INDEX
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . 3
FREQUENCY RESPONSE . . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONS AND FLYING POINTS . . . . . . . . . . . . . 4
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONTROL PANEL (FIG.1/2) . . . . . . . . . . . . . . . . . . . 6
FLASH5A CONNECTIONS (FIG.3) . . . . . . . . . . . . . . 6
CONFIGURATIONS (FIG.4/5) . . . . . . . . . . . . . . . . . . 7
SAFETY AND PRECAUTIONS . . . . . . . . . . . . . . . . . . 8
IN CASE OF FAULT . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . 8
CE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PACKAGING, SHIPPING AND COMPLAINT . . . . . . . 9
WARRANTY AND PRODUCTS RETURN . . . . . . . . . . 9
INSTALLATION AND DISCLAIMER . . . . . . . . . . . . . . 9
POWER SUPPLY AND MAINTENANCE . . . . . . . . . . 9
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . 10
INSTRUCTIONS (FIG. 1 / 2 / 3) . . . . . . . . . . . . . . . 10

TECHNICAL SPECIFICATIONS

MODEL
System type
High Frequency Device
Low Frequency Device
Angular coverage
Nominal Impedance
Input Power Ra ng (con nuos)
Input Power Ra ng (peak)
Amplifi er Peak Power
HF Amplifi er Con nuous Power
LF Amplifi er Con nuous Power
Frequency response
Sensi vity
Max SPL
Connectors
Controls
Crossover Frequency
Input Impedance (XLR / JACK)
Input Sensi vity (XLR / JACK)
Input Impedance (RCA)
Input Sensi vity (RCA)
Monitor taper
Flying System
Construc on
Cabinet Colour
Weight
Dimensions (W x H x D)
Power Supply
Consump on
FLASH5AV2
2-way vented enclosure
1'' so dome tweeter on ellip cal waveguide
5'' woofer
90° H x 60° V
-
-
-
200 W
20 W Class AB
80 W Class D
70 Hz - 20 kHz
-
114 dB
RCA / XLR / JACK
Level, gnd li , NEAR FIELD / MID FIELD
3000 Hz
30 kohm balanced / 15 kohm unbalanced
0 dBu / 0.775 V
10 kohm unbalanced
-10 dBu / 0.245 V
42°
3 x M6 - top, bo om
Polypropylene
Black
3.6 kg (7.9 lb)
175 x 265 x 176.5 mm
230 VAC or 120 VAC - 50/60 Hz
60 W
INDICE
SPECIFICHE TECNICHE . . . . . . . . . . . . . . . . . . . . . . 3
RISPOSTA IN FREQUENZA . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONI E PUNTI DI SOSPENSIONE. . . . . . . . . 4
ACCESSORI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PANNELLO DI CONTROLLO (FIG.1/2) . . . . . . . . . . . 6
FLASH5A CONNESSIONI (FIG.3) . . . . . . . . . . . . . . . 6
CONFIGURAZIONI (FIG.4/5) . . . . . . . . . . . . . . . . . . 7
AVVERTENZE PER LA SICUREZZA . . . . . . . . . . . . . 12
IN CASO DI GUASTO . . . . . . . . . . . . . . . . . . . . . . . 12
PROBLEMATICHE COMUNI . . . . . . . . . . . . . . . . . . 12
CONFORMITÀ CE . . . . . . . . . . . . . . . . . . . . . . . . . . 13
IMBALLAGGIO, TRASPORTO E RECLAMI . . . . . . . 13
GARANZIE E RESI . . . . . . . . . . . . . . . . . . . . . . . . . 13
INSTALLAZIONE E LIMITAZIONI D'USO . . . . . . . . . 13
ALIMENTAZIONE E MANUTENZIONE . . . . . . . . . . 13
INFORMAZIONI GENERALI . . . . . . . . . . . . . . . . . . 14
ISTRUZIONI (FIG. 1 / 2 / 3) . . . . . . . . . . . . . . . . . . 14

SPECIFICHE TECNICHE

FLASH5PV2
2-way vented enclosure
1'' so dome tweeter on ellip cal waveguide
5'' woofer
90° H x 60° V
16 ohm
80 W
160 W
-
-
80 Hz - 20 kHz
91 dB @ 1 W/1 m
113 dB
Push terminals
-
3000 Hz
42°
3 x M6 - top, bo om
Polypropylene
Black or White
2.5 kg (5.5 lb)
175 x 265 x 176.5 mm
-
-
3
