High Definition Replay System
INSTRUCTION MANUAL
VERSION: 110930
B U F T e c h n o l o g y , 1 2 3 3 5 W o r l d T r a d e D r i v e , S u i t e 1 1 , S a n D i e g o , C A
9 2 1 2 8
T e l e p h o n e : 8 5 8 - 4 5 1 - 1 3 5 0
w w w . b u f t e k . c o m
F a x :
8 5 8 - 4 5 1 - 6 5 8 9

Advertisement

Table of Contents
loading

Related Manuals for Buf Technology Sport-HD

Summary of Contents for Buf Technology Sport-HD

  • Page 1 High Definition Replay System INSTRUCTION MANUAL VERSION: 110930 B U F T e c h n o l o g y , 1 2 3 3 5 W o r l d T r a d e D r i v e , S u i t e 1 1 , S a n D i e g o , C A 9 2 1 2 8 T e l e p h o n e : 8 5 8 - 4 5 1 - 1 3 5 0 w w w .

  • Page 2: Table Of Contents

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 2 of 20 TABLE OF CONTENTS INTRODUCTION ................................4 FCC RADIO FREQUENCY INTERFERENCE STATEMENT ................4 WARRANTY STATEMENT............................. 4 OVERVIEW ................................4 QUICK REFERENCE.............................. 6 INSTALLATION ..............................7 BASIC OPERATION ............................... 8 COLD BOOT ................................8 OPERATION.................................
  • Page 3 Version: 110930 Sport-HD INSTRUCTION MANUAL Page 3 of 20 COMPRESSION (SD CHANNELS ONLY)...................... 16 TV STANDARD SEL............................16 DELETE CLIPS..............................16 DELETE NON-PL CLIPS..........................16 CLEAR CUES NO DELETE ..........................16 ERASE ALL VIDEO............................17 FORMAT DISK!!! ............................. 17 REC END MODE.............................. 17 MAXIMUM RECORD DURATION ........................

  • Page 4: Introduction

    The disk drive used in the Sport-HD Replay System is not warranted by BUF Technology. Please refer to the respective disk drive manufacturer for warranty information. When Sport-HD is disconnected from its power supply, power should not be reapplied for at least five (5) seconds.
  • Page 5 Version: 110930 Sport-HD INSTRUCTION MANUAL Page 5 of 20 SPORT-EX CONTROL PANEL...

  • Page 6: Quick Reference

    QUICK REFERENCE To best learn Sport-HD, feed channels with test sources (tape, off air, or DVD), and outputs to monitors. Don't use static pictures for testing, the more motion the better. Start with displays, F1-Fx, REC, MARK, CUE, PLAY, SLOW, KNOB, SCAN ( ).

  • Page 7: Installation

    Page 7 of 20 INSTALLATION 1. Install the RM-HD1 and/or RM-HD2 SPORT-HD Replay Recorders in a 19 inch rack using standard mounting methods. The rear of the units may secured if desired using separately purchased rack ears (required only in high shock applications).

  • Page 8: Basic Operation

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 8 of 20 BASIC OPERATION 1. To select a channel for control, press its F-key (F1 for ch-1, etc.). Double-tap the F-key to select all channels. Hold the F-key and tap others to select some channels. The red LED lights above channels selected for control, the green LED lights above the status channel (the channel shown on the STATUS display).

  • Page 9: Operation

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 9 of 20 OPERATION SELECTING CHANNELS To select a channel for control, press its F-key (F1 for ch-1, F2 for ch-2, etc.). Double-tap the F-key to select all channels. Hold the F-key and tap others to select some channels. The red LED lights above channels selected for control, the green LED lights above the status channel (the channel shown on the STATUS display).

  • Page 10: Playback Without Tbar

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 10 of 20 PLAYBACK WITHOUT TBAR Playback behavior is somewhat different if the TBar is not connected: Press SLOW to begin slow motion playback paused, or press a speed preset key (F7-F9 by default) to start at another speed, use the knob to vary the playback speed from 0% to 100%.

  • Page 11: Preroll

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 11 of 20 with a period after the number). DELETE NON-PL CLIPS does the same, but skips cue points and clips that are used in playlists. CLEAR CUES NO DELETE deletes a range of cue points, but not the clips - it does not erase any recorded material.

  • Page 12: Clip Scan

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 12 of 20 from the bottom to begins slow motion playback. The default scan speeds are 6 times normal speed. To change the scan speed, press SETUP, the scan key to change, turn the knob until the desired speed is shown, then press ENTER.

  • Page 13: Looping

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 13 of 20 playlist, so don't assume pressing PLAYLIST will load the same one you've been setting up (if in doubt, always hit the playlist number on the keypad before hitting PLAYLIST). Playback speed can be varied while a playlist is playing, just hit F9 to change to 75% (by default), and turn the knob to vary speed on the fly.

  • Page 14: Playlist Display

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 14 of 20 PLAYLIST DISPLAY The PLAYLIST button toggles the playlist mode on and off. If a number key (0-4) is pressed before PLAYLIST, that playlist is selected for playback. While playlist mode is enabled (PLAYLIST LED lit), the MENU display shows the playlist number and the current and next steps and cue points.

  • Page 15: Customization

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 15 of 20 CUSTOMIZATION PERSONALITY MENU ITEMS All user configuration settings are stored in permanent memory and remain safe even after extended periods without power (at least 10 years). Settings can be stored in any of five personality registers for later recall, allowing different users to personalize the panel to their preferences.

  • Page 16: Ext Ddr Software Update

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 16 of 20 access to the server. The server operates in “Native” mode and Odetics protocol extensions are not available. EXT ODETICS CNT changes the mode of the server to Odetics protocol mode, then releases control to the REMOTE connector.

  • Page 17: Erase All Video

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 17 of 20 ERASE ALL VIDEO Deletes all recorded clips, cue points, and playlists. This cannot be undone! FORMAT DISK!!! Formats a disk for recording. This menu item allows a new disk to be formatted for use. Once formatted, power must be removed (always for at least 5 seconds), then restored.

  • Page 18: Cue Points

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 18 of 20 CUE POINTS Press SETUP, CUE to enter the CUE POINTS menu. While in this menu, you can scroll through all cue points using the knob. SET PREROLL Press SETUP, PREROLL to change the preroll time. The PREROLL key operates identically to the CUE key except it cues to a point earlier than the IN or OUT point being cued.

  • Page 19: Specifications

    Version: 110930 Sport-HD INSTRUCTION MANUAL Page 19 of 20 SPECIFICATIONS VIDEO Standards: SMPTE 274M (1080I/29.97), SMPTE 296M (720P/59.94) Input: HDSDI (1) BNC 75 OHM Output: HDSDI (1) BNC 75 OHM Supported Resolutions: 1920 x 1080I/29.97 1280 x 720P/59.94 1920 x 1080I/25...
  • Page 20 Version: 110930 Sport-HD INSTRUCTION MANUAL Page 20 of 20 FRONT PANEL SINGLE REAR PANEL SINGLE FRONT PANEL DUAL REAR PANEL DUAL...
