Page 1: Time Server
907,900 NETSILON 7 (100-240 VAC) 907,901 NETSILON 7 (18-36 VDC) 907,902 NETSILON 7 (100-240 VAC + 18-36 VDC) BODET SA BP30001 49340 Trementines, France Tel. support France: 02.41.71.72.99 www.bodet-time.com Fax France: 02.41.71.72.01 On receipt, ensure that the product has not been damaged during transportation and report any concerns to the carrier. -
Page 2: Table Of Contents
CONTENTS 1. General points 1.1 introduction 1.2 netsilon presentation 1.2.1. Front panel 1.2.2. Rear panel 2. installation 2.1 Checking the package 2.2 safety 2.2.1. Installing the equipment 2.2.2. Opening the equipment 2.2.3. Earth connection 2.3 Mechanical rack installation 2.4 electrical installation 2.4.1. -
Page 3: General Points
1. General points Thank you for choosing the BODET Netsilon time server. This product has been carefully designed to meet your needs in accordance with ISO 9001 quality standards. 1.1 introduction We recommend that you read this manual carefully before using the product for the first time. - Page 4 The option cards are installed in our production factory. For subsequent installation, refer to the expansion card installation guide. Common/Normally-Closed/Normally-Open relay contact output. If contact Normally-Open: no alarms / If contact Normally-Closed: alarms. Terminal for GPS antenna: Alarms input: interfaces with the dry contact of the client equipment. Serial port.
-
Page 5: Installation
Electrical installation of the equipment must comply with applicable electrical standards. 2.2.2. Opening the equipment There are no user-repairable parts inside this equipment. Please contact BODET customer support if the equipment needs to be repaired. Do not open the product except when adding or replacing expansion cards: >... -
Page 6: Mechanical Rack Installation
2.3 Mechanical rack installation The Netsilon time server should be installed in a 19” rack or cabinet, using the two brackets supplied. 2.4 electrical installation All cables must be securely attached to the chassis before being connected to the various terminal blocks in order to prevent traction on connections. -
Page 7: Commissioning
3. CoMMissioninG Netsilon configuration is performed exclusively on the web server. In order to be able to access the web server it is necessary to configure the ETH0 port via the front panel keypad and the LCD screen. TIP: i n order not to disrupt Netsilon synchronisation with the other products present on the network, it is important to maintain identification of the time server. -
Page 8: Choosing The Lcd Screen Display Language
3.2 Choosing the lCD screen display language The network settings for configuration of the ETH0 port (assignment of an IP address) can be read or configured via the Netsilon control panel. It is first necessary to select the product’s display language: 10:54.32 Mon 19 SEP 2016 System... -
Page 9: Configuration Without A Dhcp Server
3.4 Configuration without a DHCP server Without automatic assignment of an IP address by a DHCP server, it is necessary to manually assign a fixed IP address. To manually configure the Netsilon network settings, enter the following three parameters: > IP address assignment > This is a unique address assigned to Netsilon by the network administrator. Ensure that the chosen address is available. -
Page 10: Web Server Menus
5. sUpport > To request technical assistance for this equipment : http://www.bodet-time.com/assistance-clientele.html > Telephone support is available from Monday to Friday from 8 am to 12 pm and from 1:30 pm to 5 pm. To speed up the diagnosis of your Netsilon, perform a system backup and note the Netsilon MAC address.
