- Page 1 MIX-16/MIX-32 USER GUIDE Version 1.2 January 2017 1266 Park Road Chanhassen, MN 55317 952-401-7700 support@digitalaudio.com www.digitalaudio.com...
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. CONTACT DIGITAL AUDIO LABS FOR SERVICING. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated and/or potentially dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 3: Digital Audio Labs Limited Warranty
Digital Audio Labs warrants their products against defects in material and workmanship for a period of two years from date of purchase. During this period, Digital Audio Labs will, at its option, repair the defective unit or replace it with a new or rebuilt one. -
Page 4: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ..................II IMPORTANT SAFETY INSTRUCTIONS ............II CARE ......................II DIGITAL AUDIO LABS LIMITED WARRANTY............1 REPAIR POLICY ....................1 WARRANTY SERVICE..................1 NON-WARRANTY SERVICE ................1 CONTENTS OF BOX ................... 3 INTRODUCTION ....................3 ANATOMY OF THE MIX-16/MIX-32* ............3 SETUP DIAGRAMS .................... -
Page 5: Contents Of Box
MIX-32. This will be unused if using the LM-DANTE-EXP Dante Option Card. LIVEMIX DATA LIVEMIX DATA LIVEMIX DATA MIX-16 MIX-16/32 24VDC OUT 2 (MIX-32 ONLY) OUT 1 3.75A 3. POWER SWITCH: This switch turns power on/off. The MIX-16/MIX-32 supplies power to connected Livemix personal mixers. LIVEMIX MIX-16/32... - Page 6 8. LIVEMIX DATA OUT 1: This port connects to a Livemix DA-816 analog output rack unit. 9. LIVEMIX DATA OUT 2 (MIX-32 ONLY): This port connects to a Livemix DA-816 analog output rack unit. If only using one DA-816, connect to the Livemix Data Out 1. LIVEMIX MIX-16/32...
-
Page 7: Setup Diagrams
PUSH FOR MASTER SETUP PUSH FOR MASTER SETUP PUSH FOR MASTER SETUP PUSH FOR MASTER SETUP Each MIX-16/32 Control Surface Port supports a maximum combined CAT5e (shielded recommended) cable distance of 100 meters. LIVEMIX MIX-16/32 CS-SOLO CS-SOLO CS-SOLO CS-SOLO INTERCOM... -
Page 8: Mix-16/Mix-32 To Livemix Cs-Solo/Cs-Duo Personal Mixers
DA-816 LIVEMIX DATA Dante™ is a trademark of Audinate Pty Ltd. 12VDC LINK/ACT 3.33A BALANCED +4dBu LINE OUT BALANCED +4dBu LINE OUT DA-816 LIVEMIX DATA 12VDC 3.33A BALANCED +4dBu LINE OUT LIVEMIX MIX-16/32 MIX-32 WIRELESS TRANSMITTER 2 WIRELESS TRANSMITTER 1... -
Page 9: Setup And Operation
Control Surface Port may help identify appropriate. each personal mixer when using the MirrorMix ® remote mixing feature. 3. Connect the power supply on the back of the MIX-16/ MIX-32 to an appropriate power source. 4. Turn on the MIX-16/MIX-32. LIVEMIX MIX-16/32... -
Page 10: Mix-16/Mix-32 Firmware Update Instructions
6. Insert USB flash drive containing the update, when prompted. PRESS one personal mixer Continue or Exit to cancel. Once the update has begun, do not turn connected. off the power to the MIX-16/MIX-32 or you may damage the unit. LIVEMIX MIX-16/32... -
Page 11: Livemix System Examples
CAT5e/CAT6 cable to one of the ports of the MIX-16/MIX-32. Using various controls on the unit, users can each create their own custom mix, which is then output to headphones, in-ear monitors or stage monitors, directly from the personal mixer or Livemix DA-816 analog output unit. LIVEMIX MIX-16/32... -
Page 12: Troubleshooting
TROUBLESHOOTING Verify that you have connected the external power supply to a working power outlet. The Livemix MIX-16/MIX-32 is not powering on correctly. Verify that the front panel power switch is set to ON. If the Livemix Data light is not illuminating, there is a problem with the power to the MIX- 16/MIX-32. -
Page 13: Livemix Support
LIVEMIX SUPPORT Phone Support: 952-401-7700 Toll Free: 844-DAL-INFO Email Support: support@digitalaudio.com Website: www.digitalaudio.com/support DIGITAL AUDIO LABS 1266 Park Rd Chanhassen, MN 55317 TECHNICAL SPECIFICATIONS MIX-16/MIX-32 Max Cable Length 100m CAT5e cable to CS-SOLO/CS-DUO (shielded recommended) 100m CAT5e cable Max Cable Length to AD-24/DA-816... -
Page 14: Mix-16/Mix
Open Source Statement The Livemix MIX-16/MIX-32 firmware includes the open source software module FreeRTOS, which is licensed under the terms of the GNU General Public License (version 2) AND MODIFIED BY the FreeRTOS exception, as outlined in the FreeRTOS license. In accordance with those licensing terms, we must provide you the source code for the version of FreeRTOS used in the MIX-16/MIX- 32. - Page 15 ® 2014, 2015 Digital Audio Labs. ™ & © 2017 Digital Audio Labs. Audinate®, the Audinate logo and Dante are trademarks of Audinate Pty Ltd. Livemix is a registered trademark of Digital Audio Labs. Patents pending.
