USER MANUAL
V1.2
3 AXIS HANDHELD
GIMBAL
Compatible With:
IMPORTANT MESSAGE
Thank you for choosing EVO Gimbals as your camera stabilization
solution! We know that buying a new product can be very exciting
and we are sure that you probably can not wait to use your new
gimbal! Before you start PLEASE read this manual and become
familiar with your gimbal's components and operating modes.
We highly encourage everyone to also watch our great tutorial videos
on our website as a supplement to this manual.
BATTERY SAFETY!
Your Gimbal includes (2) Lithium Ion Batteries that must be handled with care!
Here are some simple safety precautions you can take to ensure the best
performance for your batteries.
- Always handle your batteries with care.
- Always store your batteries in a cool dry and well ventilated area.
- Never mix the batteries with di erent brand, type or model battery.
- Always charge batteries in proper charger.
- Keep out of reach of children
- Always pack batteries securely and avoid excessive shock and vibration
- Regularly inspect batteries for exterior wear.
- Never throw your batteries in the trash! Always be sure to recycle them at the
appropriate battery recycling center.
Lithium-Ion batteries should not be exposed to extreme temperatures. Heat and
cold stress the batteries. Always charge and use your batteries at room tempera-
ture. If the battery has been exposed to extreme temperatures, allow the battery
to return to room temperature before charging it or using it.
WARRANTY
WARRANTY
Your new gimbal comes with a 1 Year Parts & Labor warranty. Be sure
to register your warranty by registering online at EVOGimbals.com
LATEST INFORMATION
For the latest user manuals, tutorial videos, rmware and calibration
instructions please visit our o cial wepage at EVOGimbals.com
Phone:
+1 541 728 3741
Website:
www.evogimbals.com
Address:
20810 Sockeye Pl
Suite 200
Bend, Oregon 97701
