MusicMan
* User Manual
Slim Bluetooth Headphone BT–X27
With this comfortable and good fitting Bluetooth headphone
you have surround sound experience and additionally FM radio
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares
that this device, to which this user manual belongs, complies with the essential
requirements of the standards referred to the Directive RED 2014/53/EU. The
Declaration of Conformity you find here: www.technaxx.de/ (in bar at the
bottom "Konformitätserklärung"). Before using the device the first time, read
the user manual carefully.
This device has a rechargeable battery. It must be fully charged before
first use.
NOTE: Charge the battery of the device every 2–3 month if it is not used!
Turn OFF nearby Bluetooth devices to avoid signal interference!
WARNING: DO NOT TURN THE VOLUME TOO HIGH – HEARING LOSS
MIGHT BE THE RESULT!
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Free Email: support@technaxx.de
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Warranty 2 years

Features

Music transfer & hands-free function via Bluetooth V4.2
Built-in
FM radio
When incoming call, music playback is paused
automatically
Supports MicroSD cards up to 32GB
Supports
computer, MP3, CD and AUX–IN
Foldable headphone with soft
cushioning for comfortable fit
Balanced-clear sound performance
in low and high sound ranges
Built-in rechargeable 400mAh
battery for portable use
LED indicator shows the working status
Easy to use, super slim and very light

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT–X27 and is the answer not in the manual?

Questions and answers

Summary of Contents for MusicMan BT–X27

  • Page 1 ® MusicMan * User Manual Slim Bluetooth Headphone BT–X27 With this comfortable and good fitting Bluetooth headphone you have surround sound experience and additionally FM radio The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device, to which this user manual belongs, complies with the essential requirements of the standards referred to the Directive RED 2014/53/EU.
  • Page 2: Technical Specifications

    Technical Specifications Bluetooth / Transmitting distance V4.2, 25mW / ~10m (open space) Bluetooth, Line–IN/AUX–IN, Handsfree, radio, 5 Functions MicroSD card (only MP3 files) Power Built-in rechargable 400mAh lithium polymer battery 3.7V Charging time ~3 hours (DC 5V / 500mA power adaptor) Playing time ~8 hours (max.
  • Page 3: Product Overview

    Product Overview 1 Keep pressing the button 3 sec. to Power ON/OFF the headphone. Under Bluetooth mode, short press to receive or end calls. 2 MODE: MicroSD card, AUX-IN, Bluetooth, FM Radio 3 Short press to PLAY or PAUSE. Under FM radio mode, short press to enter automatic searching.
  • Page 4 (e.g. Smartphone) you want to pair with the headphone. The headphone will automatically turn on the Bluetooth. Search the headphone with a name „MusicMan BT-X27“. Music can be streamed after pairing successfully (BLUE LED will be steady on).
  • Page 5 3. Bluetooth Music After successful pairing, click the key once to play the music sourcing from your Smartphone (BLUE LED flashes). Click again to pause. Change songs: Press short key for the next song, press short key for the previous song. Adjust volume: Press and hold long + key to increase the volume, press and hold long - key to decrease the volume.
  • Page 6 6. FM Radio Mode Press Mode (2) till you enter FM radio mode. If a channel is received (frequency range 87.5 – 108.0MHz), you hear the channel; if no channel is received, you hear a rushing noise. In that case you have to search for a channel.
  • Page 7 Troubleshooting The Karaoke BT-X27 powers Off or does not turn On again could be either a low battery or a problem with the power supply charge the BT-X27 and check the connection of the Micro-USB cable. (We suggest charging the BT-X27 all 2-3 month if it is not used for a long time.) Noises are heard from the BT-X27 could be a poor Bluetooth...
