changes from closed to open circuit Note: 1. Delay before alarm is activated is recommended to reduce the incidence of multiple SMS being sent in the event of chattering/bouncing contacts 2.
-
Page 14: Temperature Alarm
Page 14 of 16 Temperature Alarm I/O 3 and 4 can be used as analogue 0-2.5V analogue inputs, which can be used in numerous applications including; ◩ Temperature monitoring of a cool room or PC/Server room ◩ Monitoring tank, or stream levels using a level transmitter Example Monitor a server room, SMS based on temperature rise and/or fault alarm from A/C unit. -
Page 15: Etm9900(J) Quick Start Guide Issue
Page 15 of 16 Set I/O1 as Digital High to Low (NO), the message A/C Unit Fault will be sent to each phone number when I/O1 changes from open to closed circuit Set I/O3 as Analogue, in this case 4mA represents -40 C which corresponds to 500mV and 20mA represents 85 C which corresponds to 2500mV therefore 1500mV trip point equates... - Page 16 Ph 02 9481 7420 Fax 02 9481 7267 esis.enq@esis.com.au © ETM Matteknik AB · Subject to change without notice.
